Advantech ARK-1551-S6A1 I5-8365UE 4COM 2GBE FANLESS
Advantech ARK-1551-S6A1 I5-8365UE 4COM 2GBE FANLESS
- Brand: Advantech
- MPN: ARK-1551-S6A1
- Part #: IPCAVH020002
- UPC:
- Brand: Advantech
- MPN: ARK-1551-S6A1
- Part #: IPCAVH020002
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Computers





Advantech ARK-1551-S6A1 I5-8365UE 4COM 2GBE FANLESS
- Brand: Advantech
- MPN: ARK-1551-S6A1
- Part #: IPCAVH020002

Product URL: https://www.pbtech.co.nz/product/IPCAVH020002/Advantech-ARK-1551-S6A1-I5-8365UE-4COM-2GBE-FANLES
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 1 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
Intel® 8th Generation Core™ i5/Celeron Slim Fanless Computer
- Gen 8th Intel® Core™ i5/Celeron
- Dual DDR4 2400MHz SO-DIMM memory up to 32G
- 1 x swappable 2.5" SATA HDD drive bay and 1 x mSATA slot, supports Intel software RAID 0/1
- 4 x USB 3.1 Gen 2, 2 x Intel GbE LAN, 4 x RS-232/422/485, 8 bit GPIO
- 4K2K HDMI and VGA dual independent displays
- 1 x full-size mPCIe with SIM holder and 1 x M.2 2230 E Key
- Support Advantech SQF PCIex2 NVMe storage
- 12V - 24V @ -10%/+20% wide range power input
- RED for WiFi/BT/LTE are available
Specifications
CPU
Intel® Core™ i5-8365UE
Core Number
4
Frequency
1.6 GHz, turbo burst up to 4.1 GHz
BIOS
AMI EFI 256 Mbit
Technology
DDR4 2400MHz SO-DIMM
Max. Capacity
32 GB
Socket
2 x 260 pin SO-DIMM
ECC Support
No
Chipset
Intel UHD Graphics 620
Graphic Engine
Gen9 Low Power; 24 (UHD 620) /12(UHD 610) Execution Units. Media Codec Supported: H.264, MPEG2, MVC, VC-1, WMV9, H.265 / HEVC. 3D HW Acceleration: OpenGL 4.5, DirectX* 11.3/12, OpenCL* 2.1
HDMI
1
Dual Display
Yes, VGA + HDMI
Main System
Realtek ALC888S, High Definition Audio, Line-out, Mic-in
Controller
2
LAN1
10/100/1000 Mbps Intel i210 GbE, support Wake On Lan
LAN2
10/100/1000 Mbps Intel i219GbE, support Wake On LAN
Serial Port
4 x RS-232/422/485 support from 50 bps to 921.6 kbps, with auto flow control. COM3 with 5V/12V power, by jumper setting
Serial
4
USB Interface
4 x USB 3.1 Gen2, Type A connector
USB3.0
4
GPIO
8-bit
Mini PCI Express
1
Mini PCIe #1
1 x full-size mPCIe with 1x nano SIM holder (PCIe x2, USB 2.0x1, UIM, SATA x1)
M.2
1
Watchdog timer
255 levels timer interval, setup by software
TPM
Infineon SLB9665XQ 2.0
Case Open
Support
mSATA
1 x Full-size mSATA (*share with mPCIe slot)
PCIe
Support 2x Advantech SQF PCIex2 NVMe storage (1 x M.2 2230 E Key + 1 x mPCIe)
2.5" HDD/SSD
1 x Swappable 2.5" SATAIII drive bay (compatible with 7mm height
Microsoft Windows
Windows 10
Ubuntu
V
Power Type
AT/ATX
Input Voltage
12 ~ 24 VDC
Power Adaptor
AC to DC, 90W for 0 ~ 40 °C/ AC to DC, 120W for condition -20 ~ 55 °C (Optional)
Power Consumption
Typical 13.87 W, Max 47.12W
