Intel Xeon E3-1220 v6 3.0GHz Processor, 8MB Cache, LGA1151,

4Core/4Thread, 72W TDP

PB Tech price
PB Tech price
$ 382 .61
 +GST
$ 440 .00
 inc GST

Out of stock

Intel Xeon E3-1220 v6 3.0GHz Processor, 8MB Cache, LGA1151,

4Core/4Thread, 72W TDP

  • Brand: Intel
  • MPN: BX80677E31220V6
  • Part #: CPUITX31220V6
  • UPC: 735858328302
PB Tech price
$ 382 .61 $ 440 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock
  • Brand: Intel
  • MPN: BX80677E31220V6
  • Part #: CPUITX31220V6
  • UPC: 735858328302

CPU Family

Intel Xeon E3

CPU Socket

Intel LGA1151

Number of Cores

4

Base Clock Speed

3GHz

Turbo Boost Clock Speed

3.5GHz

Features

Entry Servers for Small Business Customers

No matter what the size of your business, the value of your data is enormous. Keep it accessible and better protected at all times with an affordable Intel Xeon processor E3-1200 v6 product family-based server. And on-premise server delivers a real solution for the needs of a small business demand.




Performance Increase Over Your Current Small Business/Entry Server

Improvements in processor speed, enhanced memory capabilities, hardware-enhanced security and reliability all with support and optimizations for the latest server operating systems and virtualization ISV applications with the Intel® Xeon® Processor E3-1200 V6 product family.




The Difference Professionals Demand in Computing Solutions

Hardware-enhanced security and reliability are foundational elements of professional computing and included in the Intel® Xeon® Processor E3-1200 V6 product family. Support for Error-Correcting Code (ECC) Memory in configurations up to 64GB of DDR4 2400 MHz, Intel® vPro™ technology, and additional security and reliability enhancements that are exclusive to the Intel® Xeon® processor product family and not available in consumer-grade solutions.

Specifications

Essentials

Vertical Segment

Server

Processor Number

E3-1220V6

Lithography

14 nm

Performance

# of Cores

4

# of Threads

4

Processor Base Frequency

3.00 GHz

Max Turbo Frequency

3.50 GHz

Cache

8 MB

Bus Speed

8 GT/s DMI3

TDP

72 W

VID Voltage Range

0.55V-1.52V

Supplemental Information

Embedded Options Available

No

Conflict Free

Yes

Memory Specifications

Max Memory Size (dependent on memory type)

64 GB

Memory Types

DDR4-2400, DDR3L-1866

Max # of Memory Channels

2

Max Memory Bandwidth

37.5 GB/s

ECC Memory Supported

Yes

Graphics Specifications

Processor Graphics

None

Graphics Output

N/A

4K Support

No

Max Resolution (HDMI 1.4)

N/A

Max Resolution (DP)

N/A

Max Resolution (eDP - Integrated Flat Panel)

N/A

Max Resolution (VGA)

N/A

DirectX* Support

N/A

OpenGL* Support

N/A

Intel® Quick Sync Video

No

Intel® InTru™ 3D Technology

No

Intel® Clear Video HD Technology

No

Intel® Clear Video Technology

No

# of Displays Supported

0

Expansion Options

Scalability

1S Only

PCI Express Revision

3.0

PCI Express Configurations

1x16, 2x8, 1x8+2x4

Max # of PCI Express Lanes

16

Package Specifications

Sockets Supported

FCLGA1151

Max CPU Configuration

1

Package Size

37.5mm x 37.5mm

Advanced Technologies

Intel® Optane™ Memory Supported

Yes

Intel® Turbo Boost Technology

2.0

Intel® vPro™ Technology

Yes

Intel® Hyper-Threading Technology

No

Intel® Virtualization Technology (VT-x)

Yes

Intel® Virtualization Technology for Directed I/O (VT-d)

Yes

Intel® VT-x with Extended Page Tables (EPT)

Yes

Intel® TSX-NI

Yes

Intel® 64

Yes

Instruction Set

64-bit

Instruction Set Extensions

SSE4.1/4.2, AVX 2.0

Idle States

Yes

Enhanced Intel SpeedStep® Technology

Yes

Thermal Monitoring Technologies

Yes

Intel® Data Protection Technology

Intel® AES New Instructions

Yes

Secure Key

Yes

Intel® Software Guard Extensions (Intel® SGX)

Yes

Intel® Memory Protection Extensions (Intel® MPX)

Yes

Intel® Platform Protection Technology

OS Guard

Yes

Trusted Execution Technology

Yes

Execute Disable Bit

Yes

Intel® Device Protection Technology with Boot Guard

Yes

Manufacturer Part No:
BX80677E31220V6
Brand:
Product Type:
-
UPC
735858328302
Product Family:
Xeon
Shipping Weight:
0.373 kg
PB Part No:
CPUITX31220V6
Product Model:
E3-1220 v6
