Winmate 10.1" Panel PC Intel N4200 2.5GHz 4GB RAM,128GB SSD, Windows 10 IoT, IP65, 1xM12 for Power with Ignition, 1x M12 for LAN/ USB, 1x M12 for CAN Bus (2ch, use USB to CAN converter) Wide power input (9-36V DC) GPS

PB Tech price
PB Tech price
$ 2,770 .58
 +GST
$ 3,186 .17
 inc GST

Out of stock

Winmate 10.1" Panel PC Intel N4200 2.5GHz 4GB RAM,128GB SSD, Windows 10 IoT, IP65, 1xM12 for Power with Ignition, 1x M12 for LAN/ USB, 1x M12 for CAN Bus (2ch, use USB to CAN converter) Wide power input (9-36V DC) GPS

  • Brand: Winmate
  • MPN: W10IP3S-GSH2-PB
  • Part #: IPCWMAW10IP3S
  • UPC:
PB Tech price
$ 2,770 .58 $ 3,186 .17
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?

Features

Easy-to-Clean Flat Surface

Winmate's Flat aluminum display goes beyond that of the standard industrial panel computers with its elegant, edge-to-edge design. The Panel PC is easy to clean, plus the screen is resistant to water and liquid droplets.

Dust and Water Protection

The dust and waterproof Panel PC complies with IP65 standards. Plus, the M12 connectors are waterproof for varying industrial environments.

Fanless Cooling System

The fanless design eliminates dust circulation for improved product longevity - especially in heavy-duty applications where dusty conditions are prevalent.

Comprehensive I/O Ports

Combining ruggedness with a range of I/O ports makes this device highly usable for heavy-duty industrial applications. Plus, the waterproof connectors come with screw-on caps for added protection.

Anti-Shock and Vibration

The G-Win series is as tough as it gets. The Panel PCs are compliant with MIL-STD-810G, and the aluminum die-casting is rock solid. Plus, optical bonding technology with anti-moisture treatment and resistive coating ensure the screen and housing are both rugged to the max.

- 10.1" 1280 x 800 Resolution with Projected Capacitive Multi-Touch (P-CAP)
- Intel® Celeron® Bay Trail-M N2930 1.83 GHz
- Fanless cooling system and ultra-low power consumption
- Edge-to-edge design
- Full IP65 design with Special M12 Waterproof connectors
- 1 x LAN,1 x RS232,1 x USB 2.0

Specifications

Display

Size

10.1 inches

Touch / Glass

Projected Capacitive Multi Touch Screen
Protection Glass (Optional)

Resolution

1280x800

Panel Brightness

350 nits
1000 nits(Optional)

Contrast Ratio

800:1

View Angles

85,85,85,85

Active Area

216.96 x135.6 mm

System Specification

Processor

Intel® Celeron® N4200

Memory

1 x SO-DIMM, DDR3L 1600 MHz, 4GB

Storage

1 x mSATA SSD 128GB.

Ethernet controller

2 x Intel® Gibabit Ethernet Controller

Operating System

Windows 10 IoT Enterprise (Optional)
Linux Ubuntu 18.04 (Optional)

WLAN

Support (Optional)

BT

Support (Optional)

Environment

Operating Humidity

10% to 95% RH

Operating Temperature

-15 °C to 55 °C

Storage Temperature

-30°C to 60°C

Shock

40g for 11ms

Vibration

1.48/1.90/2.24 g rms for XYZ/ 5-500Hz

IP rating

Full IP65

Certification

Certification

Compliant with MIL-STD-810F/G for vibration / shock, CE, FCC

IO Ports

USB Port

1 x USB 2.0 (M12 type)

Serial Port

1 x RS232 (M12 type)(Optional 422/485)

LAN

1 x LAN-10/100/1000 (M12 type)

Indicator

LED Indicators: Power, Storage

Power

Power Rating

9-36V DC (M12 type)

Accessory

Accessory

Quick Start Guide (Hardcopy)
Driver CD & User Manual
M12 Power Cable
M12 Serial Interface Cable
M12 USB/ LAN Cable
I/O Protective Cap x 3

Control

Button

1 x Power Button
1 x Reset Button

Manufacturer Part No:
W10IP3S-GSH2-PB
Brand:
Product Type:
10.1" Panel PC
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCWMAW10IP3S
Product Model:
-
Warranty: 12 months *
