MikroTik RBD53G-5HacD2HnD-TC&RG502Q-EA Router

PB Tech price
PB Tech price
$ 866 .09
 +GST
$ 996 .00
 inc GST

Out of stock

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

MikroTik RBD53G-5HacD2HnD-TC&RG502Q-EA Router

  • Brand: MikroTik
  • MPN: RBD53G-5HacD2HnD-TC&RG502Q-EA
  • Part #: NETMKT1395
  • UPC:
PB Tech price
$ 866 .09 $ 996 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?
  • Brand: MikroTik
  • MPN: RBD53G-5HacD2HnD-TC&RG502Q-EA
  • Part #: NETMKT1395
  • UPC:

Wireless Technology

WiFi 5 (802.11ac)

Ethernet Ports Per Unit

5

USB Ports

No

Wireless Transmission Speed

Not Specified

WiFi Bands

Dual

Cellular Connectivity

Not Specified

HyperFibre Compatible

No

Coverage Area

Not Specified

Features



Chateau 5G s a high-speed, dual-band home access point with LTE/5G support - for really fast Internet anywhere, anytime. There are many options to choose from, depending on your needs: from CAT4 LTE up to the CAT20 LTE and the ultra-fast 5G. But LTE is not the only option - Chateau also features 5 x Gigabit Ethernet ports and a full size USB port.

Strong dual-chain dual-band 2.4/5 GHz wireless for concurrent coverage will solve most interference issues in a crowded environment. For example, a client can simultaneously use the 2.4 GHz channel for all household mobile devices and reserve the 5 GHz channel for tasks that are sensitive to packet loss - such as streaming high-quality videos.

Chateau can be customized: you can choose a variety of labels, we can print your branding, if necessary. And there is another great feature - you can use TR-069 technology to create a custom remote client management option. You can choose how much control your clients need and which features of the highly versatile RouterOS they get to use. Some operators use this to allow users to configure the router via the same web-page they use to pay bills, others restrict novice users from meddling with the settings to provide better browsing experience in the long run.



Specifications

General Information

Brand

MikroTik

Manufacturer Part Number

RBD53G-5HacD2HnD-TC&RG502Q-EA

Architecture

ARM 32bit

CPU

IPQ-4019

CPU core count

4

CPU nominal frequency

716 MHz

Switch chip model

IPQ-4019

Dimensions

240 x 156 x 44 mm

RouterOS license

4

Operating System

RouterOS v7

Size of RAM

256 MB

Storage size

16 MB

Storage type

FLASH

MTBF

Approximately 200'000 hours at 25C

Tested ambient temperature

-40°C to 70°C

IPsec hardware acceleration

Yes

Powering

Number of DC inputs

1 (DC jack)

DC jack input Voltage

12-28 V

Max power consumption

23 W

Max power consumption without attachments

17 W

Cooling type

Passive

Mobile

3G Category

R8 (42.2Mbps Downlink, 5.76Mbps Uplink)

3G bands

6 (850 MHz) / 3 (1800MHz) / 5 (850MHz) / 8 (900MHz) / 19 (800 MHz) / 1 (2100MHz)

LTE Category

20 (2.0 Gbps Downlink, 200 Mbps Uplink)

LTE FDD bands

1 (2100MHz) / 3 (1800MHz) / 5 (850MHz) / 7 (2600MHz) / 8 (900 MHz) / 18 (800 MHz) / 19 (800 MHz) / 20 (800MHz) / 26 (850MHz) / 28 (700MHz) / 32 (1500 MHz)

LTE TDD bands

38 (2600MHz) / 39 (1900MHz) / 40 (2300MHz) / 41 (2500MHz) / 42 (3500MHz) / 43 (3700MHz) / 34 (2000 MHz)

5G NSA FDD bands

1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) / 28 (700 MHz)

5G NSA TDD bands

40 (2300 MHz) / 41 (2500 MHz) / 77 (3700 MHz) / 78 (3500 MHz) / 79 (4700 MHz) / 38 (2600 MHz)

5G SA FDD bands

1 (2100 MHz) / 3 (1800 MHz) / 5 (850 MHz) / 7 (2600 MHz) / 8 (900 MHz) / 20 (800 MHz) / 28 (700 MHz)

5G SA TDD bands

41 (2500 MHz) / 77 (3700 MHz) / 78 (3500 MHz) / 79 (4700 MHz) / 38 (2600 MHz) / 40 (2300 MHz)

TAC

86073604

Ethernet

10/100/1000 Ethernet ports

5

Wireless Specifications

Wireless 2.4 GHz Max data rate

300 Mbit/s

Wireless 2.4 GHz number of chains

2

Wireless 2.4 GHz standards

802.11b/g/n

Antenna gain dBi for 2.4 GHz

2

Wireless 2.4 GHz chip model

IPQ-4019

Wireless 2.4 GHz generation

Wi-Fi 4

Wireless 5 GHz Max data rate

867 Mbit/s

Wireless 5 GHz number of chains

2

Wireless 5 GHz standards

802.11a/n/ac

Antenna gain dBi for 5 GHz

4

Wireless 5 GHz chip model

IPQ-4019

Wireless 5 GHz generation

Wi-Fi 5

Peripherals

Number of SIM slots

1 Modem (Micro SIM)

Number of USB ports

1

USB Power Reset

Yes

USB slot type

USB type A

Max USB current (A)

1

Number of M.2 slots

1

Certification & Approvals

Certification

CE, EAC, ROHS

Manufacturer Part No:
RBD53G-5HacD2HnD-TC&RG502Q-EA
Brand:
Product Type:
Router
UPC
-
Product Family:
-
Shipping Weight:
1.01 kg
PB Part No:
NETMKT1395
Product Model:
RBD53G-5HacD2HnD-TC&RG502Q-EA
Warranty: 12 months *
