EKWB EK-Quantum Magnitude D-RGB sTRX4 Nickel + Acetal
Out of stock
EKWB EK-Quantum Magnitude D-RGB sTRX4 Nickel + Acetal
- Brand: EKWB
- MPN: EK-Quantum Magnitude sTRX4 D-RGB - Nickel + Acetal
- Part #: WTREKW825242
- UPC:
- Brand: EKWB
- MPN: EK-Quantum Magnitude sTRX4 D-RGB - Nickel + Acetal
- Part #: WTREKW825242
- UPC:
Features
EK-Quantum Magnitude sTRX4 - Nickel + Acetal is the newest flagship CPU water block tailor-made for AMD® Ryzen™ Threadripper™ processors. The Magnitude sTRX4, which belongs to the EK-Quantum product line, is the most complex Threadripper CPU water block on the market to date. This new lineup has no intention of succeeding or replacing their Velocity sTR4 counterparts, as the Magnitude version is a rather sophisticated alternative optimized specifically for Zen 2 based AMD Threadripper CPUs.
The award-winning, signature design truly sets the Magnitude apart, with every piece being CNC-milled from a solid piece of material. The precisely machined flat coldplate is made of nickel-plated high-grade copper and the top is made of durable black POM Acetal. The three-dimensional black-anodized aluminum mounting frame perfectly blends in with the asymmetrical shape of the Threadripper CPU socket, while making the screws a seamless part of the water block. Strong edges and chamfers root this futuristic design firmly into the EK Quantum line. Magnitude proudly bears the prestigious iF Design Award.
It is possible to rotate the Insert by 180°, thus exchanging the optimal inlet and outlet ports so that the flow direction may be reversed. Because the SP3 sockets are asymmetrical, and to prevent incorrect re-assembly, it is not possible to rotate the top, frame, or coldplate relative to the socket.
The water block implements the evolution of the patent-pending technology called TDC, or Targeted Die Cooling. This technology was first developed for the 2nd generation EK Threadripper CPU water blocks. The Magnitude now utilizes it on a more sophisticated level. The cooling engine is enlarged significantly. The coldplate is now completely flat with the 4 patches that ensure optimal contact with the IHS over CCDs creating ideal conditions for best thermal transfer. Two 0.5mm thick jet plates make sure that coolant flow is focused and turbulent over the CCDs (Core Complex Dies).
This product is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin LED connector is to be aligned with the +5V marking on the addressable RGB header. The Nickel + Acetal version uses the same high-density LED strip with a total of 44 addressable RGB diodes as the other LED-lit Magnitude water blocks, and they illuminate outwards through the milky white frame. The LED Strip must be inserted through the frame and the wire can exit the block on any of the corners for best cable routing.
Specifications
Reviews
Delivery & Pick-up
Delivery Estimates
The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-4 working days.
Next Day Delivery
Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.
Same Day Delivery
Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security & Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
1 Hour Store Pick-up / Click & Collect
You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.
Overseas Shipments
PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Related Promotions
Popular Custom Cooling Parts
Alphacool Core 1 Aurora Black For Intel LGA 1700 / LGA 1851, AMD:...
BYKSKI Acrylic 1000mm Clear 12mm ID x 16mm OD Rigid Acrylic Tube,...
Alphacool Tec Protect 2 Clear 1000ml
Alphacool NexXxoS ST30 Full Copper X-Flow 360mm - Black - 30mm...
Alphacool Core Flat Reservoir ARGB 240mm Right with VPP Apex Pump
EKWB EK-Quantum Magnitude D-RGB sTRX4 Nickel + Acetal
- Brand: EKWB
- MPN: EK-Quantum Magnitude sTRX4 D-RGB - Nickel + Acetal
- Part #: WTREKW825242
Product URL: https://www.pbtech.co.nz/product/WTREKW825242/EKWB-EK-Quantum-Magnitude-D-RGB-sTRX4-Nickel--Acet
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Newmarket | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
EK-Quantum Magnitude sTRX4 - Nickel + Acetal is the newest flagship CPU water block tailor-made for AMD® Ryzen™ Threadripper™ processors. The Magnitude sTRX4, which belongs to the EK-Quantum product line, is the most complex Threadripper CPU water block on the market to date. This new lineup has no intention of succeeding or replacing their Velocity sTR4 counterparts, as the Magnitude version is a rather sophisticated alternative optimized specifically for Zen 2 based AMD Threadripper CPUs.
The award-winning, signature design truly sets the Magnitude apart, with every piece being CNC-milled from a solid piece of material. The precisely machined flat coldplate is made of nickel-plated high-grade copper and the top is made of durable black POM Acetal. The three-dimensional black-anodized aluminum mounting frame perfectly blends in with the asymmetrical shape of the Threadripper CPU socket, while making the screws a seamless part of the water block. Strong edges and chamfers root this futuristic design firmly into the EK Quantum line. Magnitude proudly bears the prestigious iF Design Award.
It is possible to rotate the Insert by 180°, thus exchanging the optimal inlet and outlet ports so that the flow direction may be reversed. Because the SP3 sockets are asymmetrical, and to prevent incorrect re-assembly, it is not possible to rotate the top, frame, or coldplate relative to the socket.
The water block implements the evolution of the patent-pending technology called TDC, or Targeted Die Cooling. This technology was first developed for the 2nd generation EK Threadripper CPU water blocks. The Magnitude now utilizes it on a more sophisticated level. The cooling engine is enlarged significantly. The coldplate is now completely flat with the 4 patches that ensure optimal contact with the IHS over CCDs creating ideal conditions for best thermal transfer. Two 0.5mm thick jet plates make sure that coolant flow is focused and turbulent over the CCDs (Core Complex Dies).
This product is compatible with popular RGB sync technologies from all major motherboard manufacturers. The arrow marking on the 3-pin LED connector is to be aligned with the +5V marking on the addressable RGB header. The Nickel + Acetal version uses the same high-density LED strip with a total of 44 addressable RGB diodes as the other LED-lit Magnitude water blocks, and they illuminate outwards through the milky white frame. The LED Strip must be inserted through the frame and the wire can exit the block on any of the corners for best cable routing.
Specifications
CPU socket compatibility
AMD Socket sTRX4 (Socket SP3r3)
AMD Socket TR4 (Socket SP3r2)
AMD Socket SP3
AMD Socket sTR5
AMD Socket SP6
