StarTech.com ST10GSPEXNDP Dual Port 10G PCIe Network Adapter Card - Tehuti TN4010 10GBASE-T & NBASE-T PCI Express Network Interface Adapter 10/5/2.5/1GbE Multi Gigabit Ethernet 5 Speed NIC LAN Card
Out of stock
StarTech.com ST10GSPEXNDP Dual Port 10G PCIe Network Adapter Card - Tehuti TN4010 10GBASE-T & NBASE-T PCI Express Network Interface Adapter 10/5/2.5/1GbE Multi Gigabit Ethernet 5 Speed NIC LAN Card
- Brand: StarTech.com
- MPN: ST10GSPEXNDP
- Part #: ADPSTT4492106
- UPC: 065030880220
- Brand: StarTech.com
- MPN: ST10GSPEXNDP
- Part #: ADPSTT4492106
- UPC: 065030880220
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Network Cards (NIC)





StarTech.com ST10GSPEXNDP Dual Port 10G PCIe Network Adapter Card - Tehuti TN4010 10GBASE-T & NBASE-T PCI Express Network Interface Adapter 10/5/2.5/1GbE Multi Gigabit Ethernet 5 Speed NIC LAN Card
- Brand: StarTech.com
- MPN: ST10GSPEXNDP
- Part #: ADPSTT4492106
- UPC:065030880220

Product URL: https://www.pbtech.co.nz/product/ADPSTT4492106/StarTechcom-ST10GSPEXNDP-Dual-Port-10G-PCIe-Networ
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
This dual-port 10Gb PCIe network card offers a versatile and low-cost way to deploy 10GbE network connectivity. It adds two copper Ethernet ports to your server or desktop computer and provides Multi-Gigabit Ethernet access to your network at five speeds: 10G, 5G, 2.5G, 1G and 100Mbps.
Cost-Effective Multi-Gigabit Ethernet Solution
The 10GBASE-T NIC provides additional bandwidth using your existing Ethernet infrastructure to help reduce the cost of cabling upgrades. The card enables you to connect to 10GBASE-T and NBASE-T equipment at network speeds of:
- 100Mbps, 1Gbps, 2.5Gbps or 5Gbps over your CAT5e cabling (up to 100 m)
- 10Gbps over your CAT6 or better cabling (up to 100 m)
Optimal Technology for Optimal Performance
The network adapter card adds two Ethernet ports to your workstation through an x8 PCIe 2.X (or higher) slot. It features 10GBASE-T technology, supporting advanced Multi-Gigabit systems, including Cisco campus switches and Aruba Networks access points. The NIC card also supports additional features including 9K Jumbo Frames, Autonegotiation, Auto-MDIX and 802.1q VLAN tagging.
Energy Efficient Ethernet
The dual Tehuti TN4010 + Marvell 88X3110 chipset, compliant with IEEE 802.3az, ensures peak operation and reduced power consumption. The decreased consumption minimizes the heat generated to avoid operating temperatures increasing within your server case.
Applications
- Desktop Computers with an x8 PCIe 2.X (or higher) slot
- Workstation connections to Aruba Networks® access points and Cisco® Campus Switches
Specifications
Hardware
Bus Type
PCI Express
Card Type
Standard Profile (LP bracket incl.)
Chipset ID
Tehuti TN4010
Marvell 88X3110
Industry Standards
IEEE 802.3an (10GBASE-T)
IEEE 802.3ab (1000Base-T)
IEEE 802.3u (100BASE-T)
IEEE 802.3ad (Link Aggregation)
IEEE 802.1q (VLAN tagging)
PCI Express Rev 2.0
Interface
RJ45 (10 Gigabit Ethernet)
Ports
2
Performance
Auto MDIX
Yes
Compatible Networks
10 Gbps/5G/2.5G/1G/100 Mbps
Full Duplex Support
Yes
Jumbo Frame Support
9K max.
Maximum Data Transfer Rate
10 Gbps
Promiscuous Mode
Yes
PXE
No
Supported Protocols
IEEE 802.3ad (link aggregation)
IEEE 802.1q (VLAN tagging)
Connector
Connector Type(s)
1 - PCI Express x8 Male
External Ports
2 - RJ-45 Female
Software
OS Compatibility
Windows® 7, 8, 8.1, 10
Windows Server® 2008 R2, 2012, 2012 R2, 2016, 2019
Mac OS® 10.12 to 10.14
Linux 3.x to 4.14 LTS Versions only
VMWare® ESXi 5.0/5.1/6.0/6.5
Indicators
LED Indicators
2 - Link Speed
2 - Link/Activity
Enviromental
Humidity
20% ~ 80% RH
Operating Temperature
5°C to 50°C (41°F to 122°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Physical characteristics
Color
Black
Product Height
0.8 in [2 cm]
Product Length
4.8 in [12.1 cm]
Product Width
6.3 in [15.9 cm]
Weight of Product
13.8 oz [390 g]
