Winmate M101S I5 4GB 128GB Win10IoT 10.1" Rugged Tablet WIFI IP65, 1920x1200 Touch Panel, Hot-Swappable Battery Design ,Dual Camera 8MP/2MP

PB Tech price
PB Tech price
$ 3,680 .00
 +GST
$ 4,232 .00
 inc GST

Out of stock

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

Winmate M101S I5 4GB 128GB Win10IoT 10.1" Rugged Tablet WIFI IP65, 1920x1200 Touch Panel, Hot-Swappable Battery Design ,Dual Camera 8MP/2MP

  • Brand: Winmate
  • MPN: M101S
  • Part #: TABWMAM101S
  • UPC:
PB Tech price
$ 3,680 .00 $ 4,232 .00
 +GST  inc GST

No store stock available. See in-stock alternatives

Click & Collect: Collect unavailable
Delivery: Out of stock

Product is out of stock. View similar products in-stock at PB Tech

Features

10" Rugged Tablet

Key Features

- 10.1" 1920x1200 IPS LED Panel with P-Cap Touch
- Powerful performance with Intel® Core i5 Kaby Lake Processor
- IP65 water and dust proof
- Optional Barcode or RFID Reader
- Dual Camera Design: 8MP Main camera / 2MP Webcam
- Hot-Swappable Battery Design / Optional high capacity battery pack
- 2 Programmable function keys
- With Optical Bonding for Sunlight Readability





Specifications

Display Specifications


Size


10.1"


Brightness


800 nits(typ.)


Resolution


1920 x 1200 WUXGA


Contrast Ratio


800:1


Touch


Multi-Touch Projected Capacitive Touchscreen


Viewing Angle


85/85/85/85


Panel Viewability


Optical Bonding for Sunlight Viewability


System Specification


Processor


Intel Core i5-7200U Kaby lake 2.5GHz (turbo to 3.1GHz)


BIOS


AMI System BIOS


Memory


4GB DDR4 SDRAM((up to 8GB)


Storage


64GB solid state drive (SSD)Optional up to 512GB, up to 128GB additional storage with optional microSDXC card slot


Audio


1 x Built-in Mic with Noise Cancellation, 2 x 1W Speaker


Wireless Communication


WLAN


802.11 a/b/g/n/ac


Bluetooth


Bluetooth 5.0


WWAN


Optional 4G (LTE,HSPA+,GSM/GPRS/EDGE,EV-DO Rev A, 1xRTT) or optional 3G (HSPA+,GSM/GPRS/EDGE)


GPS


GPS, GLONASS


I/O Connectors


Right I/O Connectors


1 x Micro HDMI
1 x USB 3.0(Type A)
1 x USB 3.0 (Type C)
1 x Audio Combo connector (Mic in or Line Out)
1 x DC jack
1 x Micro SD Slot


Downside I/O Connectors


 1 x Docking Connector


In front Control


Control Button


1 x Power,
1 x Home (Win-set application),
2 x Programmable Function Key (Programmable function key configured by Hottab Utility)
(One for Barcode trigger key when with Barcode),
2 x Adjusting key for Volume or Brightness


LED indicator


Power, Battery, HDD Access, RF


Mechanical and Environment


Dimensions (W x L x H)


271.8 x 197.2 x 21 mm (10.7 x 7.76 x 0.83 inches)


Net Weight (kg)


1.25 kg (2.75 lbs) with standard battery, 1.4 kg (3.2 lbs) with optional high capacity battery


Operating Temperature


-20°C to 60°C (AC mode), -10°C to 50°C (Battery mode)


Storage Temperature


-30°C to 70°C (-22°F to 158°F)


IP Proof


IP65


Operating Humidity


10% to 90% RH, non-condensing


Certifications


CE, FCC
Microsoft Azure Certified for IoT


Shock


MIL-STD-810G Method 516.6 Procedure I


Vibration


MIL-STD-810G Method 514.6 Procedure I


Drop


MIL-STD-810G Method 516.6, 4 ft to concrete*


Power Management


Power Input


12~19V DC


Battery


7.4V, typ. 5140 mAh Li-Polymer Battery (2S1P)
7.4V, typ. 10280 mAh Li-Polymer Battery (2S2P, Optional)


Adapter


100-240V, 50-60Hz, 19V DC


Battery Operating Time Std. Battery:


8 hours***


High Capacity Battery:


16 hours***


Product Specification


OS


Windows 10 IoT Enterprise (64 bit)


RFID


Optional HF RFID reader 13.56 MHz


Barcode


Optional 1D/2D Barcode Reader


Camera


8MP Camera with Auto-focus and LED Light at rear
2MP Camera at front side


Security


Security


Password security for user and hard disk lock
Trusted platform module (TPM) V2.0
Kensington Lock


Mobile Device Management


SOTI Mobicontrol compatible


Datasheet


http://download.winmate.com.tw/$Productfile/TabletPC/13_0263/M101S.pdf


User Guide


https://dc.winmate.com.tw/ProductDownFile/TabletPC/Rugged_Windows_Tablet_M101S_User_Guide_V110.pdf

Manufacturer Part No:
M101S
Brand:
Product Type:
10.1" Rugged Tablet WIFI
UPC
-
Product Family:
M101S
Shipping Weight:
1.87 kg
PB Part No:
TABWMAM101S
Product Model:
I5 4GB 128GB Win10IoT
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
