Features
Omada 4G+ Cat6 AX3000 Wi-Fi 6 Outdoor/Indoor Gateway
- 4G+ Cat6 up to 300 Mbps*
- AX3000 Wi-Fi 6 with 2402 Mbps on 5GHz and 574 Mbps on 2.4GHz†#
- 3 × Gigabit WAN/LAN Ports (2 × PoE Out, 1 × PoE In)
- 1 × Nano SIM Card Slot
- 802.3at/bt PoE or 12V/2A DC Power Supply
- 4G and Ethernet WAN Auto Backup with Load Balancing
- IPSec/L2TP/PPTP/OpenVPN/GRE/WireGuard/SSL VPN§
- Centralized Management
- IP55 Weatherproofing
All-in-one Device
Combines 4G Internet access, Wi-Fi 6 wireless technology and 3 Gigabit PoE in/out ports all in one device, and automatic back up and load balancing between 4G and wired WAN can be reached. Enjoyed a powerful and versatile gateway with easy deployment.
Specially Designed Weatherproof Enclosure for Outdoors
Rated as IP55 during Ingress Protection testing, a resilient weatherproof enclosure protects the gateway against harsh outdoor conditions.
Multiple Power Supply Options
Powered by PoE or DC (compatible with solar panels) to overcome mains access limitations.
Plug and Play
Insert a Nano SIM card or connect to an Ethernet WAN Port to get gigabit Wi-Fi. Enjoy hassle-free connect to surveillance cameras via cable or wireless.
Centralized Management
Enables to easy network setup across multiple sites without sending engineer for on-site configuration. Remotely manage via Omada app or web, offering the Essentials version of cloud services for free, reducing maintenance costs for MSP/SI.
Easy Installation
Easy to mount to a wall or pole with the provided mounting kits. Its compact design allows you to place the gateway flexibly.
Easy Management with the Omada App
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Specifications
4G
Network Type
LTE Band of EU:
4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/9
00/800/700/1450 MHz)
4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz)
3G DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA: B1/B3/B5/B8
(2100/1800/850/900 MHz)
Carrier Aggregation:
B1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41
B3+B3/B5/B7/B8/B20/B28/B38/B40/B41
B5+B5/B7/B38/B40/B41
B7+B7/B8/B20/B28/B32
B8+B32/B38/B40/B41
B20+B32/B38/B40
B28+B32/B38/B40/B41
B38+B38
B40+B40
B41+B41
SIM Type
1× Nano SIM Card
Frequency
- Downlink: 300 Mbps;
- Uplink: 50 Mbps
SECURITY
DPI
Application control via DPI / Updated app library
Access Control
Source/Destination IP Based Access Control
Filtering
- Web Group Filtering
- URL Filtering- Web Security
ARP Inspection
- Sending GARP Packets
- ARP Scanning
- IP-MAC Binding
Attack Defense
- TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN
HARDWARE FEATURES
Interface
- 3 Gigabit WAN/LAN Ports
Network Media
- 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
Button
Reset Button
Power Supply
802.3at/bt PoE; 12VDC / 2A Power Adapter
Wi-Fi Frequency & Signal Rate
- 2.4 GHz: 574 Mbps
- 5 GHz: 2402 Mbps (HE160)
Flash
256 MB NAND
DRAM
512 MB DDR4
LED
4G Signal, WLAN, WAN/LAN, SYS
Dimensions ( W x D x H )
6.9 × 4.0 × 1.5 in (174.8 × 100.4 × 38.7 mm) (Antenna dimensions are not included)
Antenna
- Wi-Fi: Two 5GHz 4.0dBi & 2.4GHz 2.3 dBi dual-band build-in
antennas
- LTE: Two 4.0dBi omnidirectional detachable antennas
Mounting
Pole/Wall-Mounting
Max. Power Consumption
POE:62.9W max @ 220V/50Hz 25?
DC: 16.6W max @ 220V/50Hz 25?
PERFORMANCE
DPI Throughput
- TCP: 1131 Mbps
- UDP: 974 Mbps
GRE
- Unencrypted: 450.3Mbps
- Encrypted: 277.6Mbps
WireGuard VPN
462.8Mbps
Concurrent Session
120,000
New Sessions /Second
3,800
NAT (Static IP)
945.9Mbps / 950.2Mbps
NAT(DHCP)
947.3Mbps / 949.4Mbps
NAT(PPPoE)
916.9Mbps / 946.3Mbps
NAT (L2TP)
878.9Mbps / 778.9Mbps
NAT (PPTP)
852.2Mbps / 775.9Mbps
IPsec VPN Throughput
- ESP-SHA1-AES256: 568.3Mbps
- ESP-SHA256-AES256: 559.8Mbps
- ESP-SHA384-AES256: 565.6Mbps
- ESP-SHA512-AES256: 550.0 Mbps
OpenVPN
85.1Mbps
L2TP VPN Throughput
- Unencrypted: 858.7Mbps
- Encrypted: 467.0Mbps
PPTP VPN Throughput
- Unencrypted: 876.2Mbps
- Encrypted:
SSL VPN Throughput
86.6Mbps
66 Byte Packet Forwarding Rate
1,453,489 pps / 1,453,489 pps
1,518 Byte Packet forwarding rate
81275 pps / 81275 pps
WIRELESS FEATURES
Advanced Features
- Seamless Roaming
- Mesh (with EAP that supports Mesh)
- OFDMA
- Beamforming
- MU-MIMO
- Rate Limit: Based on SSID/Client
- Airtime Fairness
- Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
- Multiple SSIDs: 16 in total (8 per radio)
Guest Network
Support
BASIC FUNCTIONS
WAN Connection Type
- Static IP
- Dynamic IP
- PPPoE (supports MRU Configuration)
- PPTP
- L2TP
MAC Clone
Modify WAN Address
DHCP
- DHCP Server
- DHCPv6 PD Server (only in Standalone Mode)
- DHCP Options Customization
- DHCP Address Reservation
- Multi-IP Interfaces
- Multi-Net DHCP
SMS
Receive / Send SMS
IPv6
StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
VLAN
802.1Q VLAN
IPTV
IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Advanced Features
Access Control
IP/Port/Protocol/Domain Name Filtering
Advanced Routing
- Static Routing
- Policy Routing
- RIP
- OSPF
Bandwidth Control
IP-Based Bandwidth Control
Load Balance
- Intelligent Load Balance
- Application Optimized Routing
- Link Backup(Timing, Failover)
- Online Detection
NAT
- One-to-One NAT
- Multi-Net NAT
- Virtual Server
- Port Triggering
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP
Session Limit
IP-Based Session Limit
VPN
GRE
Only in Standalone Mode
SSL VPN
50 Tunnels
IPsec VPN
- 100 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
- IPsec Failover
- IKE v1/v2
- MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)
PPTP VPN
- PPTP VPN Server
- PPTP VPN Client (10)
- 50 Tunnels
- PPTP with MPPE Encryption
L2TP VPN
- L2TP VPN Server
- L2TP VPN Client (10)
- 50 Tunnels
- L2TP over IPSec
OpenVPN
- OpenVPN Server
- OpenVPN Client (5)
- 55 OpenVPN Tunnels
- "Certificate + Account" Mode
- Full Mode
WireGuard VPN
- 20 Tunnels
AUTHENTICATION
Web Authentication
- No Authentication
- Simple Password
- Hotspot (Local User / Voucher / SMS / Radius)
- External Radius Sever
- External Portal Sever
- LDAP
Management Features
Omada App
Yes.
Centralized Management
- Omada Cloud Essentials
- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller
Cloud Access
Yes.
Service Dynamic
DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
Maintenance
- Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3
- Diagnostics (Ping & Traceroute)
- NTP Synchronize
- Port Mirroring
- CLI (only in Standalone Mode)
- Syslog Support
Management Features
- Automatic Device Discovery
- Intelligent Network Monitoring
- Abnormal Event Warnings
- Unified Configuration
- Reboot Schedule
- Captive Portal Configuration
OTHERS
Certification
CE, FCC, RoHS
Package Content
- ER703WP-4G-Outdoor
- Mounting Kits
- Quick Installation Guide
System Requirements
- Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
- MAC OS, NetWare, UNIX or Linux
Environment
- Operating Temperature: -30 °C to 60 °C (-22 °F to 140 °F)
- Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
- Operating Humidity: 5% to 95% non-condensing
- Storage Humidity: 5% to 90% non-condensing
