APC SMART-UPS SRT LI-ION 2200VA RM 230V

APC SMART-UPS SRT LI-ION 2200VA RM 230V
PB Tech price: PB Tech price:

Generating Print Page

APC SMART-UPS SRT LI-ION 2200VA RM 230V

Part #: UPSAPC2302200
  • Brand: APC
  • MPN: SRTL2200RMXLI
  • Part #: UPSAPC2302200
  • UPC:
  • Capacity (VA): 2200VA
  • Capacity (Watts): 1980W
  • Form Factor: Rack/Tower
  • Outlets: 8
  • Recharge Time: 4 Hours
  • Run Time (Full Load): 14 Minutes
  • Run Time (Half Load): 29 Minutes
  • Transfer Time: Not Specified
  • View more

Features

High density, double-conversion on-line power protection with scalable runtime

Includes: CD with software, Comms cable, Documentation CD, Installation guide, Removable support feet, USB cable, Warranty card

Battery failure notification

Provides early-warning fault analysis on batteries enabling timely preventive maintenance

ECO Mode

Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection

LCD graphics display

Text and mimic diagrams that display modes of operation, system parameters and alarms.

Rack/Tower convertible

Protects the initial investment in the UPS when migrating from tower to rack-mount environment.


APC Warranty Info

All APC UPS’s have a 3 year warranty however the batteries on these UPS’s are only supported for 2 years. You can check the factory warranty of an APC UPS by following this link: http://www.apc.com/site/support/nz/en/warranty-services

Specifications

Output

Output power capacity

1.98kWatts / 2.2kVA

Max Configurable Power (Watts)

1.98kWatts / 2.2kVA

Nominal Output Voltage

230V

Output Voltage Distortion

Less than 2%

Output Frequency (sync to mains)

50/60Hz +/- 3 Hz

Other Output Voltages

220, 240

Load Crest Factor

3 : 1

Topology

Double Conversion Online

Waveform type

Sine wave

Output Connections

(2) IEC 320 C19 (Battery Backup)
(6) IEC 320 C13 (Battery Backup)

Bypass

Built-in Bypass

Input

Nominal Input Voltage

230V

Input frequency

40 - 70 Hz (auto sensing)

Input Connections

British BS1363A, IEC-320 C20, Schuko CEE 7/EU1-16P

Cord Length

1.83meters

Input voltage range for main operations

50-150 (40% Load), 80 - 150V

Number of Power Cords

1

Other Input Voltages

220, 240

Batteries & Runtime

Battery type

Li-ion

Typical recharge time

4hour(s)

Expected Battery Life (years)

5 - 10

Extendable Run Time

1

Battery Volt-Amp-Hour Capacity

621

Extended Run Options

APC-SMART-UPS-SRT-LI-ION-2200VA-RM-230V-NETWORK-CARD

Runtime

Full laod (1980W) - 14.3 min
Half load (940W) - 29.4min

Communications & Management

Interface Port(s)

RJ-45 Serial, Smart-Slot, USB

Pre-Installed SmartSlot™ Cards

AP9631

Control panel

Multi-function LCD status and control console

Audible Alarm

Audible and visible alarms prioritized by severity

Emergency Power Off (EPO)

Yes

Surge Protection and Filtering

Surge energy rating

432Joules

Physical

Maximum Height

85MM, 8.5CM

Maximum Width

432MM, 43.2CM

Maximum Depth

611MM, 61.1CM

Rack Height

3U

Net Weight

30.5KG

Shipping weight

41.4KG

Shipping Height

245MM, 24.5CM

Shipping Width

600MM, 60.0CM

Shipping Depth

870MM, 87.0CM

Color

Black

Units per Pallet

12.0

Environmental

Operating Temperature

0 - 40 °C

Operating Relative Humidity

0 - 95 (non-condensing) %

Operating Elevation

0-3000meters

Storage Temperature

-20 - 50 °C

Storage Relative Humidity

0 - 95 (non-condensing) %

Storage Elevation

0-15000meters

Audible noise at 1 meter from surface of unit

50.0dBA

Online thermal dissipation

317.0BTU/hr

Protection Class

IP 20

Conformance

Approvals

CE, EAC

Standard warranty

5 year repair or replace

Sustainable Offer Status

RoHS

Compliant

REACH

REACH: Contains No SVHCs

Battery Directive

Compliant

Manufacturer Part No:
SRTL2200RMXLI
Brand:
APC
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
40 kg
PB Part No:
UPSAPC2302200
Product Model:
-
Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
