Ideal Industries IDL61-775 1000A AC/DC TRMS TightSight Clamp Meter. CAT IV 600V and CAT III 1000VRating.

PB Tech price
PB Tech price
$ 354 .78
 +GST
$ 408 .00
 inc GST

Out of stock

Ideal Industries IDL61-775 1000A AC/DC TRMS TightSight Clamp Meter. CAT IV 600V and CAT III 1000VRating.

  • Brand: Ideal Industries
  • MPN: IDL61-775
  • Part #: SCBIDI4269
  • UPC:
PB Tech price
$ 354 .78 $ 408 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?
  • Brand: Ideal Industries
  • MPN: IDL61-775
  • Part #: SCBIDI4269
  • UPC:

Features

IDEAL INDUSTRIES 1000A AC/DC TRMS TightSight Clamp Meter. CAT IV 600V and CAT III 1000V Rating

- TightSight® second display
- Tapered jaws with hook tip
- True RMS current and voltage
- AC/DC voltage
- Audible continuity
- High-frequency rejection*
- Peak hold
- Max/min hold
- Data hold
- Selectable audible and visual alerts when potentially hazardous voltages are detected at the probe terminals
- Selectable auto power-off
- Backlit display
- Low battery indicator
- Reads accurately on noisy electrical circuits

Problem

Have you ever had to measure the circuit current in a confined, dimly lit and hard-to-reach location?

Solution

IDEAL TightSight® Clamp Meter! This meter allows the user to safely and easily view current measurements with the exclusive second TightSight® display.

Safety

- The patented TightSight® display lets you easily take readings while keeping your head at a safe distance from the panel - no more need to twist the meter or risk pulling on an energized conductor
- Easy to read backlit display with large numbers and icons so you can always see the correct reading
- Selectable audible and visual alerts when potentially hazardous voltages are detected at the probe terminals
- Electronic overload protection on all ranges
- Test leads supplied are compliant to IEC61010-031 compliant

Productivity

- Read and record while clamped instead of holding the reading, unclamping, moving and recording
- Hook tip for easier wire separation and tapered jaws for reaching into tight spaces
- Help troubleshoot with min and max value readings over a period, i.e. nuisance tripping and power supply fluctuations
- True RMS provides accurate readings of non-sinusoidal load currents
- Broad current range from 0 to 1000 amps (61-770 series) covers multiple applications
- Large jaw diameter for cables up to 51mm in diameter (770 series only)

Value

- Includes carrying case and test leads with alligator clips
- Full AC/DC capabilities: the Tightsight® is equally adaptable for both AC and DC measurement requirements - such as solar, public transportation, and battery backup applications

Specifications

CAT Rating (Safety)

CAT IV 600V
CAT III 1000V

Listing

cULus, CE, RCM

Clamp/Jaw Opening

2.0 in. (50.8mm)

AC Voltage (Volts)

750V

DC Voltage (Volts)

750V

AC Current (Amps)

1000A

DC Current (Amps)

1000A

Ohms (Resistance)

999.9O

Battery Type (Included)

1 x 9 Volt

LCD Display Count

9999

Manufacturer Part No:
IDL61-775
Brand:
Ideal Industries
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
SCBIDI4269
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
