Ubiquiti UniFi (UX) Express Cloud Gateway
WiFi 6 Dual-Band AX3000 / 1GbE x2
Ubiquiti UniFi (UX) Express Cloud Gateway
WiFi 6 Dual-Band AX3000 / 1GbE x2
- Brand: Ubiquiti
- MPN: UX
- Part #: NETUBI2207
- UPC: 810084691960
Select your store to check availability
What PB Tech customers are saying about this product...
See More Reviews"If you have a small network (UX Express plus 4 other Unifi devices), and you have simple network needs, the UX Express is a perfect solution. If you are likely to want anything mor ...view more"
"Incredibly straightforward to set up and lots of features. Yet another fantastic Ubiquiti product. Recommend!"

"A lot has been written about the UniFi ecosystem so if you'r ...view more"
COMBO DEALS: Buy Together and SAVE!







Ubiquiti UniFi USW-Flex-Mini 5-Port Gigabit L2 Managed Switch - 1GbE x5
$62.26 +GST
$71.60


Ubiquiti U-POE-at 30W 802.3AT PoE Injector
$30.96 +GST
$35.60


Cruxtec Cat6 Ethernet Cable - 1m - Black
$3.04 +GST
$3.50


Ubiquiti UniFi UAP-AC-M (AC1200) Dual-Band 4-Stream WiFi 5 Access Point (PoE 9W)
$203.78 +GST
$234.35
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular VPN Routers





Ubiquiti UniFi (UX) Express Cloud Gateway WiFi 6 Dual-Band AX3000 / 1GbE x2
- Brand: Ubiquiti
- MPN: UX
- Part #: NETUBI2207
- UPC:810084691960

Product URL: https://www.pbtech.co.nz/product/NETUBI2207/Ubiquiti-UniFi-UX-Express-Cloud-Gateway-WiFi-6-Dua?qr=popular_related_products
Branch | New Stock | On Display |
---|---|---|
Albany | 2 | |
Glenfield | 5 | |
Queen Street | 3 | |
Auckland Uni | 0 | |
Newmarket | 2 | |
Westgate | 5 | |
Penrose | 5+ | |
Henderson (Express) | 0 | |
St Lukes | 5+ | |
Manukau | 4 | |
Hamilton | 4 | |
Tauranga | 3 | |
New Plymouth | 2 | |
Palmerston North | 2 | |
Petone | 3 | |
Wellington | 3 | |
Head Office | 5+ | |
Hornby | 5 | |
Christchurch Central | 5 |
Features
Impressively compact UniFi Cloud Gateway and WiFi 6 access point that runs UniFi Network. Powers an entire network or simply meshes as an access point.
- Built-in WiFi 6 AP
- 140 m² (1,500 ft²) single-unit coverage
- 50+ connected WiFi devices*
- (1) GbE RJ45 WAN port
- (1) GbE RJ45 LAN port to extend network
- 0.96" LCM status display
- Manages up to four additional UniFi Network devices when operated as a gateway
- Managed with UniFi Network 8.0.7 and later
Specifications
Mechanical
Dimensions
98 x 98 x 30 mm (3.6 x 3.6 x 1.2")
Weight
302 g (10.7 oz)
Enclosure material
Polycarbonate
Hardware
Management interface
Ethernet
Bluetooth
Networking interface
LAN:
(1) GbE RJ45 port
WAN:
(1) GbE RJ45 port
Power method
USB type C (5V DC/3A)
Max. power consumption
10W
Max. TX power
2.4 GHz
5 GHz
22 dBm
25 dBm
MIMO
2.4 GHz
5 GHz
2 x 2 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
Throughput rate 2.4 GHz
5 GHz
573.5 Mbps
2.4 Gbps
Antenna gain
2.4 GHz
5 GHz
4 dBi
5.15 dBi
Antennas
(2) Internal 2.4G/5G WiFi dual-band antenna
(1) Internal 2.4G single-band BT antenna
LCM display
0.96" status display
Button
Factory reset
Ambient operating temperature
-10 to 45° C (14 to 113° F)
Ambient operating humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
Gateway Features
Performance
Internet quality and outage reporting
Next-generation security
Application-aware firewall rules
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Advanced networking
License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support
Software
WiFi standards
802.11a/b/g/n/ac/ax
Wireless security
WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID
Console mode: 3 per band
Standard AP: 8 per band
VLAN
802.1Q
Advanced QoS
Per-user rate limiting
Guest traffic isolation
Supported
Concurrent clients
50+*
Supported Data Rates
802.11a
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
1, 2, 5.5, 11 Mbps
802.11g
6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)
6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac (WiFi 5)
6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6)
7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
Application Requirements
UniFi Network
Version 8.0.7 and later
