Grandstream HT802 V2 2-Port FXS Analog Telephone Adapter (ATA)

PB Tech price
PB Tech price
$ 72 .25
 +GST
$ 83 .09
 inc GST
$72.25  +GST
$83.09

Grandstream HT802 V2 2-Port FXS Analog Telephone Adapter (ATA)

PB Tech price
$ 72 .25 $ 83 .09
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 26 Sep When will I receive it?
$72.25  +GST
$83.09

Colour

Black

Interface

RJ45

Microphone

No

Microphone Noise Cancelling

N/A

Noise Cancelling

N/A

Sound Mode

N/A

Wireless Technology

N/A

Features

The Grandstream HT802V2 is a 2 port VoIP analogue telephone adapter (ATA) that allows users to create a high-quality and manageable IP telephony solution for residential and office environments. Its ultra-compact size, voice quality, advanced VoIP functionality, security protection and auto provisioning options enable users to take advantage of VoIP on analogue phones and enables service providers to offer high quality IP service. The HT802 is an ideal ATA for individual use and for large scale commercial IP voice deployments.

- Supports 2 SIP profiles through 2 FXS ports and a single 10/100Mbps port
- TLS and SRTP security encryption technology to protect calls and accounts
- Automated provisioning options include TR-069 and XML config files
- Supports 3-way voice conferencing
- Failover SIP server automatically switches to secondary server if main server loses connection
- Supports T.38 Fax for creating Fax-over-IP
- Supports a wide range of caller ID formats
- Use with Grandstream's UCM series of IP PBXs for Zero Configuration provisioning

Specifications

Brand

Grandstream

Manufacturer Part Number

HT802V2

Telephony Interface

Two (2) FXS ports

Network Interface

One (1) 10/100Mbps auto-sensing ethernet ports (RJ45)

Telephony Features

Caller ID display or block, call waiting, flash, blind or attended transfer, forward, hold, do not disturb, 3-way conference

Fax over IP

T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Pass-through

Short/Long Haul Ring Load

2 REN: Up to 1km on 24 AWG

Caller ID

Bellcore Type 1 & 2, ETSI, BT, NTT, and DTMF-based CID

Disconnect Methods

Busy Tone, Polarity Reversal/Wink, Loop Current

Network Protocols

TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS, DHCP, NTP, TFTP, TELNET, STUN, SIP (RFC3261), SIP over TCP/TLS, SRTP, TR-069

QoS

Layer 3 (ToS, DiffServ, MPLS)

DTMF Method

In-audio, RFC2833 and/or SIP INFO

Dimensions

100mm x 100mm x 29.5mm

Upgrade/Provisioning

HTTP, HTTPS, TELNET, TFTP, TR-069, secure and automated provisioning using AES encryption, syslog

Manufacturer Part No:
HT802V2
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.5 kg
PB Part No:
IPHGSM489392
Product Model:
HT802 V2
Warranty: 12 months *
