StarTech.com 25SAT22MSAT Dual mSATA SSD to 2.5 SATA RAID Adapter Converter

PB Tech price
PB Tech price
$ 79 .13
 +GST
$ 91 .00
 inc GST

Out of stock

StarTech.com 25SAT22MSAT Dual mSATA SSD to 2.5 SATA RAID Adapter Converter

  • Brand: StarTech.com
  • MPN: 25SAT22MSAT
  • Part #: ADPSTT2634113
  • UPC: 065030855617
PB Tech price
$ 79 .13 $ 91 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock

Features

Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter. Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives. You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another. Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation. The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.


The StarTech.com Advantage


- Maximize system speed by adding SSD performance
- Achieve greater drive capacity, or secure data redundancy with multiple RAID modes
- Reduce overall power consumption, with high efficiency mSATA SSDs

Specifications

Hardware

Chipset ID
JMicron JMS562
Compatible Drive Types
mSATA (Mini SATA)
Drive Installation
Fixed
Drive Size
mSATA (Full Size & Half Size)
Interface
SATA
Number of Drives
2

Performance


Hot Swap Capability
No
Maximum Data Transfer Rate
6 Gbps
MTBF
5,101,299 Hours
Port Multiplier
Yes
RAID
Yes
Supported RAID Modes
BIG (Spanning or Concatenation)
JBOD - (Just a Bunch of Disks)
RAID 0 (Striped Disks)
RAID 1 (Mirrored Disks)
Type and Rate
SATA III (6 Gbps)

Connector(s)


Drive Connectors
2 - mSATA (52 pin, Mini SATA) Receptacle
Host Connectors
1 - SATA Data & Power Combo (7+15 pin) Receptacle

Software


OS Compatibility
OS independent; No software or drivers required

Indicators


LED Indicators
1 - Drive #1 Activity
1 - Drive #1 Failure
1 - Drive #2 Activity
1 - Drive #2 Failure

Environmental


Operating Temperature
-40°C to 85°C (-40°F to 185°F)

Physical Characteristics


Enclosure Type
Steel, Aluminum and Plastic
Product Height
0.3 in [7 mm]
Product Length
3.8 in [97 mm]
Product Weight
1.4 oz [39 g]
Product Width
2.8 in [70 mm]

Included in Package
1 - Dual mSATA to 2.5in SATA Adapter
1 - Mounting screw kit
1 - Install Guide
Manufacturer Part No:
25SAT22MSAT
Brand:
Product Type:
-
UPC
065030855617
Product Family:
-
Shipping Weight:
0.05 kg
PB Part No:
ADPSTT2634113
Product Model:
25SAT22MSAT
Warranty: 24 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
