Teltonika Uninterruptible power supply for RUT300, RUTX08, RUTX10, TSW110, TSW210

PB Tech price
PB Tech price
$ 202 .77
 +GST
$ 233 .19
 inc GST

Out of stock

Teltonika Uninterruptible power supply for RUT300, RUTX08, RUTX10, TSW110, TSW210

  • Brand: Teltonika
  • MPN: BAT120
  • Part #: NETTTK0120
  • UPC:
PB Tech price
$ 202 .77 $ 233 .19
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?

Features

Teltonika Uninterruptible power supply for RUT300, RUTX08, RUTX10, TSW110, TSW210

The BAT120 is the first uninterrupted power supply from Teltonika Networks.

It is equipped with two 4-pin DC ports for power input and output. The input voltage ranges from 9V to 30V and output of 12VDC when operated from the battery.

Acting as an uninterrupted power source, BAT120 provides enough power from two 18650 Li-Io cells to keep a compatible Teltonika Networks device working for up to 6 hours. BAT120 has reverse and overvoltage protection for input and 3A overcurrent protection for output as safety features.

This rugged and reliable uninterrupted power source is perfect for applications that require constant connectivity from their Teltonika Networks devices even when power outages or fluctuations occur.

- Power Supply lasts up to 6 hours
- I/O Can be set up with a router for custom alerts
- Reverse polarity & Overvoltage
- Rugged aluminum housing protection
- DIN rail and surface mounting options
- Compatible with: RUT2xx, RUT95x, RUT3xx, RUTXxx, TRB14x, TRB2xx, TSW110, TCR100



Specifications

MPN

BAT120

Connector

4-pin industrial DC power socket

Input power/max charging current

Charger: max 4 W/300 mA (max battery charging current)

Input voltage range

9 - 30 VDC

Input protection

Reverse polarity protection, Overvoltage protection

Output voltage in passthrough mode

9 - 30 VDC

Output voltage in battery mode

12 VDC

Output protection

3A overcurrent protection

Max output power/current in battery mode

22 W/1.8 A

Battery capacity

2300 mAh 17 Wh

Power IN

1 x 4 pin DC connector

Power OUT

1 x 4 pin DC connector

Status LEDs

1 x IN PWR LED, 1 x OUT PWR LED, 4 x Power status LEDs

Switch

On/Off slider switch

Alarm Output

1 x Active HIGH output, max output 12 V, 2.5 mA

Lithium cells

2 x 18650 Li-Ion cells

Compatible devices

RUT2xx, RUT95x, RUT3xx, RUTXxx, TRB14x, TRB2xx, TSW110, TCR100

Casing material

Aluminum housing

Dimensions (W x H x D)

100 x 30 x 85 mm

Weight

315g

Mounting options

DIN rail, flat surface placement

Operating temperature

0 °C to 45 °C

Regulatory

CE/RED, UKCA, EAC

Manufacturer Part No:
BAT120
Brand:
Teltonika
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
NETTTK0120
Product Model:
-
Warranty: Not applicable
