Features
EKI-5626CI-PN is new generation of entry-level managed switch products. They support media redundancy protocols and meet the PROFINET real time standard. The devices come with a compact metal housing that is IP30 rated to protect against dusty industrial environments. The wide power input power (8.4 to 52.8 VDC) is dedicated to operating in areas of unstable power and rugged environments.
- 8 Fast Ethernet ports + 2 Gigabit Copper/SFP combo ports
- Entry-Level Managed Switch
- IXM function enables fast deployment
- Provides GSDML files
- Management: SNMP v1/v2c/v3, WEB, Standard MIB, Private MIB
- Supports Media Redundancy Protocol (MRP Clients)
Specifications
MPN
EKI-5626CI-PN-AE
16 + 2G Combo ports entry-level managed switch support PROFINET w/wide temp.
Communications
Standard
IEEE 802.3, 802.3u, 802.3x, 802.1D, 802.1w, 02.1p, 802.1Q, 802.1X, 802.3AD,802.3az
LAN
10/100Base-T (X),
Transmission Distance
Ethernet: UP to 100m (4-wire Cat.5e, Cat.6
RJ-45 cable suggested for Gigabit port)
SFP: UP to 110km (depends on SFP)
Transmission Speed Ethernet
Ethernet: 10/100Mbps Auto-Negotiation
Gigabit Copper: 10/100/1000Mbps,
Auto-Negotiation
Gigabit Fiber: UP to 1000Mbps
Interface
I/O Port
EKI-5626C/I-PN: 16 x RJ-45 + 2 x RJ-45/SFP combo ports
Power Connector
6-pin screw Terminal Block (including relay)
Physical
Enclosure
Metal Shell
Protection Class
IP 30
Installation
DIN-Rail
Dimensions (W x H x D)
74 x 120 x 84 mm
LED Display
System LED
PWR1, PWR2, P-Fail, Loop/Status
Port LED
Link / Speed / Activity
Environment
Operating Temperature
-40 ~ 75°C (-40 ~ 167°F)
Storage Temperature
-40 ~ 85°C
Ambient Relative Humidity
10 ~ 95% (non-condensing)
Humidity
10 ~ 95% (non-condensing)
MTBF
EKI-5626C/I-PN: 2,825,281 hours
Power
Power Consumption
EKI-5626C/I-PN: Max 8.2W
Power Input
12 ~ 48 VDC (8.4~52.8 VDC), redundant dual power input
Fault Output
1 Relay Output
Certification
EMI
CE, FCC Class A
Safety
UL508, Class 1 Division 2, ATEX
EMC
EN 61000-4-2; EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-8
Shock
IEC 60068-2-27
Freefall
IEC 60068-2-32
Vibration
IEC 60068-2-6
L2 Features
L2 MAC Address
8K
Jumbo Frame
9216 Bytes
VLAN Group
256 (VLAN ID 1~4094)
VLAN Arrange
Port based VLAN, GVRP
Port Mirroring
Per port, Multi-source port,
IP Multicast
IGMP Snooping v1/v2/v3, MLD
Snooping, IGMP Immediate leave
Storm Control
Broadcast, Multicast, Unknown unicast
Redundancy
IEEE 802.1D-STP, IEEE 802.1s-MSTP, IEEE 802.1w-RSTP,
X-Ring, with ultra high-speed recovery time less than 20ms
QoS
Priority Queue Scheduling
WRR (Weighted Round Robin), SP (Strict Scheduling Priority) Hybrid Priority
Class of Service
IEEE 802.1p Based CoS, IP TOS, DSCP based CoS
Rate Limiting
Ingress Rate limit, Egress Rate limit
Link Aggregation
IEEE 802.3ad Dynamic Port Trunking, Static Port Trunking
Security
Port Security
Static, Dynamic, MAC address filtering
Authentication
802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption)
Management
Access
SNMP v1/v2c/v3, WEB, Standard MIB, Private MIB
Software upgrade
TFTP, HTTP, Dual Image
NTP
SNTP client
Data
Syslo
Protocols
IPV6, LLDP, PROFINET, Media Redundancy Protocol
