Supermicro 740GP-TNRT Barebone, Pedestal, 2x LGA4189, 16 DIMM, 8x 3.5" Hot-Swap / 4x Hybrid NVMe, 2x 10G RJ-45, 6x PCIe 4.0 x16 FHFL, 1x PCIe 4.0 x8, Up to 4 GPU Support, 2x M.2, 2x 2200W Redundant Power Supplies
Out of stock
Supermicro 740GP-TNRT Barebone, Pedestal, 2x LGA4189, 16 DIMM, 8x 3.5" Hot-Swap / 4x Hybrid NVMe, 2x 10G RJ-45, 6x PCIe 4.0 x16 FHFL, 1x PCIe 4.0 x8, Up to 4 GPU Support, 2x M.2, 2x 2200W Redundant Power Supplies
- Brand: Supermicro
- MPN: SYS-740GP-TNRT
- Part #: SVRSPM740103
- UPC: 672042424016
- Brand: Supermicro
- MPN: SYS-740GP-TNRT
- Part #: SVRSPM740103
- UPC: 672042424016
Features
Specifications
Reviews
Delivery & Pick-up
Delivery Estimates
The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-4 working days.
Next Day Delivery
Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.
Same Day Delivery
Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security & Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
1 Hour Store Pick-up / Click & Collect
You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.
Overseas Shipments
PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Related Promotions
Popular Servers
HPE ProLiant ML350 Gen11 with Intel Xeon-S 4410Y 12C/24T, 32 GB...
Supermicro 740GP-TNRT Barebone, Pedestal, 2x LGA4189, 16 DIMM, 8x 3.5" Hot-Swap / 4x Hybrid NVMe, 2x 10G RJ-45, 6x PCIe 4.0 x16 FHFL, 1x PCIe 4.0 x8, Up to 4 GPU Support, 2x M.2, 2x 2200W Redundant Power Supplies
- Brand: Supermicro
- MPN: SYS-740GP-TNRT
- Part #: SVRSPM740103
- UPC:672042424016
Product URL: https://www.pbtech.co.nz/product/SVRSPM740103/Supermicro-740GP-TNRT-Barebone-Pedestal-2x-LGA4189
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
Key Features
- Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
- Intel® C621A Chipset
- 16 DIMM Slots;
Up to 4TB DRAM;
- Up to 4TB Intel® Optane™ Persistent Memory (up to 6TB with DRAM) ;
3200/2933/2666 ECC DDR4 LRDIMM;RDIMM;
Intel® Optane™ Persistent Memory 200 series
- 1 PCI-E 4.0 x8 LP
4 PCI-E 4.0 x16 (double-width) slots, 2 PCI-E 4.0 x16 (single-width) slots,
- 2 M.2 NVMe or SATA for boot drive only
Total 8x 3.5" Hot-swap drive bays
Up to 8 NVMe drives (4 NVMe drives supported by default)
- 4 Removable heavy duty fans w/ Optimal Fan Speed Control
- 2x 2200W redundant Titanium level power supplies
Specifications
Motherboard
Model
Super X12DPG-QT6
Processor
CPU
Dual Socket P+ (LGA-4189)
3rd Gen Intel® Xeon® Scalable processors
Support CPU TDP 270W
Cores
Up to 40C/80T; Up to 60MB Cache
GPU
Supported GPU
NVIDIA A100,A40, and RTX A6000
CPU-GPU Interconnect
PCI-E 4.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect
PCI-E
System Memory
Memory
Memory Capacity: 16 DIMM slots
Up to 4TB: 16x 256 GB DRAM
Up to 6TB: 8x 512 GB PMem
Memory Type: 3200/2933/2666MHz ECC DDR4 RDIMM/LRDIMM
Intel® Optane™ persistent memory 200 series
Memory Voltage
1.2 V
Error Detection
ECC
On-Board Devices
SATA
SATA3 (6Gbps); RAID 0/1/5/10 support
Chipset
Intel® C621A
Network Connectivity
2x 10GbE BaseT port(s)
IPMI
Support for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output
Video
1 VGA port(s)
System BIOS
BIOS Type
AMI 32MB SPI Flash EEPROM
Management
Software
OOB Management Package (SFT-OOB-LIC )
Redfish API
IPMI 2.0
SSM
Intel® Node Manager
SPM
KVM with dedicated LAN
SUM
NMI
Watch Dog
SuperDoctor® 5
Power Configurations
ACPI Power Management
Power-on mode for AC power recovery
PC Health Monitoring
CPU
7 +1 Phase-switching voltage regulator
Monitors for CPU Cores, Chipset Voltages, Memory
FAN
Fans with tachometer monitoring
Pulse Width Modulated (PWM) fan connectors
Status monitor for speed control
Temperature
Monitoring for CPU and chassis environment
Thermal Control for fan connectors
Chassis
Form Factor
Tower
Model
CSE-747BTS-R2K20BP
Dimensions and Weight
Height
7" (178mm)
Width
17.2" (437mm)
Depth
29" (737mm)
Package
27" (H) x 13" (W) x 38" (D)
Weight
Net Weight: 46 lbs (20.9 kg)
Gross Weight: 62 lbs (28.1 kg)
Available Color
Black Front & Silver Body
Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Hard drive activity LED
Network activity LEDs
Power status LED
System Overheat & Power Fail LED
Expansion Slots
PCI-Express (PCI-E)
Slot 1: PCI-E 4.0 x16 FHFL
Slot 2: PCI-E 4.0 x16 FHFL
Slot 3: PCI-E 4.0 x16 FHFL
Slot 4: PCI-E 4.0 x16 FHFL
Slot 5: PCI-E 4.0 x16 LP
Slot 6: PCI-E 4.0 x16 LP
Slot 7: PCI-E 4.0 x8 LP
Drive Bays / Storage
Hot-swap
8x 3.5" hot-swap NVMe/SATA/SAS Support drive bays (4x 2.5" NVMe dedicated)
M.2
2 M.2 NVMe OR 2 M.2 SATA3
System Cooling
Fans
4 heavy duty fans with optimal fan speed control
Power Supply
Type
2x 2200W Redundant Power Supplies, Titanium Level
Dimension
(W x H x L)
76 x 40 x 336 mm
AC Input
1200W: 100-127Vac / 50-60Hz
2200W: 200-240Vac / 50-60Hz
+12V
Max: 100A / Min: 0A (100Vac-127Vac)
Max: 183.3A / Min: 0A (200Vac-240Vac)
5V SB
Max: 1A / Min: 0A
Output Type
Backplanes (gold finger)
Certification
Titanium Level94%+ Titanium Level
Operating Environment
Environmental Spec.
Operating Temperature:
10°C ~ 35°C (50°F ~ 95°F)
Non-operating Temperature:
-40°C to 60°C (-40°F to 140°F)
Operating Relative Humidity:
8% to 90% (non-condensing)
Non-operating Relative Humidity:
5% to 95% (non-condensing)
