Vestel PDU98SF81B-4 98" Professional UHD Display

PB Tech price
PB Tech price
$ 12,418 .26
 +GST
$ 14,281 .00
 inc GST

Out of stock

Vestel PDU98SF81B-4 98" Professional UHD Display

  • Brand: Vestel
  • MPN: PDU98SF81B-4
  • Part #: DGSVTL1002
  • UPC:
PB Tech price
$ 12,418 .26 $ 14,281 .00
 +GST  inc GST

No store stock available. See in-stock alternatives

Click & Collect: Click & Collect unavailable
  • Brand: Vestel
  • MPN: PDU98SF81B-4
  • Part #: DGSVTL1002
  • UPC:

DisplayPorts

1

HDMI Ports

4

Refresh Rate

60hz

Screen Size

98 inches

Smart

Not Specified

USB Ports

2

VESA Size

900 x 600

Screen Resolution

3840x2160

Similar in-stock products available at PB Tech right now

Features

98" Vestel PDU98SF81B/4 UHD Signage Display

Vestel PDU98SF81B/4 98" UHD Signage Display is a large display designed to deliver maximum impact at crystal clear UHD resolution.

Signal Failover
Our displays have a protection for "No Signal". If the source is disconnected, the display will either show your customized banner or search for any other signal from video sources. Since blank screen is the worst case scenario for advertisement, failover is one of the critical feature in our signage displays.

Display Control
Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time.

Scheduler
The built in scheduler is one of the many important included features. The scheduler allows you to plan daily routines of when the display is powered on or off, along with selection of different sources or USB playlists.

Pixel Shifting
The Pixel Shifting feature can be activated in order to reduce the potential risk of image sticking when static content is displayed over long periods of time. The feature periodically shifts the image on the display, without causing any interference of the visual experience.

External Device Connections
You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.

Usb Security
This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention.

Usb Auto-Play
You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.

OPS Support
All our products in this series have compliance with OPS (Open Pluggable Standard). OPS will empower your screens with enhanced processing power and ability to choose Windows or Android as your operating system to fit your specific application.

Subtle Design
This series' displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, OPS-slot, detachable power plug, carrying handles and IR extender.

SoC Content Management
With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems.

Open Platform Support
Our SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on our displays.

Daisy Chain
The display can mirror the content (to another display) into its display port out coming from its display port in. This set up creates a daisy chain like structure allowing for monitors to be set up as Video Wall mode.

Specifications

Panel

Screen Size

98"

Panel Technology

SVA

Backlight Type

ELED

Brightness (typical)

500 cd/m²

Native Resolution

UHD: 3840 x 2160 - HDR10

Contrast Ratio (typical)

4000:1

Dynamic Constrast Ratio

50000:1

Panel Life Time ( Min. )

50000 Hrs

Response Time (typical)

6ms

Active Area (H x V)

2158 x 1214 mm

Pixel Pitch (H x V)

0.5621 x 0.5621 mm

PPI (pixel per inch)

45

Viewing Angle

178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10

Color Value

16.7 M (8-bit)

Screen Treatment

2H

Haze Level

25%

Refresh Rate

60 Hz

Front Type

SNB

Orientation

Horizontal / Vertical

Operation Hours

24/7

Area of Usage

Indoor

Mainboard

Mainboard Model

17MB135VS

Monitor Connectivity

RGB Input

VGA(DE-15F)

RGB Output

N/A

Video Input

4xHDMI2.0, 1xDP1.2a, 2xUSB2.0, USB2.0(Internal)

Video Output

HDMI2.0, DP1.2a

Audio Input

Line In L/R

Audio Output

Headphone, Optic SPDIF

External Control

RS232(DE-9F), Ethernet(RJ45), Service(RJ12)

External Sensor

RJ12

Mechanical

Product Dimensions (WxDxH)

2236 x 98 x 1292 mm

Package Dimensions (WxDxH)

2423 x 380 x 1563 mm

Product Weight

102.3 kg

Package Weight

126.7 kg

Vesa Mounting

900 x 600 mm

Bezel Width

B:39 | T:39 | L/R:39 mm

Environmental Conditions

Operating Temperature

0-40°C

Operating Humidity

10-90%

Power

Power Supply

110 VAC - 240 VAC - 50/60 Hz

Power Consumption

Typical

498 W

Deep Standby

= 0.5 W

Manufacturer Part No:
PDU98SF81B-4
Brand:
Vestel
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1.01 kg
PB Part No:
DGSVTL1002
Product Model:
PDU98SF81B-4
Warranty: 12 months *
