APC Easy UPS 3S 10 kVA 400 V 3:3 UPS for internal batteries , 1 year on-site repair or replace with factory authorized Start-Up

PB Tech price
PB Tech price
$ 8,664 .06
 +GST
$ 9,963 .67
 inc GST

Out of stock

APC Easy UPS 3S 10 kVA 400 V 3:3 UPS for internal batteries , 1 year on-site repair or replace with factory authorized Start-Up

  • Brand: APC
  • MPN: E3SUPS10KHB
  • Part #: UPSAPC1001697
  • UPC:
PB Tech price
$ 8,664 .06 $ 9,963 .67
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?
  • Brand: APC
  • MPN: E3SUPS10KHB
  • Part #: UPSAPC1001697
  • UPC:

Capacity (VA)

3000VA - 10000VA

Capacity (Watts)

>1000W

Features



Easy UPS 3S 10kVA 400V 3:3 UPS for internal batteries

High-efficiency 3-phase UPS that features advanced product features, competitive specifications, and robust electrical design, making business continuity easy in the data center or electrical room. This is an exceptionally easy to install, operate, maintain, and service 10 kVA UPS, ideal for small and medium businesses. Includes dust filter and conformance-coated boards for harsh environments. This UPS is for internal batteries, but is supplied without batteries, so you can easily customize the battery runtime.

- Easy UPS 3S is easy to install and start up
- Parallel up to 4 UPSs for capacity or redundancy
- Extended runtime options available
- EcoStruxure IT: Enables resilient, secure, and sustainable IT environments
- Environmental performance of the product

Specifications

Main

Main Input Voltage

400 V 3 phases

Product Or Component

Type Uninterruptible power supply (UPS)

Other Input Voltage

380 V
415 V

Main Output Voltage

400 V 3 phases

Other Output Voltage

380 V
415 V

Rated Power In W

10 kW

Rated Power In Va

10 kVA

Batteries & Runtime

Battery Type

VRLA

Battery Voltage

240 V

Maximum Short-Circuit Current

10 kA

Number Of Battery Filled Slots

0

Number Of Battery Free Slots

3

Discharge Battery Voltage

+/- 198 V DC

Physical

Colour

 White (RAL 9003)

Height

140 cm

Width

38 cm

Depth

92.8 cm

Net Weight

112 kg

Usb Compatible

Yes

Input

Maximum Input Current

18 A

Input Harmonic Distortion

Less than 3 % for full load

Load Power Factor

0.9 leading to 0.9 lagging

Input Power Factor At Full Load

0.99

Input Voltage Limits

304...477 V

Network Frequency

45...65 Hz

Output

Maximum Configurable Power In  Va

10 kVA

Maximum Configurable Power In W

10 kW

Output Frequency

50 Hz sync to mains
60 Hz sync to mains

Harmonic Distortion

Less than 3 %

Output Harmonic Distortion

< 3% linear load

Output Overload Operation

130-150% for 1 minute and 125-130% for 10 minutes

Output Voltage Tolerance

+/- 1.5 %

Ups Type

Double conversion online

Conformance

Product Certifications

CE
EAC
RCM

Environmental

Ambient Air Temperature For Operation

0…40 °C

Relative Humidity

0…95 % non-condensing

Operating Altitude

0...3333 ft

Ambient Air Temperature For Storage

-15…40 °C

Storage Relative Humidity

0…95 % non-condensing

Storage Altitude

0.00…15240.00 m

Acoustic Level

60 dBA

Heat Dissipation

516 W

Ip Degree Of Protection

IP20

Packing Units

Unit Type Of Package 1

PCE

Number Of Units In Package 1

1

Package 1 Height

164 cm

Package 1 Width

101.4 cm

Package 1 Length

56.3 cm

Package 1 Weight

145 kg

Manufacturer Part No:
E3SUPS10KHB
Brand:
APC
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
40 kg
PB Part No:
UPSAPC1001697
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
