Netsys NV-202G 2 Giga LAN VDSL2 Extender. Symmetric LAN bridge over copper.
100Mbps bridge over single copper wire pair
Netsys NV-202G 2 Giga LAN VDSL2 Extender. Symmetric LAN bridge over copper.
100Mbps bridge over single copper wire pair
- Brand: Netsys
- MPN: NV-202G
- Part #: NETNTS2021
- UPC:
- Brand: Netsys
- MPN: NV-202G
- Part #: NETNTS2021
- UPC:
Similar in-stock products available at PB Tech right now
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular VPN Routers





Netsys NV-202G 2 Giga LAN VDSL2 Extender. Symmetric LAN bridge over copper. 100Mbps bridge over single copper wire pair
- Brand: Netsys
- MPN: NV-202G
- Part #: NETNTS2021

Product URL: https://www.pbtech.co.nz/product/NETNTS2021/Netsys-NV-202G-2-Giga-LAN-VDSL2-Extender-Symmetric
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
- Supports high bandwidth up to 160Mbps symmetric over Line ports
- Supports 2 10/100/1000m LAN ports
- Supports long reach mode up to 3 km with 24 gauge phone wire
- Supports auto speed for Line port and Interleave mode selectable through CO side DIP switch
- DIP switch with CO and CPE mode selectable
- Supports long packet size up to 1536 bytes
- Supports Surge protection
- Supports wall mounting
- Supports DIN-Rail mount installation (Optional)
- Compact size and metal case design
- Supports point-to-point applications
- Supports G.INP function, which enhances performance by mitigating noise and ensuring more reliable connections.
- NV-202G is fully compatible with NV-202
Specifications
Cable Connections
RJ-45 (Ethernet): Category 3~6 UTP/STP
RJ-11/Terminal Block (VDSL2): Twisted Pair phone or network grade cable
LED Indicators
1 x Power LED
2 x Link/Active Status for Ethernet port
1 x Link/Active status for SFP Slot
1 x Link LED for VDSL2 (Line) Port
1 x CO Mode indicator LED
1 x CPE Mode indicator LED
VDSL2 Line Code
Discrete multitone (DMT) modulation
Typical Power Consumption
5 W
Power Requirement: Input Voltage
12VDC / 1A (Commercial-grade Power Adapter)
EMC
EMI Compliant: FCC class A
EMS Compliant: CE mark
Operating Temperature
32°F ~ 122°F(0°C ~ 50°C)
Fanless, free air cooling
Storage Temperature
-4°F ~158°F (20°C ~ 70°C)
Humidity
10% to 90% (non-condensing)
Mounting Method
Desktop or Under Counter
Dimensions
3.74" X 4.33" X 1.06" (95 mm X 110 mm X 27 mm)
Power Requirements
External Switching Power Adapter
(Input: 100~240VAC, 50/60Hz Output: 12V/1A)
Agency Compliance
FCC Part 15 Class A, CE
RoHS compliant
