TP-Link Omada ER706WP-4G 4G+ CAT6 Gigabit Multi-WAN PoE VPN Gateway with Dual-Band WiFi 6 AX3000

SFP x1 / 1GbE PoE+ x4 (45W) / Nano-SIM Slot x2

PB Tech price

$ 520 .87

+GST

$ 599 .00

inc GST

TP-Link Omada ER706WP-4G 4G+ CAT6 Gigabit Multi-WAN PoE VPN Gateway with Dual-Band WiFi 6 AX3000

SFP x1 / 1GbE PoE+ x4 (45W) / Nano-SIM Slot x2

Brand: TP-Link
MPN: ER706WP-4G
Part #: NETTPL7062
UPC:

NEW ARRIVAL

PB Tech price

$ 599 .00

inc GST

+GST inc GST

Hurry, only 1 unit left!

In stock at PB Tech

Check store stock levels

Click & Collect: Select your store to check availability

Delivery: Order now and it ships tomorrow When will I receive it?

Add To Compare

Stock Alerts

Finance from $6.23 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Weekly payments are indicative only and based on a retail price of over a loan term of months at an interest rate of % p.a. and include a monthly service fee and a establishment fee (excludes optional Payment Protection Insurance).The total amount payable over the term of the loan is . Details of finance (including weekly payments, the total amount repayable over the term of the loan, interest rate and any applicable fees) can be confirmed with a detailed quote. Full disclosure of all of the terms of your finance will also be provided to you in the Finance Now disclosure statement for your consideration prior to confirmation of your purchase. All finance is subject to Finance Now terms and conditions and approval criteria.

Learn more about Finance Now

24 months interest FREE available*

View All Finance Options

Click or hover over image to enlarge

Brand: TP-Link
MPN: ER706WP-4G
Part #: NETTPL7062
UPC:

Be the first to review this product

Wireless Technology

WiFi 6 (802.11ax)

Ethernet Ports Per Unit

USB Ports

Wireless Transmission Speed

3000Mbps

WiFi Bands

Dual

Cellular Connectivity

4G (Single SIM)

HyperFibre Compatible

Not Specified

Coverage Area

Not Specified

View full specs

Returns & Warranty Bulk Quote Print Page

Features

Omada 4G+ Cat6 AX3000 Gigabit VPN Gateway with 4-Port PoE+

- Support 4G+ Cat6*: Insert a Nano SIM card to enjoy up to 300 Mbps (Not compatible with AT&T's Text & Data plans** in the US).
- AX3000 Dual-Band WiFi 6: Supports 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz***
- 5 Gigabit Ethernet Ports: Provide high-speed wired connectivity.
- 5 High-Gain Detachable Antennas: Extend and concentrate the Wi-Fi signals.
- Centralized Management: Cloud access and the Omada app for easy management.
- Omada Mesh: Seamlessly connects to EAPs that support mesh technology.*
- High-Security VPN: Supports IPSec / SSL / WireGuard / OpenVPN / PPTP / L2TP VPN.

Specifications

Network Type

LTE Band of EU:
- 4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/
900/800/700/1450 MHz)
- 4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz)
- 3G DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA: B1/B3/B5/B8
(2100/1800/850/900 MHz)
Carrier Aggregation of EU:
B1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41
B3+B3/B5/B7/B8/B20/B28/B38/B40/B41
B5+B5/B7/B38/B40/B41
B7+B7/B8/B20/B28/B32
B8+B32/B38/B40/B41
B20+B32/B38/B40
B28+B32/B38/B40/B41
B38+B38
B40+B40
B41+B41

SIM Type

2× Nano SIM Card( (4G+ Cat6)

Frequency

- Downlink: 300 Mbps;
- Uplink: 50 Mbps

SECURITY

DPI

Application control via DPI / Updated app library

IDS/IPS

Signature-based IPS/IDS threat detection

Access Control

Source/Destination IP Based Access Control

Filtering

- Web Group Filtering†
- URL Filtering
- Web Security†

ARP Inspection

- Sending GARP Packets
- ARP Scanning†
- IP-MAC Binding

Attack Defense

- TCP/UDP/ICMP Flood Defense
- Block TCP Scan (Stealth FIN/Xmas/Null)
- Block Ping from WAN

HARDWARE FEATURES

Interface

- 1 Gigabit SFP WAN/LAN Port
- 1 Gigabit WAN Port
- 4 Gigabit LAN/WAN Ports

Network Media

- 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100O STP (Max 100 m)
- 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)

Button

Reset Button

Power Supply

4 Ports PoE+ Output, 45 W PoE Budget

Wi-Fi Frequency & Signal Rate

- 2.4 GHz: 574 Mbps
- 5 GHz: 2402 Mbps (HE160)

Flash

256 MB NAND

DRAM

512 MB DDR4

LED

SYS, WLAN, SFP, LTE1, LTE2, PoE Max, LTE Signal, WAN (1000M Link/Act, 100/10M Link/Act), WAN/LAN (1000M Link/Act, 100/10M Link/Act, PoE)

Dimensions ( W x D x H )

8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm) (Antenna dimensions are not included)

Antenna

- Wi-Fi: Three 5GHz 5.5dBi & 2.4GHz 4.5dBi dual-band detachable antennas
- LTE: Two 4.0dBi omnidirectional detachable antennas

Mounting

Desktop/Wall-Mounting/Rackmount

Max. Power Consumption

64.9W with PoE Max; 19.8W without PoE

PERFORMANCE

IPS Throughput

- TCP: 229 Mbps
- UDP: 188 Mbps

DPI Throughput

- TCP: 933 Mbps
- UDP: 927 Mbps

GRE

- Unencrypted: 545.3Mbps
- Encrypted: 282.6Mbps

WireGuard VPN

387.7Mbps

Concurrent Session

150,000

New Sessions /Second

5,100

NAT (Static IP)

947.1Mbps / 940.1Mbps

NAT(DHCP)

949.2Mbps / 941.1Mbps

NAT(PPPoE)

942.6Mbps / 941.1Mbps

NAT (L2TP)

875.4Mbps / 892.0Mbps

NAT (PPTP)

881.2Mbps / 895.8Mbps

IPsec VPN Throughput

- ESP-SHA1-AES256: 652.2Mbps
- ESP-SHA256-AES256: 654.4Mbps
- ESP-SHA384-AES256: 646.5Mbps
- ESP-SHA512-AES256: 670.5 Mbps

OpenVPN

115.5Mbps

L2TP VPN Throughput

- Unencrypted: 990.0Mbps
- Encrypted: 475.0Mbps

PPTP VPN Throughput

- Unencrypted: 1177.9Mbps
- Encrypted: 177.4Mbps

SSL VPN Throughput

122.5Mbps

66 Byte Packet Forwarding Rate

1,453,489 pps / 1,453,488 pps

1,518 Byte Packet forwarding rate

81274 pps / 91275 pps

WIRELESS FEATURES

Advanced Features

- Seamless Roaming
- Mesh (with EAP that supports Mesh)
- OFDMA
- Beamforming
- MU-MIMO
- Rate Limit: Based on SSID/Client
- Airtime Fairness
- Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise
- Multiple SSIDs: 16 in total (8 per radio)

Guest Network

Support

BASIC FUNCTIONS

WAN Connection Type

- Static IP
- Dynamic IP
- PPPoE (supports MRU Configuration)
- PPTP
- L2TP

MAC Clone

Modify WAN Address

DHCP

- DHCP Server
- DHCPv6 PD Server (only in Standalone Mode)
- DHCP Options Customization
- DHCP Address Reservation
- Multi-IP Interfaces
- Multi-Net DHCP

SMS

Receive / Send SMS

IPv6

StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode

VLAN

802.1Q VLAN

IPTV

IGMP v2/v3 Proxy, Custom Mode, Bridge Mode

Advanced Features

Access Control

IP/Port/Protocol/Domain Name Filtering

Advanced Routing

- Static Routing
- Policy Routing
- RIP†
- OSPF†

Bandwidth Control

IP-Based Bandwidth Control

Load Balance

- Intelligent Load Balance
- Application Optimized Routing
- Link Backup(Timing, Failover)
- Online Detection

NAT

- One-to-One NAT
- Multi-Net NAT
- Virtual Server
- Port Triggering†
- NAT-DMZ
- FTP/H.323/SIP/IPSec/PPTP ALG
- UPnP

Session Limit

IP-Based Session Limit

VPN

GRE

Only in Standalone Mode

SSL VPN

50 Tunnels

IPsec VPN

- 100 IPSec VPN Tunnels
- LAN-to-LAN, Client-to-LAN
- Main, Aggressive Negotiation Mode
- DES, 3DES, AES128, AES192, AES256 Encryption Algorithm
- IPsec Failover
- IKE v1/v2
- MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm
- NAT Traversal (NAT-T)
- Dead Peer Detection (DPD)
- Perfect Forward Secrecy (PFS)

PPTP VPN

- PPTP VPN Server
- PPTP VPN Client (10)
- 50 Tunnels
- PPTP with MPPE Encryption

L2TP VPN

- L2TP VPN Server
- L2TP VPN Client (10)
- 50 Tunnels
- L2TP over IPSec

OpenVPN

- OpenVPN Server
- OpenVPN Client (5)
- 55 OpenVPN Tunnels
- "Certificate + Account" Mode
- Full Mode

WireGuard VPN

- 20 Tunnels

AUTHENTICATION

Web Authentication

- No Authentication
- Simple Password§
- Hotspot (Local User / Voucher§ / SMS§ / Radius§)
- External Radius Sever
- External Portal Sever§
- LDAP

Management Features

Omada App

Yes.

Centralized Management

- Omada Cloud-Based Controller
- Omada Hardware Controller (OC300)
- Omada Hardware Controller (OC200)
- Omada Software Controller

Cloud Access

Yes.

Service Dynamic

DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)

Maintenance

- Web Management Interface
- Remote Management
- Export & Import Configuration
- SNMP v1/v2c/v3
- Diagnostics (Ping & Traceroute)†
- NTP Synchronize†
- Port Mirroring
- CLI (only in Standalone Mode)
- Syslog Support

Zero-Touch Provisioning

Yes. Require the use of Omada Cloud-Based Controller.

Management Features

- Automatic Device Discovery
- Intelligent Network Monitoring
- Abnormal Event Warnings
- Unified Configuration
- Reboot Schedule
- Captive Portal Configuration

OTHERS

Certification

CE, FCC, RoHS

Package Content

- ER706WP-4G
- Power Adapter
- Quick Installation Guide

System Requirements

- Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11
- MAC OS, NetWare, UNIX or Linux

Environment

- Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
- Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
- Operating Humidity: 10% to 90% non-condensing
- Storage Humidity: 5% to 90% non-condensing

Manufacturer Part No:

ER706WP-4G

Brand:

TP-Link

Product Type:

4G+ CAT6 Gigabit Multi-WAN PoE VPN Gateway with Dual-Band WiFi 6 AX3000

UPC

Product Family:

Omada

Shipping Weight:

1.95 kg

PB Part No:

NETTPL7062

Product Model:

ER706WP-4G

Warranty: 36 months *
