StarTech.com 450FBLCLC4PP Fiber Optic Cable - 4m

OM4 - Multimode - LC-LC

PB Tech price
PB Tech price
$ 56 .52
 +GST
$ 65 .00
 inc GST
$56.52  +GST
$65.00

StarTech.com 450FBLCLC4PP Fiber Optic Cable - 4m

OM4 - Multimode - LC-LC

  • Brand: StarTech.com
  • MPN: 450FBLCLC4PP
  • Part #: CABSTT6070934
  • UPC: 65030900775
NEW ARRIVAL
PB Tech price
$ 56 .52 $ 65 .00
 +GST  inc GST


Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 18 Sep When will I receive it?
$56.52  +GST
$65.00
  • Brand: StarTech.com
  • MPN: 450FBLCLC4PP
  • Part #: CABSTT6070934
  • UPC: 65030900775

Cable Length

4m

Colour

Not Specified

Connector 1

Fibre Optic

Connector 2

Fibre Optic

Braided

N/A

HDMI Version

N/A

Similar in-stock products available at PB Tech right now

Features

10m (32.8ft) LC to LC (UPC) OM4 Multimode Fiber Optic Cable w/Push Pull Tabs, 50/125µm, 100G, Bend Insensitive, Low Insertion Loss - LSZH Fiber Jumper Cord

- PUSH-PULL OM4 CABLE: OM4 LOMMF Cable is immune to EMI and supports up to 100Gbps networks; Push-pull tab design provides quick access for precise insertion/removal in high-density installations; Retractable connector housings for toolless polarity swapping

- QUALITY CONSTRUCTION: LC/LC-UPC ends for improved return loss over PC polish; Bend Insensitive fiber core housed in Aramid-reinforced jacket for a loaded bend radius of 6cm and 3cm when unloaded

- SAFETY AND RELIABILITY: Individually tested for signal integrity; LSZH (Low-Smoke Zero-Halogen) jacket emits low toxic fumes if combusted; Safe for enclosed/poorly ventilated spaces; Attenuation below 2.4dB/km at 850nm meets or exceeds industry standards

- WIDE COMPATIBILITY: OM4 multimode cable supports 10/40/100G networks; Backward compatible with OM3; High micro-bending resistance facilitates tight bends in intricate environments, ideal for fiber switches/servers, SANs, and SFP+/QSFP+/QSFP28 modules

- SPECS: 4 meters (13.1ft); OM4; LC/LC UPC; Push Pull Tabs; 50/125µm; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: 4700MHz/km (850nm); Attenuation: =2.4dB/km (850nm), =0.6dB/km (1300nm); Cable OD: 2.9mm; Bend Radius: 6cm/2.4in (loaded), 3cm/1.2in (unloaded)

LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable enables 40/100G network connections. The push-pull tabs on each connector ensure quick connection and removal, facilitating accurate installation in high connection density environments. The bend-insensitive fiber and molded strain reliefs support cable runs requiring micro/macro bends while maintaining low attenuation. The retractable strain-relief housings enable toolless in-field polarity swapping. Color-coded LC-Duplex connectors ensure error-free polarity configuration.

Engineered for Optimal Performance

Precision-manufactured ceramic ferrules ensure accurate fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics. The Laser-Optimized Multi-Mode Fiber (LOMMF) OM4 fiber patch cable is ideal for 850nm and 1300nm Vertical-Cavity Surface-Emitting Laser (VCSEL) and LED sources.

Compatibility

This multimode 50/125µm fiber optic patch cord is backward compatible with OM3 and 1/10/40G networks, ensuring a reliable connection in legacy fiber environments.

LSZH Cable Jacket

Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.

Each OM4 fiber cable is also individually tested for insertion loss performance that meets or exceeds the TIA/EIA-568 industry standard, for guaranteed compatibility and 100% reliability.

Specifications

Connector(s)

Connector A

1 - Fiber Optic LC Duplex

Connector B

1 - Fiber Optic LC Duplex

Environmental

Humidity

0~90% RH

Operating Temperature

-20°C to 60°C (-4°F to 140°F)

Storage Temperature

-20°C to 60°C (-4°F to 140°F)

Hardware

Fire Rating

LSZH Rated (Low Smoke Zero Halogen)

Fiber Size

50/125

Fiber Classification

OM4

Packaging Information

Package Height

0.5 in [1.3 cm]

Package Length

7.9 in [20.0 cm]

Shipping (Package) Weight

1.6 oz [46.0 g]

Package Width

8.7 in [22.0 cm]

Package Quantity

1

Performance

Maximum Data Transfer Rate

100Gbps

Cable Rating

1Gbps / 10Gbps / 40Gbps / 100Gbps

Maximum Cable Length

13.1 ft [4 m]

Type

Multi Mode

Wavelength

850nm
1300nm

Physical Characteristics

Product Height

0.0 in [0.0 mm]

Product Length

13.1 ft [4.0 m]

Weight of Product

1.0 oz [29.0 g]

Product Width

0.5 in [1.2 cm]

Color

Aqua

Cable Length

13.1 ft [4 m]

What's in the Box

Included in Package

1 - 4m OM4 Multimode Fiber Optic Cable LC - LC

Manufacturer Part No:
450FBLCLC4PP
Brand:
Product Type:
Fiber Optic Cable
UPC
65030900775
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
CABSTT6070934
Product Model:
450FBLCLC4PP
