Features
Milesight 5MP NDAA AI LPR 12X AF Motorized Pro Bullet Plus Network Camera
- ONVIF Profile G & Q & S & T, API Compatible
- Supports 802.3at PoE
- Supports H.265+/H.265/H.264+/H.264
- License Plate Recognition (LPR/ANPR)
- 12X AF Lens
- 90m Detection Distance
- 95% Accuracy �
- Up to 1000 records inside the camera
- IP67 & IK10
- AI LPR � 200km/h
- 90fps High Frame Rate
- vGRID SaferCity Platform Compliant
Evidence Camera Linkage
Beyond vehicle feature and license plate recognition, Milesight AI Road Traffic Camera can link with any regular cameras to capture the evidence. With seamless triggering between Milesight traffic camera and regular camera, users can easily provide solid and convincible evidence including LPR results as well as overview snapshots.
LPR Smart Search
Relevant videos can be found quickly by searching for only a portion of the target suspect vehicle's features, such as vehicle brand, type & color, plate color, plate number, direction and etc., ensuring efficient event investigations and intelligent road traffic monitoring. It also supports manual export and auto export for easy management.
Intelligent AI-powered LPR Algorithm
Based on AI algorithm, the LPR function provides value-added data via a pre-trained deep learning model and continuously training to algorithms automatically. Milesight AI Road Traffic Pro Bullet Plus Camera can not only recognize vehicle plates in real time, but also identify various vehicle features, like vehicle type, brand, color, etc., generating reliable traffic insights to improve safety and mobility.
12x Optical Zoom
The 12x Optical Zoom can zoom in to distant vehicles while still maintaining clarity, delivering high quality video over the entire image.
IP67 & IK10
Equipped with industry-leading IP67-rated weather-proofing and lK10-rated vandal-proofing, the camera is well protected against adverse impacts to ensure the robust performance.
SIP/VoIP Support
Milesight AI Camera features industry leading SIP/VoIP function and video streaming for mobile phones and video phones.
Specifications
Camera
Name
AI Road Traffic Pro Bullet Plus Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Min. Illumination
Color: 0.008Lux@ F1.6
B/W: 0Lux with IR on
WDR
120dB Super WDR
Shutter Time
1/100000s~1s
Day/Night Mode
Day/Night/Auto/Customize/Schedule
IR Wave Length
850nm (Default); 740nm (Optional)
Illumination Distance
Up to 180m
S/N
>55dB
Lens
Lens
5.3~64mm, 12x Optical Zoom
Field of View
H57°~H4°/D69°~D5°/V44°~V1°
Mount
F14
Focus Control
Auto/Manual
Aperture
F1.6~F2.8
Iris Control
Auto
Road Traffic Management
Max. Vehicle Speed
120km/h
Recognition Accuracy
>95%
Coverage
2 lanes
Country Region Supported
More than 80 countries and regions
ANPR Distance
Up to 150m during the day; Up to 80m during the night with illumination
Attributes Identification
Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand, No-plate Vehicle Capture, Vehicle Direction Detection
Smart Traffic Function
Evidence Camera Linkage, Specific Lane Management
White/Black List
Up to 20,000 records inside the camera
LPR Smart Search
Support
Interface
Ethernet
1*RJ45 10M/100M Ethernet Port
Audio I/O
1/1
Alarm I/O
1/1 (Integrated Cable Version) 2/2 (Cable Out Version)
Video
Max. Image Resolution
2592x1944
Primary Stream
60Hz: 30fps@ (2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576)
50Hz: 25fps@ (2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576)
Secondary Stream
60Hz: 30fps@ (704x576, 640x480, 640x360, 352x288, 320x240)
50Hz: 25fps@ (704x576, 640x480, 640x360, 352x288, 320x240)
Tertiary Stream
60Hz: 30fps@ (1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)
50Hz: 25fps@ (1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)
Video Compression
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Video Bit Rate
16Kbps~16Mbps(CBR/VBR Adjustable)
Privacy Masking
Up to 8 Areas (Mask Area and Mosaic Area are optional)
ROI
Up to 8 areas
Image Setting
Brightness/Contrast/Saturation/Sharpness
Network
Network Storage
NAS(Support NFS, SMB/CIFS), ANR
Protocol
IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP,UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2
Audio
Audio Compression
G.711/AAC/G.722/G.726
Audio Sampling Rate
8/16/32/44.1/48KHz
Audio Bit Rate
16~256kbps
Two-way Audio
Support
System
System Compatibility
API, HTTP, TCP, ONVIF Profile G & M & S & T
Storage
Support microSD/SDHC/SDXC Card Local Storage, up to 1TB
Advanced Function
BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP Support
Yes, Voice & Video-over-IP
Event Trigger
Black/White List, Attributes Event, Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.
Event Action
FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc
General
Working Temperature
-40°C~60°C
Working Humidity
5~90%(Non-condensing)
Power Supply
PoE (802.3at) / DC 12V±10%
Power Consumption
8W MAX
13W MAX (With IR on)
Weather Proof
Up to IP67-rated for Weather-resistant Performance
Housing
Vandal-proof IK10-rated Metal Housing
Surge Protection
4KV
Weight
1623g
Dimensions
320mm x 134mm x 171mm
Naming Convention
P - PoE Supported
C/E - AI Series
