AAEON UP Xtreme Board A30 Remove CPLD/40pin with Celeron 4305UE. 4GB RAM. 64GB EMMC, w/o 40pin

AAEON UP Xtreme Board A30 Remove CPLD/40pin with Celeron 4305UE. 4GB RAM. 64GB EMMC, w/o 40pin

  • Brand: AAEON
  • MPN: UPX-WHLCR-A30-04064
  • Part #: SBCAAEUP00076
  • UPC:

Features

The UP Xtreme is the third generation of UP Board products, powered by 8th Generation Intel® Core™ and Celeron® processors (formerly Whiskey Lake) with up to 16GB of onboard RAM and 64GB of eMMC memory to power through any application. With the latest Intel® graphics solution, the UP Xtreme is capable of 4K video output, and features a built-in audio jack as standard.

The UP Xtreme brings industrial grade features to the UP line of products, such as 12~60V wide voltage power input, two RS232/422/485 10-pin headers, and time sensitive networking (TSN) to facilitate communication in a connected factory. The UP Xtreme is also built to perform in temperatures ranging from 0°C up to 60°C.

The UP Xtreme offers flexible expandability with both a 40-pin and 100-pin connector, as well as m.2 2230 and 2280 slots, and mPCIe slots. The UP Xtreme can be expanded with wireless modules for Wi-Fi, Bluetooth, 4G and LTE. The UP Xtreme is compatible with other UP Board modules, including the AI Core X, AI Core XM 2280, and Vision Plus X, all featuring the Intel® Movidius™ Myriad™ X. With each module installed, the UP Xtreme supports up to six Intel® Movidius™ Myriad™ X modules, providing high-performance AI processing for edge computing applications.

Users can also get the UP Xtreme in a pre-built system, the UP Xtreme Edge (UPX Edge). The rugged UPX Edge can operate in conditions as cold as -20°C up to 70°C with the AI Core XM 2280 modules (two Intel® Movidius™ Myriad™ X VPUs).


Features

- Intel® WHL-U Core i7/i5/i3/Celeron® Processor SoC
- Onboard DDR4 memory, Max 16GB
- eMMC 64GB
- 40Pin HAT Connector
- 100pin docking connector
- SATA 6.0Gb/s x 3
- Mini-card slot x 1
- M.2 2280 M key x 1
- M.2 2230 E key x 1
- Audio Jack x 1 (line out + Mic)
- Lockable DC connector

Specifications

PROCESSOR

8th generation Intel® Core i7/i5/i3/Celeron Processor SoC

GRAPHICS

Intel® Graphics , GEN 9

I/O

RJ45 Ethernet Connector x 2
HDMI/DP STACK Connector x 1
Power Button / LED x 1
Audio Jack (Line out + MIC) x 1
DC connector (Lockable) x 1
STM32 connector x 1
eDP with Backlight control Header x 1
10 pin 1xUSB2.0 x 1 / HSUART (TTL) x 1
SATA Connector with power connector (5V, GND) x 1
4 pin Fan connector x1
Power Button header x 1
Reset Pin header x 1
M.2 2230 E Key x 1
M.2 2280 M Key x 1
40 pin HAT connector x 1
mPCIe slot x 1
10 pin RS232/422/485 pin header x 2
100pin connector x 1

CAMERA

-

USB

USB 3.2 Gen 2 STACK Connector for 2 ports (Front) x 1
USB 3.2 Gen 2 STACK Connector for 2 ports (Rear) x 1

EXPANSION

M.2 2230 E Key x 1
M.2 2280 M key x 1
mPCIe slot x 1
100pin connector x 1
40pin HAT

RTC

RTC battery, CR2032 x 1

POWER

12V - 60VDC

DIMENSION

122 x 120 mm

MEMORY

Onboard DDR4 memory, Max 16GB
Single Channel: 4GB
Dual Channel: 8GB, 16GB

STORAGE

SATA3 (6Gb/s) x 3:
a.SATA connector x 1
b. M.2 2280 SATA option (auto detect) x 1
c. minicard mSATA option (auto detect) x 1

DISPLAY INTERFACE

HDMI2.0 x 1
DP1.2 x 1
eDP x 1
CEC support with STM32 on HDMI x 1

ETHERNET

i7/i5 SKU LAN (i210 AT) x 1, LAN (i219 LM) x 1
i3/Celeron® LAN (i210 AT) x 1, LAN (i219 V) x 1

OS SUPPORT

Win 10
Linux Ubuntu 18.04 with Kernel 5.0
Linux Yocto 2.7 with Kernel 4.19

OPERATING TEMPERATURE

0 ~ 60°C (32 ~ 140°F)

OPERATING HUMIDITY

0% ~ 90% relative humidity, non-condensing

CERTIFICATE

CE/FCC class A, RoHS Compliant, REACH

Manufacturer Part No:
UPX-WHLCR-A30-04064
Brand:
Product Type:
-
UPC
-
Product Family:
UP Xtreme Board A30
Shipping Weight:
1 kg
PB Part No:
SBCAAEUP00076
Product Model:
Remove CPLD/40pin
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
