Advantech AI computer MIC-710AILX NVIDIA Jetson NANO Lite AI Inference System XAV NX No storage included. Please use wide temp peripherals to achieve full wide temp. Power adapter sold separately.
Advantech AI computer MIC-710AILX NVIDIA Jetson NANO Lite AI Inference System XAV NX No storage included. Please use wide temp peripherals to achieve full wide temp. Power adapter sold separately.
- Brand: Advantech
- MPN: MIC-710AILX-00B1
- Part #: IPCAVH080002
- UPC:
- Brand: Advantech
- MPN: MIC-710AILX-00B1
- Part #: IPCAVH080002
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Industrial Automation & I/O





Advantech AI computer MIC-710AILX NVIDIA Jetson NANO Lite AI Inference System XAV NX No storage included. Please use wide temp peripherals to achieve full wide temp. Power adapter sold separately.
- Brand: Advantech
- MPN: MIC-710AILX-00B1
- Part #: IPCAVH080002

Product URL: https://www.pbtech.co.nz/product/IPCAVH080002/Advantech-AI-computer-MIC-710AILX-NVIDIA-Jetson-NA
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | - | |
Auckland - Glenfield | - | |
Auckland - Queen Street | - | |
Auckland - Auckland Uni | - | |
Auckland - Newmarket | - | |
Auckland - Westgate | - | |
Auckland - Penrose | - | |
Auckland - Henderson (Express) | - | |
Auckland - St Lukes | - | |
Auckland - Manukau | - | |
Hamilton | - | |
Tauranga | - | |
New Plymouth | - | |
Palmerston North | - | |
Petone | - | |
Wellington | - | |
Auckland - Head Office | - | |
Auckland - East Tamaki Warehouse | - | |
Christchurch - Hornby | - | |
Christchurch - Christchurch Central | - | |
Dunedin | - |
Features
- NVIDIA® Jetson™ Xavier NX embedded
- 2 x embedded LAN port
- Linux OS with board support package (BSP)
- Supports deep learning trained models
- Wide operating temperature range
- Support 24/7 secure remote monitoring, control, and OTA deployment empowered by Allxon
- Support wireless without RED Certification
Specifications
Processor System
Carmel CPU
ARMv8.2 (64-bit) heterogeneous multi-processing (HMP) CPU architecture | 3 x dual-core CPU clusters
(six NVIDIA Carmel processor cores) (Max. Operating Frequency: 1.9 GHz)
Volta GPU
384 CUDA Core, 48 Tensor Cores, Performance up to 21 TOPS (INT8)
Max. operating frequency: 1100 MHz
Memory
8 GB 128-bit LPDDR4x DRAM
Flash
16G of eMMC
Ethernet
Interface
RJ-45
Controller
Intel® i210IT
Speed
2 x Gigabit Ethernet (10/100/1000 Mbps)
I/O
Display
HDMI (Max. resolution 3840 x 2160 @ 60Hz)
USB
External
1 x USB 2.0
1 x USB 3.0
Internal
1 x USB 2.0
OTG USB (Internal)
1 x Micro USB
DI/DO
4bit in, 4bit out
COM
1 x RS-232/RS-422/RS-485
Expansion
MiniPCIe (iDoor)
1 x MiniPCIe
Storage
M.2 SATA
1 x M.2 2280 (M Key)
SD Card
1 x Micro SD
Power
Power Supply
Power adaptor: 19-24V (1.5A-1.18A)
Power Type
Terminal block 2 Pin
Environment
Operational Temperature
-10 ~ 60 °C with 0.7 m/s air flow (Max-P ARM mode)
Operating Humidity
95% @ 40 °C (non-condensing)
Vibration
3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis
Mechanical
Dimensions (W x D x H)
147 x 118 x 52mm (5.7 x 4.6 x 2.0")
Weight
1.2 kg (3.5 lb)
Installation
Desktop/DIN RAIL
Operating System
Linux
Ubuntu 18.04 with JetPack
Certifications
CE/FCC/BSMI/CCC (No RED certification)
