ASUS IoT PE200U I3, 8G Dual-LAN, Multiple COM with mini PCIe slot, DP, HDMI, 12-24V DC
Out of stock
ASUS IoT PE200U I3, 8G Dual-LAN, Multiple COM with mini PCIe slot, DP, HDMI, 12-24V DC
- Brand: ASUS IoT
- MPN: 90ME00N3-M0UCY0
- Part #: WKSASUPE200UI3
- UPC: 192876854587
- Brand: ASUS IoT
- MPN: 90ME00N3-M0UCY0
- Part #: WKSASUPE200UI3
- UPC: 192876854587
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Computers





ASUS IoT PE200U I3, 8G Dual-LAN, Multiple COM with mini PCIe slot, DP, HDMI, 12-24V DC
- Brand: ASUS IoT
- MPN: 90ME00N3-M0UCY0
- Part #: WKSASUPE200UI3
- UPC:192876854587

Product URL: https://www.pbtech.co.nz/product/WKSASUPE200UI3/ASUS-IoT-PE200U-I3-8G-Dual-LAN-Multiple-COM-with-m
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
PE200U - Intel® Core™ i3 Processor Intelligent Edge Computer with mini PCIe slot,DDR4 2400MHz, DP, HDMI, Dual-LAN, Multiple COM, 12-24V DC
- Achieve high performance with full CPU utilization and fan-less thermal
- Wide range of power inputs (12~24V) and operating temperatures (-20°~60°)
- Diverse I/O interface and expansion options for multiple markets
- World-class after-sales service and long-term availability guarantee
- A high-quality, TCO-optimized solution for AIoT computing
- Supports I2C, SMBus and GPIO
ASUS PE200U is an Intelligent Edge Computer with a high-quality, TCO-optimized solution for AIoT computing. PE200U includes up to 6 COM ports(2 x RS-232/422/485) and supports dual display configuration by multiple interface: HDMI/DP and integrated CPU. PE200U is designed for high performance and silent operation in harsh environment. It's capable of achieving full CPU utilization while being cooled by a fanless thermal solution.
ASUS Edge Computer offers enhanced features to ensure optimal performance and the flexibility to adapt to the surrounding environment, configure easily with a wide range of power inputs (12~24V), operating temperatures (-20°~60°), diversified I/O interface and expansion for multiple vertical markets. ASUS Edge computer is built for 24/7 stability and reliability, combined with our world-class after-sales service and guaranteed long-term availability - your investment for the duration of the product lifecycle is maximized.
Frequently asked questions
Can I swap out parts and/or add/change/remove operating systems in a PB Tech PC?
We can add any part to a PC for a small fee as long as we don't need to remove an existing part for it to fit, for example adding more RAM, an extra hard drive, installing a Windows OS, or adding a graphics card to a PC without one (we can even SLI/Crossfire for you if it is compatible). We cannot change components that are part of an existing build e.g. Upgrade an existing graphics card or add a SSD with Windows installed if the PC only has a single hard drive (as the OS is already pre-installed). If you do have a specific requirement, then one of our experienced sales team will be happy to build a system that suits your needs.
Contact our WebSales team here
What parts are used in this PC?
The parts are subject to change depending on stock availability but the specifications listed in the title will always be correct. If you have specific parts you are after, one of our experienced sales team will be happy to build a system that suits your needs.
Once again, you can contact our WebSales team here
I've just purchased my first custom PC, how do I set it up?
Our short new PC setup guide shows you how to safely unbox it, and set it all up so you can get to work or start playing games.
Specifications
CPU
Intel® Core™ i3-8145U Processor (formerly Whiskey Lake-U)
Chipset
Integrated
Memory
8GB (Up to 16GB) DDR4
Expansion Slots
1 x M.2 Socket 1 with E key, type 2230 for WIFI/BT device
1 x M.2 Socket 3 with M key, type 2242 (PCIe x2 mode & SATA mode)
1 x Full-Length Mini PCIe slot with an on-board Nano-SIM socket
Storage
1 x SATA 6Gb/s connecter
1 x mSATA slot (shared with Mini PCIe)
1 x Micro SD Card slot (on-board)
Display
Multi-VGA output support :DP/HDMI ports
USB
4 x USB3.1 Gen2 Type-A ports
Serial Port
2 x RS-232/422/485
Internet
Dual RJ45 connectors (1 x Intel® I219V, 1 x Intel® I211AT)
Audio
Realtek ALC887-VD2 High Definition Audio CODEC
Internal I/O
1 x Chassis fan header
1 x Clear CMOS jumper
1 x LPC Debug header
1 x SMBus header
1 x I2C header
GPIO
1 x 8bit GPIO
BIOS
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.0, WfM 2.0, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, Last Modified Log, ErP
Watch dog timer
Yes
Power requirement
12-24V DC input
Operation Temperature
-20~60°C (w/ selected memory and storage)
Non-Operation Temperature
-40~85°C
Relative Humidity
0%~85%
Operating System Support
Windows® 10 (64-bit) / Windows® 10 IoT Enterprise / Linux
Form Factor
254 x 147 x 57 mm
