Panasonic DP-UB150GN-K 4K Ultra HD Blu-Ray Player with Dolby Vision & Multi HDR Support

Please note this Blu-Ray Player is designed to play Region B Blu-Rays only.

PLAYABLE DISCS

BD-ROM

Ultra HD Blu-ray/ FULL HD 3D/ BD-Video: yes

BD-RE/ BD-RE DL (Ver.3)

BDAV/ BDMV/ JPEG/ MPO: yes
MKV(H.264/ HEVC)/ MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2): yes
FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3: yes

BD-R (Ver.1.3) / BD-R DL (Ver.2)

BDAV/ BDMV/ MKV/ JPEG/ MPO: yes
MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2): yes
FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3: yes

DVD

DVD-Video: yes

DVD-R*1/ DVD-R DL*1/ DVD-RW*1

DVD-Video/ DVD Video Recording: yes
AVCHD/ MKV(H.264/ HEVC): yes/ yes* (*DVD-R/ DVD-R DL)
MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2): yes (DVD-R/ DVD-R DL)
FLAC/ WAV/ ALAC/ AIFF/ DSD/ WMA/ AAC/ MP3: yes (DVD-R/ DVD-R DL)
JPEG/ MPO: yes (DVD-R/ DVD-R DL)

+R*1/ +R DL*1/ +RW*1

Video/ AVCHD: yes

CD, CD-R/ -RW

CD-DA/ DTS-CD: yes
MKV(H.264/ HEVC): yes (CD-R/ -RW)
MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC), PS(MPEG-2): yes (CD-R/ -RW)
FLAC/ WAV/ ALAC/ AIFF/ WMA/ AAC/ MP3: yes (CD-R/ -RW)
JPEG/ MPO: yes (CD-R/ -RW)

AUDIO SYSTEM

Dolby Audio (Dolby Digital/ Dolby Digital Plus/ Dolby TrueHD)

yes (Decode and Bitstream Output*²)

DTS-HD Master Audio/ DTS-HD High Resolution Audio

yes (Decode and Bitstream Output*²)

Dolby Atoms/ DTS:X

yes (Bitstream Output*²)

FLAC

yes (Max. 192 kHz/ 24 bit)

WAV

yes (Max. 384 kHz/ 32 bit)

ALAC

yes (Max. 192 kHz/ 32 bit (2ch))

DSD (DFF, DSF)

yes (2.8 MHz (2ch/ 5.1ch), 5.6 MHz (2ch/ 5.1ch), 11.2 MHz (2ch))

AIFF

yes (Max. 384 kHz/ 32 bit (2ch))

USB

Slot

yes (1)

Front

1 (USB 2.0 High Speed)

Playback

FLAC/ WAV/ ALAC/ AIFF/ DSD (DFF, DSF)/ WMA/ AAC/ MP3: yes
MKV(H.264/ HEVC)/ MP4 (H.264/ HEVC), TS (MPEG-2 /H.264/ HEVC): yes
PS (MPEG-2) / AVCHD/ AVCHD 3D: yes
JPEG/ MPO: yes

HIGH QUALITY PICTURE

4K Networking (4K Video*6 Playback/ 4K JPEG Playback*4)

yes

Deep Colour

yes

x.v.Colour

yes*?

HDR

HDR: yes
HDR10+: yes
Hybrid Log Gamma(HLG): yes
4K Up-scaling 60p/50p/ 4:4:4 (HDMI2.0): yes*4*5
24p/ 25p: yes*4*5

SMART FEATURE

Remote Control

yes (Simple)

HDAVI Control 5 (VIERA Link) / HDMI CEC

yes (HDMI CEC only)

External HDD Playback

yes*¹4

BD-Live™

yes*¹5

TERMINAL

HDMI Output

yes (1)

LAN (Ethernet) Terminal

yes (for Ultra HD Blu-ray, BD-Live™*¹5 and Firmware Update)

OTHERS

Video System

PAL/ NTSC

Power Supply

AC 220-240 V, 50 Hz

Power Consumption

Normal Use 12 W
Standby (Quick Start Off)-Network Standby Off 0.3 W

DIMENSIONS, WEIGHT

Dimensions (W x H x D)

320 x 46 x 193 mm *¹7

Weight

1.2 kg

NOTIFICATION

NOTE

*1 Discs recorded and finalized on recording devices.
*2 HDMI connections and compatible equipment (e.g. AV Receiver) required.
*3 Enabled by software update
*4 For 4K Up-scaling playback a TV with same resolution is required.
*5 For 4K/60p video, a high speed HDMI cable supporting 18 Gbps bandwidth is required.
*6 MP4(4K/25p,30p) bit rate up to 100 Mbps/resolution up to 3840x2160.
*7 Some network content services may not be available in your country.
*8 Ultra HD Blu-ray and Photo (JPG/ MPO) are not supported.
*9 This function is effective only when reproducing AVCHD data recorded with x.v.Color technology. The function cannot be used with BD-ROM or DVD-ROM discs. HDMI connection is required.
*10 File formats that are not supported by your Network Contents server (DLNA compatible server, etc.) cannot be played.
*11 CD sampling is done at 176.4/88.2 kHz.
*12 A device that supports the Mirroring function and Android™ ver. 4.2 or higher is required.
*13 Requires broadband Internet service.
*14 The external HDD with capacities of 4TB or less in processing NTFS/ FAT32 data is supported. Playback is not possible with some external hard disk drives.
*15 To enjoy content, you will need to insert a USB (1GB or more of free space/ sold separately). Requires broadband Internet service.
*16 The analog 2-channel output terminal can also be used as an analog 7.1-channel output terminal.
*17 Excluding the projecting parts.
Specifications are subject to change without notice. All numbers given here are approximate.
WARNING The recording and playback of content on this or any other device may require permission from the owner of the copyright or other such rights in that content. Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. It is your responsibility to ensure that your use of this or any other device complies with applicable copyright legislation in your country. Please refer to that legislation for more information on the relevant laws and regulations involved or contact the owner of the rights in the content you wish to record or playback.
Playability may vary depending on the contents, discs and quality of the recording. For content recorded for your personal use.
Specifications are subject to change without notice.
TRADEMARK NOTICE Blu-ray Disc™, Blu-ray™, Ultra HD Blu-ray™ and the logos are trademarks of Blu-ray Disc Association.
"AVCHD" and the "AVCHD" logo are trademarks of Panasonic Corporation and Sony Corporation.
HDR10+™ logo is a trademark of HDR10+ Technologies, LLC.
MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.
Dolby, Dolby Audio, Dolby Vision, and the double-D symbol are trademarks of Dolby Laboratories.
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, DTS-HD, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS-HD Master Audio is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.
DLNA, the DLNA Logo and DLNA CERTIFIED are trademarks, service marks, or certification marks of the Digital Living Network Alliance.
Android is a trademark of Google LLC.
THX and the THX logo are trademarks of THX Ltd., registered in the United States and other countries.
