LevelOne IGP-0310 3-Port Industrial Gigabit POE Switch 802.3at PoE+ in and out 1x SFP

PB Tech price
PB Tech price
$ 144 .35
 +GST
$ 166 .00
 inc GST
$144.35  +GST
$166.00

LevelOne IGP-0310 3-Port Industrial Gigabit POE Switch 802.3at PoE+ in and out 1x SFP

  • Brand: LevelOne
  • MPN: IGP-0310
  • Part #: NETLEL1008
  • UPC:
PB Tech price
$ 144 .35 $ 166 .00
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 19 Sep When will I receive it?
$144.35  +GST
$166.00

Features

IGP-0310, 3-Port Industrial Gigabit PoE PSE/PD Switch,802.3at PoE, 30W

LevelOne IGP-0310 Industry Ethernet Switch provides 2 PoE ports 10/100/1000Base plus 1 port SFP to enable high speed network at mission-critical environment. With the industrial standard DIN-rail mount; this switch can be easily installed in the cabinet, plus the clearly visible status LEDs provide simple monitoring of port link activity. Moreover, the SFP slots support pluggable modules that enabling you to choose from a variety of transceivers. This switch is Power Sourcing Equipment (PSE), and it is fully complied with IEEE802.3af/at  PoE standard at maximum 30W. It helps to save infrastructure wiring costs dramatically by eliminating electric wiring and less UPS needed. Also, it is compatible with IEEE802.3 af/at standard PD devices.

- 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX
- Provides DIN-rail, wall or desktop mounting
- IP30 metal case
- 6KV surge protection level on each port
- ESD and surge protection

Specifications

General

Brand

LevelOne

Manufacturer Part Number

IGP-0310

Color

Black

Weight

0.35 kg

Dimensions (W x D x H)

101 x 65 x 36 mm

Port Configuration

Gigabit RJ45

2

Gigabit SFP

100/1000 Mbps

802.3af/at PoE

1

System specifications

Power supply

PoE

Data Rate

1Gbps

Power supply included

No

Power consumption

<5W

Standard

IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 10Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3z 1000Base-X Gigabit Ethernet
IEEE802.3x Flow Control and Back Pressure,
IEEE802.3af for POE
IEEE802.3at for POE+

Pin assignment and polarity

1/2 (+), 3/6 (-)

Mount

DIN rail mount

Indicators

Uplink 3: Green LEDs indicate Link/Act
Downlink 1~2: On RJ45 green LEDs indicate Link/Act
Yellow LEDs indicate PoE

Packet buffer

1M

Backplane (Gbps)

6

Miscellaneous

Grade

Industrial

PoE Supported

Yes

Manageable

No

Fanless

Yes

Concurrent ports

Total 3.00

PoE Power Budget

Total 30.00

Others

Approval and Compliance

CE/FCC

Operating humidity

10% RH ~ 90% RH

Operating temperature

-40°C ~ 75°C

Storage humidity

0% RH ~ 95% RH

Storage temperature

-40°C ~ 85°C

Package Contents

IGP-0310
Quick Installation Guide

Manufacturer Part No:
IGP-0310
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.5 kg
PB Part No:
NETLEL1008
Product Model:
-
Warranty: 12 months *
