StarTech.com PCI Combo Card 2x Serial/1x Parallel

PB Tech price
PB Tech price
$ 56 .52
 +GST
$ 65 .00
 inc GST

Out of stock

StarTech.com PCI Combo Card 2x Serial/1x Parallel

PB Tech price
$ 56 .52 $ 65 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?

Features

This PCI 1x Parallel and 2x Serial Combo Card installs into a single PCI slot in your computer (occupying 2 to 3 expansion slots, depending on profile), and adds a DB25 IEEE 1284 parallel port and two DB9 RS 232 serial ports to your system.

Adds an LPT Parallel Port

The controller card features an Asix MCS9865 chip and enables you to connect a DB25 parallel device to your desktop computer. The parallel port is ideal for connecting printers, scanners, plotters, point-of-sale terminals, PLCs, scientific sensors, medical equipment or oscilloscopes. The parallel (LPT) port supports SPP/Byte/Nibble/ECP/EPP modes and IEEE 1284 for speeds up to 1.5Mbps.

Adds a COM Serial Port

The Asix MCS9865 chip also enables you to connect two DB9 devices using the same controller card, compatible with industry standard 16C550 UART. The serial ports are ideal for connecting point of sale terminals, serial printers, PLCs, control/automation in factories, scientific sensors, medical equipment, scanners and oscilloscopes. The serial (COM) ports support bi-directional RS232 speeds up to 115.2Kbps per port, available 256 byte FIFO buffer & 9th data bit.

Wide Installation Compatibility

With broad OS support, including for Windows (7 and up), and Linux (2.6.x to 5.x LTS versions only), this PCI serial/parallel card is easy to integrate into mixed environments. The card comes pre-configured with 2x full-profile brackets, and includes optional 3x low-profile brackets, so installation is easy regardless of the case form factor.

- PCI CARD WITH SERIAL & PARALLEL PORTS: Using one PCI bus, add a DB25 parallel & two DB9 RS232 ports to your computer; Serial Parallel PCI Card installs in 2x full profile or 3x low profile expansion slots; Auto IRQ & IO assignment; Supports IRQ Sharing

- TECH SPECS: Parallel Speeds up to 1.5Mbps | Supports SPP/Byte/ECP/EPP modes | Compatible with IEEE 1284 | Asix MCS9865 chip | RS-232 speeds up to 115.2 Kbps | 16C550 UART | 256 byte FIFO buffer | 5-9 bit character | Even, Odd, No, Space or Mark Parity

- VERSATILE APPLICATIONS: PCI expansion combo card adds LPT Printer & two COM serial ports working with printers, scanners, plotters, point of sale terminals, PLCs, control/automation in factories, scientific sensors, medical equipment, oscilloscope

- STANDARD PROFILE & LOW PROFILE BRACKETs: PCI multiport Parallel LPT & dual serial COM adapter card installs using 2x standard bracket (pre-installed) or 3x low profile brackets (incl); Supports Windows 7 and up, Linux 2.6.x to 5.x

Specifications

Connector(s)

Connector Type(s)

1 - PCI (5V, 32-bit)

External Ports

2 - DB-9 (9 pin, D-Sub)
1 - DB-25 (25 pin, D-Sub)

Environmental

Operating Temperature

0°C to 70°C (32°F to 158°F)

Storage Temperature

-20°C to 85°C (-4°F to 185°F)

Humidity

10~90% RH

Hardware

Ports

3

Interface

PCI / PCI-X (5 / 3.3V)

Bus Type

Parallel
Serial

Card Type

Standard Profile (LP bracket incl.)

Port Style

Integrated on Card

Industry Standards

IEEE 1284
16C550 (RS-232)

Chipset ID

Asix - MCS9865

Packaging Information

Shipping (Package) Weight

6.7 oz [190.0 g]

Package Height

1.2 in [3.0 cm]

Package Length

6.7 in [17.0 cm]

Package Width

5.6 in [14.2 cm]

Performance

Maximum Data Transfer Rate

Serial - 115.2Kbps
Parallel - 1.5Mbps

Serial Protocol

RS-232

Max Baud Rate

115.2 Kbps

Data Bits

5, 6, 7, 8, 9

FIFO

256 Bytes

Flow Control

None, Xon/Xoff, RTS/CTS

Parity

None, Odd, Even, Space, Mark

Stop Bits

1, 1.5, 2

Physical Characteristics

Color

Black

Product Height

4.7 in [12.0 cm]

Weight of Product

5.0 oz [141.0 g]

Product Length

5.3 in [13.4 cm]

Product Width

0.9 in [2.2 cm]

Software

OS Compatibility

Windows® 7, 8, 8.1, 10, 11
Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
Linux 2.6.x to 5.x LTS Versions only

Manufacturer Part No:
PCI2S1P2
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IDESTT5305730
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
