POE Texas 8-Port Gigabit Passive PoE Switch 7 PoE Ports and 1 Uplink

PB Tech price
PB Tech price
$ 152 .17
 +GST
$ 175 .00
 inc GST
$152.17  +GST
$175.00

POE Texas 8-Port Gigabit Passive PoE Switch 7 PoE Ports and 1 Uplink

  • Brand: POE Texas
  • MPN: GPOES-8-7AB
  • Part #: UNC001002974
  • UPC:
PB Tech price
$ 152 .17 $ 175 .00
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 26 Sep When will I receive it?
$152.17  +GST
$175.00
  • Brand: POE Texas
  • MPN: GPOES-8-7AB
  • Part #: UNC001002974
  • UPC:

Features

  • 8 port switch with 7 passive PoE ports
  • 10/100/1000 Gigabit Ethernet capability
  • Use to power 24 or 48 volt PoE devices
  • Unamanaged for easy install with VLAN transparancy
  • Passive "Always On" Power over Ethernet for versatility
  • Can be powered via another PoE switch or PoE injector on the uplink port
  • PoE repeater - Daisy-chain in series to extend Gigabit data up to 200m

Instantly add Passive PoE to your LAN
48v or 24v power supply required
7 PoE ports allow you to power multiple devices

Offers passive PoE mode B via dip switch for Ubiquiti and Mikrotik devices

Add 7 ports of PoE to your network. Run a single Ethernet cable up to 100 meters from your existing modem or router and connect to the switch to provide power and data to as many as 7 devices. Or run two GPOES-8-7AB switches in a series to extend your data reach to more than 200m.

Passive PoE means versatility. A Passive PoE injector always delivers the same voltage as its power source.

Choose PoE mode A or B. For 24V passive it should be set to mode B via dip switch.

Plug and Play - Unmanaged PoE switch with transparent VLAN throughput
Delivers passive "always on" power to the end device
Select Mode A, Mode B or Data only per port for compatibility options

Data + PoE Ports : 7
Data only Ports : 1
Data Rate : Gigabit
Dimensions : 19.05 x 8.255 x 3.175 cm
Operating Humidity : 5% to 90%
Operating Temperature Range : -10 - 60C
Output Voltage : 24 Volts
PoE Method : Passive
PoE Mode/Pinout : Mode A (-1,2 +3,6) / Mode B (+4,5 -7,8)
Power Input : 2.1 x 5.5 mm DC or PoE on uplink port

Specifications

Manufacturer Part No:
GPOES-8-7AB
Brand:
POE Texas
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
UNC001002974
Product Model:
-
Warranty: 12 months *
