HIKVISION 301316077 Hik DS-2DF8C842IXS-AELW (T2) 4K (8MP) IR PTZ 42x Zoom +Wip.x
Out of stock
HIKVISION 301316077 Hik DS-2DF8C842IXS-AELW (T2) 4K (8MP) IR PTZ 42x Zoom +Wip.x
- Brand: HIKVISION
- MPN: 301316077
- Part #: CCTHIK301316077
- UPC:
- Brand: HIKVISION
- MPN: 301316077
- Part #: CCTHIK301316077
- UPC:
Features
8-inch 4K 42X DarkFighter IR Network Speed Dome
- 1/1.2" Progressive Scan CMOS
- High quality imaging with 8 MP resolution
- Excellent low-light performance with DarkFighter technology
- 42× optical zoom, 16× digital zoom
- Up to 500 m IR distance
- Capturing every point fast even in critical events
- Water and dust resistant (IP67)
- Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face.
- Support vehicle detection (license plate number,vehicle model, and vehicle color recognition)
- Person arming: supports real-time modeling and comparison, arms and tracks predefined persons
- Vehicle arming: supports vehicle detection and license plate recognition, arms and tracks predefined vehicles
Ultra-High Definition 4K Imaging with DarkFighter Technology
The 8-inch PTZ speed dome features a 1/1.2" progressive scan CMOS sensor, delivering exceptional 8 MP resolution and vibrant color imaging even under extremely low-light conditions, thanks to Hikvision's advanced DarkFighter technology.
Powerful 42x Optical Zoom and 500m Infrared Night Vision
With 42× optical and 16× digital zoom, this camera enables effective long-range identification and tracking. The EXIR-powered IR illuminator achieves up to 500 meters of night vision for expansive perimeter or city surveillance.
Industry-Leading PTZ Control with Robust Scheduling and Presets
Full 360° pan, high-speed tilt, up to 300 presets, 8 patrols, and advanced pattern scans are all supported. Operators can rapidly position and freeze views, benefiting from 3D positioning and proportional zoom-critical for demanding monitoring environments.
Next-Level AI Analytics: Face & Vehicle Recognition, Person/Vehicle Arming
The camera supports concurrent detection, tracking, and selection among up to 30 faces in motion, with best-shot output. Vehicle analytics include license plate, color, and model recognition, and the system enables real-time arm/tracking of predefined people and vehicles.
Advanced Network, Storage, and Security Features for Enterprise Applications
With up to 20 concurrent video streams, three video codecs, SVC, dual memory options (on-board microSD up to 256GB and NAS/ANR support), plus HTTPS and 802.1X, the model offers security and flexibility for large deployments.
All-Weather, Heavy-Duty Protection with Automated Wiper
A robust metal construction rated IP67, ±6kV lightning/surge protection, wide temp range (-40°C to 70°C), and auto rain-sensing wiper ensure uninterrupted operation even in harsh outdoor or industrial settings.
Specifications
Reviews
Delivery & Pick-up
Delivery Estimates
The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-4 working days.
Next Day Delivery
Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.
Same Day Delivery
Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security & Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
1 Hour Store Pick-up / Click & Collect
You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.
Overseas Shipments
PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Wired IP Cameras
EZVIZ H9c 5MP/3K Dual-Lens Outdoor Wireless PT Camera with...
Ubiquiti UniFi Protect UVC-G6-Bullet 8MP/4K Bullet PoE Camera ...
Reolink TrackMix PoE 8MP/4K Dual-Lens Outdoor PTZ PoE Camera with...
Reolink Duo 2 PoE 8MP/4K Dual-Lens Outdoor PoE Camera with...
Reolink P334 8MP/4K Outdoor Turret POE IP Camera Plug&play /...
HIKVISION 301316077 Hik DS-2DF8C842IXS-AELW (T2) 4K (8MP) IR PTZ 42x Zoom +Wip.x
- Brand: HIKVISION
- MPN: 301316077
- Part #: CCTHIK301316077
Product URL: https://www.pbtech.co.nz/product/CCTHIK301316077/HIKVISION-301316077-Hik-DS-2DF8C842IXS-AELW-T2-4K
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
8-inch 4K 42X DarkFighter IR Network Speed Dome
- 1/1.2" Progressive Scan CMOS
- High quality imaging with 8 MP resolution
- Excellent low-light performance with DarkFighter technology
- 42× optical zoom, 16× digital zoom
- Up to 500 m IR distance
- Capturing every point fast even in critical events
- Water and dust resistant (IP67)
- Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face.
- Support vehicle detection (license plate number,vehicle model, and vehicle color recognition)
- Person arming: supports real-time modeling and comparison, arms and tracks predefined persons
- Vehicle arming: supports vehicle detection and license plate recognition, arms and tracks predefined vehicles
Ultra-High Definition 4K Imaging with DarkFighter Technology
The 8-inch PTZ speed dome features a 1/1.2" progressive scan CMOS sensor, delivering exceptional 8 MP resolution and vibrant color imaging even under extremely low-light conditions, thanks to Hikvision's advanced DarkFighter technology.
Powerful 42x Optical Zoom and 500m Infrared Night Vision
With 42× optical and 16× digital zoom, this camera enables effective long-range identification and tracking. The EXIR-powered IR illuminator achieves up to 500 meters of night vision for expansive perimeter or city surveillance.
Industry-Leading PTZ Control with Robust Scheduling and Presets
Full 360° pan, high-speed tilt, up to 300 presets, 8 patrols, and advanced pattern scans are all supported. Operators can rapidly position and freeze views, benefiting from 3D positioning and proportional zoom-critical for demanding monitoring environments.
Next-Level AI Analytics: Face & Vehicle Recognition, Person/Vehicle Arming
The camera supports concurrent detection, tracking, and selection among up to 30 faces in motion, with best-shot output. Vehicle analytics include license plate, color, and model recognition, and the system enables real-time arm/tracking of predefined people and vehicles.
Advanced Network, Storage, and Security Features for Enterprise Applications
With up to 20 concurrent video streams, three video codecs, SVC, dual memory options (on-board microSD up to 256GB and NAS/ANR support), plus HTTPS and 802.1X, the model offers security and flexibility for large deployments.
All-Weather, Heavy-Duty Protection with Automated Wiper
A robust metal construction rated IP67, ±6kV lightning/surge protection, wide temp range (-40°C to 70°C), and auto rain-sensing wiper ensure uninterrupted operation even in harsh outdoor or industrial settings.
Specifications
Camera
Image Sensor
1/1.2＂ progressive scan CMOS
Min. Illumination
Color: 0.002 Lux @(F1.6, AGC ON),B/W: 0.0002 Lux @(F1.6, AGC ON),0 Lux with IR
Shutter Speed
1/1s~ 1/30,000s
Slow Shutter
yes
Focus
semi-auto;manual;auto
Day & Night
ICR
Day/Night Switch
day;night;auto;scheduled-switch
BLC
yes
WDR
120 dB WDR
HLC
yes
3D DNR
yes
Defog
yes
EIS
Yes. Built-in gyroscope to improve EIS performance.
Regional Exposure
yes
Regional Focus
yes
Image Settings
saturation;brightness;contrast;sharpness;not adjustable
White Balance
auto;ATW;sodium lamp;fluorescent lamp;indoor;outdoor;MWB
Digital Zoom
16x
Optical Zoom
42x
Privacy Mask
up to 24 masks;polygon region ;mosaic mask ;mask color configurable
DORI
Detect(25px/m)：4137.9m
Observe(63px/m)：1642m
Recognize(125px/m)：827.6m
Identify(250px/m)：413.8m
SNR
≥55dB
General Function
mirror;password protection;video tampering alarm;watermark;IP address filter
Optical Defog
yes
Lens
Focal Length
7.5mm to 315mm，42X Optical
Zoom Speed
approx. 7.5 s
FOV
Horizontal field of view: 60.4° to 1.7° (wide-tele),
Vertical field of view: 36.2° to 0.9° (wide-tele),
Diagonal field of view: 67.8° to 2.2° (wide-tele)
Aperture
F1.6
Illuminator
IR Distance
500m
Smart IR
yes
PTZ
Movement Range (Pan)
360°
Movement Range (Tilt)
-20° to 90° (auto flip)
Pan Speed
pan speed: configurable from 0.1° to 210°/s; preset speed: 280°/s
Tilt Speed
tilt speed: configurable from 0.1° to 150°/s, preset speed 250°/s
Proportional Zoom
yes
Presets
300
Patrol Scan
8 patrols, up to 32 presets for each patrol
Pattern Scan
4 pattern scans, record time over 10 minutes for each scan
Power-off Memory
yes
Park Action
preset;pattern scan;patrol scan;auto scan;tilt scan;random scan;frame scan;panorama scan
3D Positioning
yes
PTZ Status Display
yes
Preset Freezing
yes
Scheduled Task
preset;pattern scan;patrol scan;auto scan;tilt scan;random scan;frame scan;panorama scan;dome reboot;dome adjust;aux output
Video
Max. Resolution
3840 × 2160
Main Stream
50Hz:25fps(3840×2160, 2560×1440, 1920×1080,1280×960,1280×720);
60Hz:30fps(3840×2160, 2560×1440, 1920×1080,1280×960,1280×720)
Sub-Stream
50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 480, 352 × 240)
Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Compression
H.265;H.264;MJPEG
Video Bit Rate
32 Kbps ~ 16384 Kbps
H.264 Type
baseline profile;main profile;high profile
H.265 Type
main profile
H.264+
yes
H.265+
yes
SVC
yes
ROI
dynamic license plate tracking;dynamic face tracking;fixed region
Audio
Audio Compression
G.711alaw;G.711ulaw;G.722.1;G.726;MP2L2;PCM
Audio Bit rate
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 192 Kbps(MP2L2)
Smart Features
Face Capture
Support detecting up to 30 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face.
Face Comparison
yes
Road Traffic
Support vehicle detection (license plate number,vehicle model, and vehicle color recognition)
Basic Event
motion detection;video tampering alarm;alarm input and output;exception
Smart Event
Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Audio Exception Detection;vandal-proof alarm;unattended baggage detection;object removal detection
Smart Tracking
manual tracking;event tracking;support patrol tracking among multiple detection scenes;auto-tracking
Smart Record
ANR;Dual-VCA
Alarm Linkage
preset;patrol scan;pattern scan;memory card video recording;alarm output;sending email;notify surveillance center; upload to FTP;NAS video recording
Network
Network Storage
NAS (NFS, SMB/ CIFS)
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, UDP, IGMP, ICMP, Bonjour
API
Open-ended API, ONVIF (Profile S, Profile G), ISAPI, Hikvision SDK, Third-party management platform, ISUP
Simultaneous Live View
Up to 20 channels
User/Host
Up to 32 users. 3 levels: Administrator, Operator and User
Smooth Streaming
yes
Security Measures
Authenticated username and password;MAC address binding;IP address filter;802.1X authenticated access;HTTPS encryption
Client
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser
IE 10+, Chrome 57+, Firefox 52+, Safari 12+
Interface
Communication Interface
RJ45;Self-adaptive 10M/100M Ethernet port
On-board Storage
Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB; NAS (NFS, SMB/ CIFS), ANR
Alarm Input
7 alarm inputs
Alarm Output
2 alarm outputs
Audio Input
1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%
Audio Output
1 audio output, line level, impedance: 600 Ω
Video Output
1.0V[p-p]/75Ω;PAL;NTSC;BNC connector
RS-485
HIKVISION, Pelco-P, Pelco-D, self-adaptive
General
Power
24 VAC (Max. 60 W, including max. 15 W for IR and max. 8 W for heater), PoE 802.3 bt (Max. 51 W, including max. 15 W for IR and max. 8 W for heater)
Operating Conditions
Temperature: -40°C to 70°C (-40°F to 158°F)，Humidity: ≤ 95%
Wiper
Yes. Rain-sensing auto control
Material
ADC12
Dimensions
Φ 267 mm × 430 mm (Φ 10.51" × 16.93")
Weight
Approx. 9.6 kg (21.16 lb.)
Web Client Language
32 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Approval
Protection
Lightning Protection, Surge Protection and Voltage Transient Protection,±6kV Line to Gnd, ±3kV Line to Line,IEC61000-4-5;IP67 Standard
