Adeunis Pulse V2 for LoRaWAN 863-870 MHz

PB Tech price
PB Tech price
$ 73 .91
 +GST
$ 85 .00
 inc GST
$73.91  +GST
$85.00

Adeunis Pulse V2 for LoRaWAN 863-870 MHz

  • Brand: Adeunis
  • MPN: ARF8230AA
  • Part #: ADU1014
  • UPC:
PB Tech price
$ 73 .91 $ 85 .00
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 22 Sep When will I receive it?
$73.91  +GST
$85.00

Features

The Adeunis LoRaWAN EU868 Pulse is a ready to use IoT radio transmitter that can be used to transform any type of meter into a wireless meter (smart meter). This product meets the needs of users who require to remotely monitor the consumption of different fluids (water, gas, electricity, heat ...) or any other phenomenon with an impulse interface (rain gauge, odometer ...). The use of the LoRaWAN 863-870 protocol allows the user to integrate the LoRaWAN 863-870 Pulse into any network that is already deployed. Two 3 wires-meters or one 5 wires-meters may be controlled by a single LoRaWAN 863-870 Pulse transmitter thus permitting a significant reduction in implementation and deployment costs. The Adeunis ARF8230AA emits the data from the meters periodically with or without history. It allows also the detection of tamper, and leakage, and the flow calculation with transmission possibilities on exceeding high or low thresholds. The configuration of the transmitter is accessible by the user via a micro-USB port or remotely via the LoRaWAN 863-870 network, allowing in particular a choice of modes of transmission, periodicity or triggering thresholds. The LoRaWAN 863-870 Pulse is powered by a non-replaceable internal battery.

- Pulse-based interface
- Up to 2 connectable meters
- Detection of tampers and leaks
- Flow rate monitoring
- Locally and remotely configurable
- Low power consumption for optimal autonomy

FEATURES OF THE PULSE IoT SENSOR

ALERT--And/or trigger an alarm when:
-
a fraud is detected
- the flow rate exceeds a threshold (high/low)
- a leak is detected.


MONITOR--Periodically report water, electricity and heat meter readings:
- index transmission
- flow monitoring (min/max)
Count the number of cycles of a piece of equipment and anticipate its maintenance.

Specifications

Product Code

ARF8230AA

Supply voltage

Nominal 3.6V

Power supply

Battery Li-SOCl2

Maximum Power

90mA

Working temperature

-25°C / +70°C

Dimensions

105 x 50 x 27mm

Casing

IP 67

LoRaWAN 863-870 zone

EU 863-870 MHz

Power transmission

14 dBm

Applicative port(downlink)

1

Manufacturer Part No:
ARF8230AA
Brand:
Adeunis
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
ADU1014
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
