Features
IgniteNet MetroLinq 2.5G 60GHz mmWave Outdoor + 5GHz w/ Int 36dBi (60GHz) & External (5GHz) RP-SMA Connectors, 2500Mbps + SFP point-to-point devices support an extreme capacity of 2.5 Gbps. Its new generation RF powered by a quad core CPU supports higher modulation allowing delivery of more than two times higher capacity (up to 4.6 Gbps OTA rate) compared to the first generation platform.
Note: Pole Mount Bracket Not Included, see below for two options; ICC-BRACKET-LR or ICC-BRACKET-STD
Key Features
- 2.5+ Gbps Aggregate throughput; dynamically allocated (60GHz)
- Management VLAN support and VLAN pass-through
- Supports Service Provider and Enterprise type networks
- Stand-alone or Cloud-controlled operating modes
- Link failover/backup (60GHz + 5GHz) Per Client
- 128bit AES Encryption (standard; 5GHz, and 60GHz)
- SNMP Monitoring with Private MIB
- Interference-Free & Unlicensed Band
Specifications
Manufacturer's Code
ML2.5-60-19-1
Output Power
27 dBm
Operating Modes
PTP
Frequency Range
5170 - 5875MHz + 60GHz
Security
128bit AES Encryption
Interfaces
1x 2.5 Gigabit Ethernet Port, 1x SFP Port, 1 x DC Terminal Block
Wireless standards
802.11ac, 802.11ad
Temperature Range
-30 to +55° C
PoE In
Yes, 24V - 48V 1.5A Passive Gigabit PoE
PoE Out
No
Management
Standalone or cloud-managed
Antenna gain dBi
36dBi (60GHz) & External RP-SMA (5GHz)
Max Power consumption
15 W
Polarisation
Dual Linear
Beamwidth
3° (H-pol) / 3° (V-pol)
Maximum Range
up to 650m
Pole Diameter
30-80mm
