HP HPE GBIC SFP+ 10GbE SR 850nm for BladeSystem c-Class
HP HPE GBIC SFP+ 10GbE SR 850nm for BladeSystem c-Class
- Brand: HP
- MPN: 456096-001
- Part #: SVPHSV1789
- UPC:
- Brand: HP
- MPN: 456096-001
- Part #: SVPHSV1789
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Server Accessories





HP HPE GBIC SFP+ 10GbE SR 850nm for BladeSystem c-Class
- Brand: HP
- MPN: 456096-001
- Part #: SVPHSV1789

Product URL: https://www.pbtech.co.nz/product/SVPHSV1789/HP-HPE-GBIC-SFP-10GbE-SR-850nm-for-BladeSystem-c-C
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
A 10-Gigabit transceiver in SFP+ form-factor that supports the 10-Gigabit SR standard, providing 10-Gigabit connectivity up to 400m on OM4 multi-mode fiber.
- 10Gb Ethernet transmission rate with SFP+ form factor
- Transmissions are up to 300m on MMF (SR), up to 220 m MMF (LRM) and 10 km on SMF (LR)
- Low power consumption at <0.8W for SR, <1W for LRM and LR
- Duplex LC connector
The HPE 456096-001 is an Plug-in module form factor transceiver module supporting the 1 x Ethernet 10GBase-SR - LC multi-mode x 2 standard. The 456096-001 is hot pluggable and has a 1 x Ethernet 10GBase-SR - LC multi-mode x 2 interface. The transceiver provides speeds of 10 Gbps on 10 Gigabit Ethernet connections up to 1 x SFP+
PB Tech is a HP Gold Partner
Specifications
Brand:
HPE
MPN:
456096-001
General
Device Type:
SFP+ Transceiver Module
Form Factor:
Plug-in Module
Transceiver Form Factor:
SFP+
Networking
Connectivity Technology:
Wired
Cabling Type:
10GBase-SR
Data Link Protocol:
10 Gigabit Ethernet
Data Transfer Rate:
10 Gbps
Max Transfer Distance:
980 ft
Ports:
1 LC 10-GbE port (IEEE 802.3ae Type 10Gbase-SR), Duplex: full only
Connector Type:
LC
Wavelength:
850 nm
Cable type:
62.5/125 ?m or 50/125 ?m (core/cladding) diameter, graded-index, low metal content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC793-2Type A1b or
A1a, respectively
Fiber type:
Multi Mode
Maximum distance:
2-26m with 62.5 ?m multimode cable @ 160 MHz*km 2-33m with 62.5 ?m multimode cable @ 200 MHz*km 2-66m with 50 ?m multimode cable @ 400 MHz*km 2-82m with 50 ?m multimode cable @ 500 MHz*km 2-300m with 50 ?m multimode cable @ 2000 MHz*km
Expansion / Connectivity
Interfaces:
1 x Ethernet 10GBase-SR - LC multi-mode x 2
Compatible Slots:
1 x SFP+
Physical Characteristics
Product Dimensions & Weight
Width: 0.54 inch (1.38 cm)
Height: 0.47 inch (1.19 cm)
Depth: 2.19 inch (5.57 cm)
Weight: 0.04 lbs (0.02 kg)
