Supermicro 500W 1U Redundant Power Supply
Out of stock
Supermicro 500W 1U Redundant Power Supply
- Brand: Supermicro
- MPN: PWS-504P-1R
- Part #: PSUSPM50401
- UPC: 672042077199
- Brand: Supermicro
- MPN: PWS-504P-1R
- Part #: PSUSPM50401
- UPC: 672042077199
Product is out of stock. View similar products in-stock at PB Tech
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Server Power Supplies





Supermicro 500W 1U Redundant Power Supply
- Brand: Supermicro
- MPN: PWS-504P-1R
- Part #: PSUSPM50401
- UPC:672042077199

Product URL: https://www.pbtech.co.nz/product/PSUSPM50401/Supermicro-500W-1U-Redundant-Power-Supply
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
Supermicro 500W 1U Redundant Power Supply
- Designed for Supermicro 1U Server
- Redundant PSU with PMBus 1.2 Support for Remote Management
- 80 Plus Titanium Efficiency
- Supermicro Certified
The Supermicro PWS-504P-1R is an 80 Plus Titanium level redundant power supply capable of supplying 500W output power at 91% efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages. Features a card edge connector for connection with the backplane of compatible Supermicro 1U systems. This power supply is designed to not only provide you reliable power to your Supermicro server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. Rest easy knowing your hardware will be up and running with a mean-time between failure (MTBF) of greater than 100,000 hours and an LED indicator to keep you informed on normal/abnormal conditions for your PSU. This power supply is redundant to safe-guard your system from power failure and allows for hot-swap replacement to eliminate system downtime. All materials contained comply with RoHS requirements and is certified by Supermicro.
Specifications
Total Power Output
500W
Type
Module
Type of Power Supply
Power Supply
Form Factor
1U
Dimension (W x H x L)
54.5 x 40 x 320 mm
+5V
N/A
+12V
42A
+3.3V
N/A
5V Standby
3A
Input Voltage Range
100-240V
Input Frequency Range
50-60Hz
Input Current Range
6.1-2.6A
Output Type
Gold Finger (54.5 Wide Molex)
8Pin / 4Pin (12V) Connector
N/A
PFC
Yes
Voltage / Current
Yes
Energy Efficiency
91% Peak
80 Plus Certification
80 Plus Titanium
Validated Systems
AS-1014S-WTRT, AS-1114S-WTRT, SYS-1019P-WTR, SYS-5017R-WRF, SYS-5018R-WR, SYS-5019C-WR, SYS-5019P-WTR, SYS-5019S-W4TR, SYS-5019S-WR, SYS-6017B-URF, SYS-6017R-TDLRF, SYS-6018R-TDTPR
Validated Chassis
CSE-113TQ-R500CB, CSE-113TQ-R500UB, CSE-813LT-R500CB, CSE-815TQ-R500CB, CSE-815TQ-R500UB, CSE-815TQ-R500WB, CSE-815TQC-R504CB, CSE-815TQC-R504WB, CSE-815TQC-R504WB2, CSE-LA15TQC-R504W, CSE-LB16AC2-R504W
Product Environmental Compliance
RoHS and REACH compliant, details available upon request
