Winmate M101EK 4G, 128GB Win 10 IoT 10.1" Rugged Tablet WIFI 1920x1200 IPS LED, P-Cap Touch, Intel Celeron N6211, IP65, 5900Mah Battery Dual Camera Design: 8MP rear camera/2MP Webcam

PB Tech price
PB Tech price
$ 2,038 .64
 +GST
$ 2,344 .44
 inc GST

Out of stock

Winmate M101EK 4G, 128GB Win 10 IoT 10.1" Rugged Tablet WIFI 1920x1200 IPS LED, P-Cap Touch, Intel Celeron N6211, IP65, 5900Mah Battery Dual Camera Design: 8MP rear camera/2MP Webcam

  • Brand: Winmate
  • MPN: M101EK
  • Part #: TABWMAM101EK
  • UPC:
PB Tech price
$ 2,038 .64 $ 2,344 .44
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?

Features

10.1" Windows Rugged Tablet PC with Intel® Celeron® N6211

- Intel® Elkhart Lake Celeron® N6211 Processor

- 10.1" 1920 x 1200 IPS LED Panel with direct optical bonding

- IP65 water and dust proof with MIL-STD-810H rugged housing

- Low power consumption with fanless design

- Removable battery with hot-swap function for all day productivity

- Sunlight readable with antiglare solution USB Type-C port supports power delivery 20V In

- Integrated 4G/5G Wireless WWAN (Optional)

Powerful Computing Performance

With a fanless cooling system powered by an Intel® processor, M101EK offers stable performance for multi-tasks in rigorous conditions. It supports Windows® IoT Enterprise operating system to fulfill increasing industrial applications requirements and provide an alternative solution for those between general consumer-grade and extremely rugged solutions.

On Field Communication Reliability

The M101EK lightweight tablet offers the latest wired and wireless connection options for faster and improved reliability in dense deployments. Bring a level-up communication with no delay.

Compact, Slim, Yet Rugged

M101EK rugged tablet is designed sleek, lightweight, IP65 waterproof sealed, and passed the Defence-standard protection to survive all challenging environmental conditions. M101EK is designed genuinely for mobile workers and keepers who always worry about accidental damage.

Optimal Screen Interactivity in the Field

M101EK has 10.1 inches screen supported with the stylus, glove, and wet-touch modes, also integrated with an IPS 800-nits screen for clear visibility and operation comfort whatever the weather and locations are.

Specifications

Display

Size

10.1 inches

Resolution

1920x1200

Type

Projected Capacitive Multi Touch

Panel Brightness

800.0 nits

Contrast Ratio

800:1

View Angles

85,85,85,85

Bonding

Optical Bonding for Sunlight Viewability

Viewability

Anti-Glare touch treatment

System Specification

Processor

Intel Celeron N6211 @1.20 GHz (up to 3.00 GHz)

Memory

4GB LPDDR4

Storage

128GB SSD

Smart Card Reader

Add-on Smart Card Reader (Optional)

Security

Trusted Platform Module (TPM) 2.0
Kensington Lock

Operating System

Windows 10 IoT Enterprise LTSC (64 bit)

WLAN

Support

BT

Support

WWAN

4G (Optional)
5G (Optional)

GNSS

GPS, GLONASS, Galileo, BeiDou

RFID

HF RFID 13.56 MHz reader (Optional)
add-on UHF RFID Reader (Optional)

Sensors

Light sensor/ G-sensor / Gyro

Camera

Front Camera

2MP Front Camera

Rear Camera

8MP Rear Camera with auto-focus and LED light

Mechanical

Dimension

271.9 x 197.3 x 19.5 mm

Weight

1.2 kg (2.65 lbs) with standard battery,
1.4 kg (3.1 lbs) with optional high capacity battery

Cooling System

Fanless design

IO Ports

USB Port

1 x USB 3.0 (Type A), 1 x USB 3.0 (Type-C support Power Delivery 20V In)

Video

1 x Micro HDMI Output (Optional)

Audio

1 x Audio combo 3.5mm audio combo jack (Mic in or Line Out)
Dual Digital Mic With Noise Cancellation
Dual Speaker

SD Card Slot

1 x Micro SD Card slot (Support SDXC)

SIM Card Slot

1 x SIM card slot

Expansion Port

1 x Expansion connector (Optional)

Indicator

4x LED Indicator for Power, Battery, HDD, RF status

Docking Connector

1 x 19-pin docking connector

Environment

Operating Humidity

10% to 90% RH, non-condensing

Operating Temperature

-20°C to 60°C

Storage Temperature

-30°C to 70°C (-22°F to 158°F)

Shock

MIL-STD-810G Method 516.6 Procedure I

Vibration

MIL-STD-810G Method 514.6 Procedure I

Drop

MIL-STD-810G Method 516.6, 4 ft

IP rating

IP65

Certification

Certification

CE, FCC, UL, PTCRB, Verizon

Control

Button

1 x Power, 1 x Home, 2 x Volume,
2 x Programmable Function Keys

Security Function

SOTI MobiControl

SOTI MobiControl Compliance

Kensington Lock

Kensington Lock Support

Accessory

Accessory

Adapter and Power Cord
Capacitive Stylus
Standard Battery

Optional Accessory

Desk Dock (Optional)
Vehicle Dock (without VGA output) (Optional)
Vehicle Cradle (Optional)
Battery Charger (Optional)
Smart Card Reader (Optional)
High Capacity Battery (Optional)
Hand Strap (Optional)
VESA Mount Kit (Optional)
Shoulder Strap (Optional)
Carry Bag (Optional)
Vehicle Charger (Optional)

Barcode Scanner

Barcode Scanner

1D/2D barcode reader (Optional)

Power

Battery

Hot-swappable 7.7V, typ. 5900 mAh Li-Polymer Battery (2S1P)
7.4V, typ. 10280 mAh Li-Polymer Battery (2S2P, optional)

Battery Operating Time

Standard. Battery: 9 hours
High Capacity Battery: 16 hours

Power Rating

19V DC

Adapter

100-240V, 50-60Hz / 19V DC

Manufacturer Part No:
M101EK
Brand:
Product Type:
10.1" Rugged Tablet WIFI
UPC
-
Product Family:
M101EK
Shipping Weight:
2.1 kg
PB Part No:
TABWMAM101EK
Product Model:
4G, 128GB Win 10 IoT
Warranty: 12 months *
