Supermicro SNK-P0046A4 Heatsink for LGA1150 / LGA1155, 32dBA, 2U / Ped, UP

Supermicro SNK-P0046A4 Heatsink for LGA1150 / LGA1155, 32dBA, 2U / Ped, UP

  • Brand: Supermicro
  • MPN: SNK-P0046A4
  • Part #: FANSPM0046
  • UPC:672042052134
  • Fan Size:N/A
  • LED Colour:N/A
  • Bearing Type Variation:N/A
  • Sound Level (Roughly):32dB
  • Number of Fans:1
PB Tech price:PB Tech price:
$3400$3910
 +GST  inc GST

Store Pickup: Select your store to check availability
Delivery: Order now and it ships today
When will I receive it?
Add To Compare

Four easy payments of $10.07 per fortnight*

Oxipay lets you spread the cost of your purchase over 4 fortnightly payments.

Click the button below or select Oxipay as your payment method during the checkout process.

If you do not have an Oxipay account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Oxipay

Features

This CPU fan heat sink is designed for Supermicro X9 and X10 generations 2U and above UP servers and workstations equipped with Intel Xeon E3-1200 series processors. The heat sink has been fully tested and validated by Supermicro to ensure the best quality and cooling performance.

Specifications

SERVER FORM FACTOR

2U

COOLING TYPE

Active

CPU CONFIGURATION

Uni Processor

SUPPORTED CPU SKU

Intel® Xeon® Processor E3-1200, E3-1200 v2, E3-1200 v3, E3-1200 v4, and E3-1200 v5 Series

SUPPORTED CPU SOCKET

FCLGA1150, FCLGA1155

SUPPORTED CPU TDP

Up to 95 Watts

ATTACHED COOLING FAN

Speed Control:

4-pin PWM

Rated Voltage:

12.0 VDC

Rated Speed:

2,800 RPM

Acoustic Noise:

33.5 dB(A) at Rated Speed

Dimensions:

94L x 94H x 25.2W (mm)

Position:

Top Side

MTBF/MTTF:

150,065 Hours

WARRANTY

1 year warranty

PRODUCT ENVIRONMENTAL COMPLIANCE

RoHS and REACH compliant, details available upon request

Manufacturer Part No: SNK-P0046A4 Brand: Supermicro Product Type: -
UPC 672042052134 Product Family: - Shipping Weight: 0.85 kg
PB Part No: FANSPM0046 Product Model: SNK-P0046A4

Warranty: 12 months local warranty *
