StarTech.com SV431DPDDUA2 4 Port Dual DisplayPort KVM Switch - DisplayPort 1.2 KVM - 4K 60Hz
StarTech.com SV431DPDDUA2 4 Port Dual DisplayPort KVM Switch - DisplayPort 1.2 KVM - 4K 60Hz
- Brand: StarTech.com
- MPN: SV431DPDDUA2
- Part #: KVMSTT4157163
- UPC: 065030867863
Select your store to check availability
- Brand: StarTech.com
- MPN: SV431DPDDUA2
- Part #: KVMSTT4157163
- UPC: 065030867863
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Other KVM Accessories
StarTech.com SV431DPDDUA2 4 Port Dual DisplayPort KVM Switch - DisplayPort 1.2 KVM - 4K 60Hz
- Brand: StarTech.com
- MPN: SV431DPDDUA2
- Part #: KVMSTT4157163
- UPC:065030867863
Product URL: https://www.pbtech.co.nz/product/KVMSTT4157163/StarTechcom-SV431DPDDUA2-4-Port-Dual-DisplayPort-K?qr=popular_related_products
Branch | New Stock | On Display |
---|---|---|
Albany | 0 | |
Glenfield | 0 | |
Queen Street | 1 | |
Auckland Uni | 0 | |
Newmarket | 0 | |
Westgate | 1 | |
Penrose | 0 | |
Henderson (Express) | 0 | |
St Lukes | 0 | |
Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Head Office | 0 | |
Hornby | 0 | |
Christchurch Central | 0 |
Features
https://www.startech.com/en-nz/server-management/sv431dpddua2
This 4-port dual DP KVM switch combines dual 4K 60Hz displays with KVM switch control of four connected PC and Mac computers. It features audio and USB peripheral support along with dual-display capability, which makes it easy to create a multimedia workstation that can switch between two dual-head DP systems.
Maximize productivity with dual video
With two DP video inputs and control of four different computers, this Ultra HD KVM switch helps maximize productivity by giving you the freedom to multitask. Each of the DP ports supports resolutions up to 4K 60Hz, for maximum screen viewing space.
Astonishing picture quality
The dual DisplayPort KVM switch supports resolutions up to 4K at 60Hz, and can drive two large DP displays with ease. An ideal solution for creating workstations where high-quality imaging is critical, such as for graphic design.
Convenient multimedia and peripheral sharing
The KVM switch features full multimedia control with separate 3.5 mm microphone and speaker ports and two USB ports separate from the HID keyboard and mouse. The independent audio support lets you share independent analog audio from each of your connected computers, while the 2-port USB hub enables you to share USB peripherals between each connected computer.
The SV431DPDDUA2 is TAA compliant and backed by a 2-year StarTech.com warranty.
- Maximum productivity with dual-display, multi-computer access
- Full multimedia control with separate 3.5 mm microphone and speaker support
- Astonishing picture quality with support for Ultra HD 4K resolutions at 60Hz
- Share your USB peripheral devices with built-in 2-port USB hub
- Access computers easily with hotkey and push-button switching
Specifications
HARDWARE
Audio Yes
Cables Included No
Daisy-Chain No
KVM Ports 4
Number of Monitors Supported 2
PC Interface USB
PC Video Type DisplayPort
Rack-Mountable Yes
U Height 2U
PERFORMANCE
Aspect Ratio 16:9
Auto Scan 3, 8, 15 & 30 seconds
DVI Support No
Hot-Key Selection Yes
IP Control No
Maximum Data Transfer Rate 500 Mbps (USB 2.0)
Maximum Digital Resolutions 3840 x 2160 (Ultra HD 4K) @ 60hz
Maximum Number of Users 1
MTBF 142000 hours
On-Screen Display No
Port Selection Support Push Button and Hotkeys
Supported Resolutions 1024x768
1280x720 (High-definition 720p)
1920x1080 (High-definition 1080p)
1920x1200
2560x1600
3840 x 2160 (4K)@ 60hz
Wide Screen Supported Yes
CONNECTOR(S)
Console Interface(s) 2 - 3.5 mm Mini-Jack (3 Position) Female
2 - DisplayPort (20 pin) Female
2 - USB Type-A (4 pin) USB 2.0 Female
2 - USB Type-A (4 pin; HID Port) USB 1.1 Female
Host Connectors 2 - USB B (4 pin) Female
4 - DisplayPort (20 pin) Female
8 - 3.5 mm Mini-Jack (3 Position) Female
INDICATORS
LED Indicators 1 - Power
4 - Green - Online indicator (One LED per port)
4 - Red - Select indicator (One LED per port)
POWER
Center Tip Polarity Positive
Input Current 0.6 A
Input Voltage 100 - 240 AC
Output Current 1.5 A
Output Voltage 12 DC
Plug Type M
Power Consumption (In Watts) 18 W
Power Source AC Adapter Included
ENVIRONMENTAL
Humidity 0% - 80%
Operating Temperature 0? - 40?
Storage Temperature -10? - 60?
PHYSICAL CHARACTERISTICS
Color Black
Enclosure Type Steel
Product Height 2.5 in [6.3 cm]
Product Length 5 in [12.7 cm]
Product Width 8.5 in [21.6 cm]
Weight of Product 2.7 lb [1.2 kg]
PACKAGING INFORMATION
Package Height 3.4 in [87 mm]
Package Length 11.7 in [29.7 cm]
Package Width 9.6 in [24.3 cm]
Shipping (Package) Weight 3.9 lb [1.8 kg]
WHAT'S IN THE BOX
Included in Package 1 - KVM switch
1 - universal power adapter (NA/JP, EU, UK, ANZ)
1 - quick start guide
4 - rubber feet
