Winmate Marine PC I330EAC-ITW I5/8G/256GB/Win10 IoT 1xDVI, 1x DP, 2x RS232, 2x lan, 2x Removable 2.5" SSD drive bay,24V DC, DNVGL-CG-0339,IEC 60945 4th Edition (Test Report Available)CE / FCC,
Winmate Marine PC I330EAC-ITW I5/8G/256GB/Win10 IoT 1xDVI, 1x DP, 2x RS232, 2x lan, 2x Removable 2.5" SSD drive bay,24V DC, DNVGL-CG-0339,IEC 60945 4th Edition (Test Report Available)CE / FCC,
- Brand: Winmate
- MPN: I330EAC-ITW
- Part #: WKSWMAI330EAC01
- UPC:
- Brand: Winmate
- MPN: I330EAC-ITW
- Part #: WKSWMAI330EAC01
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Computers





Winmate Marine PC I330EAC-ITW I5/8G/256GB/Win10 IoT 1xDVI, 1x DP, 2x RS232, 2x lan, 2x Removable 2.5" SSD drive bay,24V DC, DNVGL-CG-0339,IEC 60945 4th Edition (Test Report Available)CE / FCC,
- Brand: Winmate
- MPN: I330EAC-ITW
- Part #: WKSWMAI330EAC01

Product URL: https://www.pbtech.co.nz/product/WKSWMAI330EAC01/Winmate-Marine-PC-I330EAC-ITW-I58G256GBWin10-IoT-1
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
KEY FEATURES
- Intel® Tiger Lake Core™ i5-1135G7
- RAM 4G DDR4L (Up to 32G)
- Removable 2.5" SSD drive bay
- Multi Video Output, DVI/HDMI/Display Port
- Isolation Power Protection 1.5KV
- 4 x Digital Input / 4 x Digital Output
- 8 x NMEA Port 0183
- DNVGL-CG-0339, IEC60945 Certificate
Fanless Cooling System
We use well-defined thermal analysis procedures to verify IPC systems to meet the harsh environment applications. Especially in fanless cooling design, we develop a heat-sink or heat-pipe solution to conduct the heat and the airflow for the best thermal solution. In the fan cooling system, we will analyze the system's thermal profiles before designing it to ensure the most efficient heat convection.
RS422/485 Communication with Isolation Protection
Winmate's multi-port serial cards can be equipped with various high-performance peripheral devices in field devices that use RS-232/422/485 serial communication protocol. Each interface card requires only one PCI or ISA slot to provide independent serial channels.
Frequently asked questions
Can I swap out parts and/or add/change/remove operating systems in a PB Tech PC?
We can add any part to a PC for a small fee as long as we don't need to remove an existing part for it to fit, for example adding more RAM, an extra hard drive, installing a Windows OS, or adding a graphics card to a PC without one (we can even SLI/Crossfire for you if it is compatible). We cannot change components that are part of an existing build e.g. Upgrade an existing graphics card or add a SSD with Windows installed if the PC only has a single hard drive (as the OS is already pre-installed). If you do have a specific requirement, then one of our experienced sales team will be happy to build a system that suits your needs.
Contact our WebSales team here
What parts are used in this PC?
The parts are subject to change depending on stock availability but the specifications listed in the title will always be correct. If you have specific parts you are after, one of our experienced sales team will be happy to build a system that suits your needs.
Once again, you can contact our WebSales team here
I've just purchased my first custom PC, how do I set it up?
Our short new PC setup guide shows you how to safely unbox it, and set it all up so you can get to work or start playing games.
Specifications
System Specification
Processor
Intel® Tiger Lake Core™ i5-1135G7, 2.4 GHz(turbo up to 4.2GHz)
Memory
2 x SODIMM, DDR4 2133 MHz, 4G
Storage
1 x M.2 128GB
Ethernet controller
Intel® Ethernet Controller I211-AT +
Intel® Ethernet Connection I219-LM
Operating System
Windows 10 IoT Enterprise (Optional)
Environment
Operating Humidity
5% to 95%
Operating Temperature
-15~55°C
Shock
15G,11ms duration
Vibration
0.7g@DNVGL CG-0339 (Class A)
IO Ports
USB Port
4 x USB 3.0
Serial Port
2 x RS232/422/485
LAN
2 x Giga LAN
Video
1 x DVI
1 x Display Port
1 x HDMI Output (Optional)
Audio
1 x Audio combo 3.5mm audio combo jack
Expansion Port
2 x 2.5" Removable 64GB SSD/HDD up to 512GB (Optional)
DIDO
8 x Isolated DIDO, 4 In/ 4out
NMEA
8 x NMEA 0183 Port
Mechanical
Dimension
316.44 x 206.8 x 62.1 mm
(With Mounting)
Mounting
table mount
Enclosure
Aluminum
Cooling System
Fanless Design
Power
Power Rating
24V DC In (Approval by Certificate)
9~36V DC Input Acceptable
