Supermicro E300-8D Barebone Intel Xeon D-1518, 4 DIMM, 1x 2.5" fixed drive bay, 1x M.2 PCI-E, 2x 10G SFP+, 6x GbE LAN, DC PSU

Supermicro E300-8D Barebone Intel Xeon D-1518, 4 DIMM, 1x 2.5" fixed drive bay, 1x M.2 PCI-E, 2x 10G...

  • Brand: Supermicro
  • MPN: SYS-E300-8D
  • Part #: SVRSPM30004
  • UPC:672042242344
  • Server Type:Barebone
  • CPU Sockets:1
  • CPU Physical Cores:4
  • DIMM Slots:4
  • System Memory:None
  • RAID Support:RAID 0,1,5,10
  • 2.5" Hot swap Bays:None
  • 3.5" Hot swap Bays:None
PB Tech price:PB Tech price:
$1,12086$1,28899
 +GST  inc GST

Store Pickup: Select your store to check availability
Delivery: Order now and it ships today
When will I receive it?
Add To Compare

Pay only $577.66 and then three easy payments of $250.00 per fortnight*

Oxipay lets you spread the cost of your purchase over 4 fortnightly payments.

Click the button below or select Oxipay as your payment method during the checkout process.

If you do not have an Oxipay account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Oxipay

Six easy payments of $221.28 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Finance from $11.74 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Repayments shown above are indicitive only and may vary. Ts and Cs and lending criteria apply.
Learn more about Finance Now

No payments or interest for 12 months available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email finance@pbtech.co.nz to chat with our finance team.

*Ts and Cs and lending criteria apply.
Learn more about Q Card

What PB Tech customers are saying about this product...See More Reviews

"Hey guys. Just purchased this. Intending on posting a better review after spending more time with the machine. Just letting everyone know this system does NOT support Load Reduced DIMM. It only..."
 Dean C. ~ 22-06-19   VERIFIED OWNER

Features

- Embedded Networking Applications
- Network Security Appliance
- FireWall Applications
- Virtualization Server

1. Intel Xeon processor D-1518, Single socket FCBGA 1667; 4-Core, 8 Threads, 35W
2. System on Chip
3. 1x 2.5" fixed drive bay with bracket (when AOC area is not occupied)
4. Up to 128GB ECC RDIMM DDR4 2133MHz or 64GB ECC/non-ECC UDIMM in 4 sockets
5. 1 PCI-E 3.0 x8 AOC slot (LP), Mini PCI-E (mSATA support), M.2 PCI-E 3.0 x4 (SATA support), M Key 2242/2280/22110
6. 2x 10G SFP+, 6 GbE LAN, and dedicated LAN for IPMI 2.0
7. VGA via BMC, 2 USB 3.0 ports
8. Passive CPU heat sink and 2x 40mm chassis fans
9. DC power adapter

Specifications

Processor
Intel Xeon processor D-1518,
2.2GHz; CPU TDP support 35W
FCBGA 1667
Cores / Cache
4 Cores, 8 Threads / 6MB

System Memory - Memory Capacity
4x DDR4 DIMM sockets
Supports up to 128GB DDR4 ECC RDIMM
Supports up to 64GB DDR4 ECC/non-ECC UDIMM

Memory Type
2133/1866/1600MHz ECC DDR4 ECC RDIMM and ECC/Non-ECC UDIMM

DIMM Sizes
32GB, 16GB, 8GB, 4GB

Memory Voltage
1.2 V

Error Detection
Corrects single-bit errors
Detects double-bit errors
(using ECC memory)

On-Board Devices - Chipset
System on Chip

SATA
SoC controller for 4 SATA3 (6Gbps) ports; RAID 0,1,5,10 RSTe

Network Controllers
Dual 10G SFP+ from D-1500 SoC
Quad 1GbE with Intel I350-AM4
Dual 1GbE with Intel I210

IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Graphics
Aspeed AST2400

USB 3.0
Intel SoC

TPM
TPM 2.0 header

Input / Output - SATA
4 SATA3 (6Gbps) ports

LAN
2 10G SFP+ LAN ports
6 1GbE LAN ports
1 Dedicated IPMI LAN port

USB
2 USB 3.0 ports (rear)

Display
1 VGA port

DOM
2 SuperDOM (Disk on Module) power connectors

TPM
TPM 2.0 header

Chassis Form Factor
Mini-1U

Model
CSE-E300

Dimensions
Width
10" (254mm) / 15" (381mm) - pkg.
Height
1.7" (43mm) / 10.87" (276mm) - pkg.
Depth
8.9" (226mm) / 5.59" (142mm) - pkg.

Weight
Gross Weight: 7.5 lbs (3.4 kg)
Net Weight: 3.45 lbs (1.56 kg)

Available Colors
Black

Front Panel - Buttons
Power On/Off button

LEDs
Power LED (Hard drive activity LED)

Expansion Slots - PCI-Express
1 PCI-E 3.0 x8 slots

M.2
Interface: PCI-E 3.0 x4
Form Factor: M Key 2242/2280/22110
Support SATA devices

Mini PCI-E
Interface: PCI-E 2.0 x1
Support mSATA

Drive Bays - Internal
1x 2.5" fixed drive bay with bracket (when AOC area is not occupied)

System Cooling - Fans
Passive CPU heat sink and max. 3x 40mm chassis fans

Power Supply
DC Power Adapter

System BIOS - BIOS Type
128Mb SPI Flash with AMI BIOS

BIOS Features
PCI 3.0
ACPI 5.0
USB Keyboard support
Hardware BIOS Virus protection
SMBIOS 2.8
UEFI 2.4
RTC (Real Time Clock) Wakeup

Management - Software
Intel Node Manager
IPMI 2.0
KVM with dedicated LAN
NMI
SUM
SuperDoctor 5
Watch Dog

Power Configurations
ACPI Power Management
+12V DC Power Input
Control of power-on for recovery from AC power loss
CPU thermal trip support for processor protection
M.2 NGFF connector, Node Manager Support, SDDC, System level control, UID, WOL

Fan
Fans with tachometer status monitoring
Status monitor for speed control
Low noise fan speed control
Pulse Width Modulated (PWM) fan connectors

Operating Environment / Compliance
RoHS Compliant

Operating Temperature
0°C to 40°C (32°F to 104°F)

Non-operating Temperature
-40°C to 70°C (-40°F to 158°F)

Operating Relative Humidity
8% to 90% (non-condensing)

Non-operating Relative Humidity
5% to 95% (non-condensing

Manufacturer Part No: SYS-E300-8D Brand: Supermicro Product Type: -
UPC 672042242344 Product Family: E300-8D Barebone Shipping Weight: 3.401 kg
PB Part No: SVRSPM30004 Product Model: -

Warranty: 36 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

5 out of 5 StarsBased on 1 Reviews

5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Star
0

Filter Results

Do you own this product?

Write a review and go into the draw to win great prizes each month! Learn more WRITE A REVIEW
Displaying 1 - 1 of 1 reviews
Dean C.
VERIFIED OWNER

Great so far

22 June 2019
Hey guys. Just purchased this. Intending on posting a better review after spending more time with the machine. Just letting everyone know this system does NOT support Load Reduced DIMM. It only supports DDR4 ECC RDIMM or ECC/non-ECC UDIMM. LRDimm has the same physical bus connector and same voltage but is not compatible with this system. I ordered the wrong Dimm (LRDimm) by mistake and had to get an RA and pay a restocking fee because of my error. Hope this can save you the same problem :)
Did you find it helpful?
0 out of 0 users found this review helpful

Customer Questions & Answers

Want to know something about this product? Ask a question which other users may be able to answer.
Answer:
For this unit, RAM, Storage and operating system.
Answered by: PB Tech on 20 July 2017

Accessories

PB Part NoProduct NameAvailable StockPrice
SVPSPM293000Supermicro CSE-E300 Rackmount Kit
PB TECH: 6
SUPPLIER: 0
$68.69 +GST$78.99 inc GST
