Ubiquiti UniFi USW-Flex-2.5G-5 5-Port 2.5G L2 Managed Switch - 2.5GbE x5
Ubiquiti UniFi USW-Flex-2.5G-5 5-Port 2.5G L2 Managed Switch - 2.5GbE x5
- Brand: Ubiquiti
- MPN: USW-Flex-2.5G-5
- Part #: SWHUBI10565
- UPC: 810084695944
Select your store to check availability
What PB Tech customers are saying about this product...
See More Reviews"Good for when you're using the express or express 7 with just 1 LAN port on it, matches the express 7's 2.5gbe. While not being super expensive"
"The small for factor makes it perfect as a desk extension fr ...view more"
"It just works, not sure why BrendanG6 has problems with port 4 & 5, maybe a setup issue or a faulty unit, I can confirm ALL 5 ports work together with or without vlans"
COMBO DEALS: Buy Together and SAVE!
Ubiquiti U-POE-at 30W 802.3AT PoE Injector
$30.96 +GST
$35.60
Cruxtec Cat6 Ethernet Cable - 2m - White
$4.51 +GST
$5.19
Features
Flex Mini 2.5G
Compact, 5-port 2.5G switch that can be powered with PoE or a USB-C adapter.
- (4) 2.5 GbE ports
- (1) 2.5 GbE PoE input port for power
- Optional powering with included 5V, 1A USB-C adapter
Specifications
Reviews
Do you own this product?
Ok unit for hyperfiber extention but......
Its not a bad little unit for those on 2gbit hyper fiber that need to add in a few more devices.
Simply plug it in and it works.
But heres the real kicker. It says 5 port but you can only use 4 ports at once on it.
Port4 and POE Port 5 are tied together data wise so you can only use 1 of those two ports at a time.
If you have something in port 4 then port 5 will not transfer data until you unplug port 4.
So really it should be advertised as 4 port with a POE optional port.
Solid Utility Switch
Good for when you're using the express or express 7 with just 1 LAN port on it, matches the express 7's 2.5gbe. While not being super expensive
Excellent build quality and an affordable price
The small for factor makes it perfect as a desk extension from your main router.
The build quality is excellent. It looks and feels premium without the matching price tag.
Powered over POE reducing the footprint makes this product a no brainer for those wanting to make the most of hyper fibre.
Works as it should
It just works, not sure why BrendanG6 has problems with port 4 & 5, maybe a setup issue or a faulty unit, I can confirm ALL 5 ports work together with or without vlans
good switch
a much needed speed boost from the 1GB models
Delivery & Pick-up
Delivery Estimates
The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-4 working days.
Next Day Delivery
Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.
Same Day Delivery
Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security & Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
1 Hour Store Pick-up / Click & Collect
You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.
Overseas Shipments
PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Switches
Ubiquiti UniFi USW-Flex-Mini 5-Port Gigabit L2 Managed Switch -...
TP-Link TL-SG1005D 5-Port Gigabit Desktop Switch
TP-Link TL-SG105 5-Port 10/100/1000Mbps Desktop Switch
TP-Link TL-SG108PE 8-Port Gigabit Easy Smart PoE Switch with 4...
Ubiquiti UniFi USW-Lite-8-POE 8-Port Gigabit L2 Managed PoE...
Ubiquiti UniFi USW-Flex-2.5G-5 5-Port 2.5G L2 Managed Switch - 2.5GbE x5
- Brand: Ubiquiti
- MPN: USW-Flex-2.5G-5
- Part #: SWHUBI10565
- UPC:810084695944
Product URL: https://www.pbtech.co.nz/product/SWHUBI10565/Ubiquiti-UniFi-Switch-USW-Flex-25G-5-Flex-Mini-25G
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 1 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 1 | |
| Auckland - Newmarket | 0 | |
| Auckland - Westgate | 1 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 2 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 4 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 4 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
Flex Mini 2.5G
Compact, 5-port 2.5G switch that can be powered with PoE or a USB-C adapter.
- (4) 2.5 GbE ports
- (1) 2.5 GbE PoE input port for power
- Optional powering with included 5V, 1A USB-C adapter
Specifications
Mechanical
Dimensions
117.1 x 90 x 21.2 mm (4.6 x 3.5 x 0.8")
Weight
206 g (7.3 oz)
Enclosure material
Polycarbonate
Hardware
Management interface
Ethernet In-Band
Networking interface
(5) 1/2.5 GbE RJ45 ports
Total non-blocking throughput
12.5 Gbps
Switching capacity
25 Gbps
Forwarding rate
18.6 Mpps
Power method
(1) AC power adapter, 5V DC, 1A
(1) PoE (PairA 1, 2+; 3, 6-)(PairB 4, 5+; 7, 8-)
Power supply
External AC/DC adapter
UniFi PoE switch
Supported voltage range
AC/DC input: 5V DC
PoE input: 44-57V DC
Max. power consumption
AC/DC input: 5W
PoE input: 6.4W
Button
Factory reset
Ambient operating temperature
-20 to 45° C (-4 to 113° F)
Ambient operating humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
Switching Features
Layer 2 features
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Port mirroring
Multicast / broadcast rate limiting
Flow control
Jumbo frames
Egress rate limit
LEDs
System
(1) Blue/white: power
Blinking white: bootup in progress
Blinking blue: firmware upgrading
Steady white: factory defaults; unit is awaiting adoption
Steady blue: unit is adopted
Ethernet
(5) Green: link/activity
Application Requirements
UniFi Network
Version 8.4.62 and later
