StarTech.com 10P6G-PCIE-SATA-CARD SATA PCIe Card Controller Card 10 Ports

PB Tech price
PB Tech price
$ 207 .83
 +GST
$ 239 .00
 inc GST
$207.83  +GST
$239.00

StarTech.com 10P6G-PCIE-SATA-CARD SATA PCIe Card Controller Card 10 Ports

  • Brand: StarTech.com
  • MPN: 10P6G-PCIE-SATA-CARD
  • Part #: ADPSTT5386999
  • UPC: 065030893763
PB Tech price
$ 207 .83 $ 239 .00
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 01 Jul When will I receive it?
$207.83  +GST
$239.00

Four payments of $60.35 per fortnight*

Afterpay lets you spread the cost of your purchase over 4, interest-free, fortnightly payments.

Click the button below or select Afterpay as your payment method during the checkout process.

If you do not have a Afterpay account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.

Learn more about Afterpay

Finance from $3.14 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Weekly payments are indicative only and based on a retail price of over a loan term of months at an interest rate of % p.a. and include a monthly service fee and a establishment fee (excludes optional Payment Protection Insurance).The total amount payable over the term of the loan is . Details of finance (including weekly payments, the total amount repayable over the term of the loan, interest rate and any applicable fees) can be confirmed with a detailed quote. Full disclosure of all of the terms of your finance will also be provided to you in the Finance Now disclosure statement for your consideration prior to confirmation of your purchase. All finance is subject to Finance Now terms and conditions and approval criteria.

Learn more about Finance Now

24 months interest FREE available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email [email protected] to chat with our team.

*12 Months No Payments & No Interest (“Payment Holiday”) is available on Long Term Finance (LTF) for in-store & online purchases. Min Spend $200. Lending criteria, $50 annual Account Fee, fees, Ts&Cs apply. $55 Establishment Fee applies to your first LTF transaction, $35 Advance Fee applies to subsequent LTF transactions. Standard Interest Rate currently 28.95% p.a. applies at the end of LTF Interest Free Period. Rates and fees correct as at date of publication, subject to change. Other interest rates and fees may apply. See qcard.co.nz for full details. Credit provided by Columbus Financial Services Limited. Excludes vouchers, gift cards, software licenses, game activation codes, pre-orders, Customized-to-Order (CTO) Apple Mac, and backorders.

*See here for full T&C

  • Brand: StarTech.com
  • MPN: 10P6G-PCIE-SATA-CARD
  • Part #: ADPSTT5386999
  • UPC: 065030893763

Features

This 10-port SATA III (6Gbps) controller enables you to add 10 SATA 6Gbps Hard Drives (HDDs) or Solid State Drives (SSDs) to your computer system or server via an available PCIe x2 card slot. The card supports SATA III and PCI-Express 2.0 Specifications.

ASM1062 to Deliver 10-Port SATA 6Gbps Performance

Featuring the ASM1062 controller, this SATA card enables the connection of 10 high-performance SATA 6Gbps drives with a combined total throughput of up to 8Gbps. The SATA drives are connected via ten individual SATA ports located on the card (SATA cables sold separately).

Wide Compatibility

The controller card is widely supported across all popular operating system platforms including Windows (7,8,10, 11), macOS (10.10 and above) and Linux (2.6.32 and above). The card also supports port multiplier, giving you the ability to connect multiple drives to a single SATA port (additional hardware required, sold separately).

To further improve motherboard compatibility the card does not have a built-in RAID controller, but fully supports the use of software RAID. Plus, with support for PCIe 2.0 and SATA III Specifications this card ensures backward compatibility with previous generations (SATA I/II, PCIe 1) at lower performance.

Hassle-Free Installation

The SATA controller card features plug-and-play installation and can be installed in a full-profile or low-profile computer systems with the full-profile bracket preinstalled, and an interchangeable low-profile (half-height) bracket included. The card also supports storage software data management systems such as Storage Spaces (Microsoft), RAID Assistant (MacOS) and mdraid/mdadm (Linux), for hassle-free setup, partitioning and software RAID array building.

Specifications

Connector(s)

1 - Connector Type(s)

PCI Express x2

10 - Internal Ports

SATA (7 pin, Data)

Environmental

Operating Temperature

0°C to 85°C (32°F to 185°F)

Storage Temperature

-25°C to 85°C (-13°F to 185°F)

Humidity

20~80% RH

Hardware

Ports

10

Interface

SATA

Bus Type

PCI Express

Card Type

Standard Profile (LP bracket incl.)

Industry Standards

Serial ATA 3.0 specification - SATA I/II/III (1.5/3/6Gbps)
PCI Express Base Specification Revision 2.0

Chipset ID

ASMedia - ASM1062R

Indicators

2 - LED Indicators

Header, for drive activity LEDs

Packaging Information

Package Width

5.6 in [14.2 cm]

Package Length

6.9 in [17.5 cm]

Package Height

1.2 in [3.0 cm]

Shipping (Package) Weight

3.9 oz [111.0 g]

Performance

Maximum Data Transfer Rate

6 Gbps

TRIM Support

Yes

4Kn Support

Yes

S.M.A.R.T. Support

Yes

Type and Rate

SATA III (6 Gbps)

Port Multiplier

Yes

Bootable

Yes

Hardware Raid Supported

Yes

Supported RAID Modes

RAID 0 (Striped Disks)
RAID 1 (Mirrored Disks)
BIG (Spanning or Concatenation)
JBOD - (Just a Bunch of Disks)

ATAPI Support

Yes

Physical Characteristics

Color

Red

Product Width

0.7 in [1.8 cm]

Product Length

2.8 in [7.1 cm]

Weight of Product

1.2 oz [33.0 g]

Product Height

4.8 in [12.1 cm]

Software

OS Compatibility

Windows® 7, 8, 8.1, 10, 11
Windows Server® 2012 R2, 2016, 2019
macOS® 10.10 to 12
Linux 2.6.32 and up

What's in the Box

1 - Included in Package

SATA Controller Card
Full-Profile Bracket (Installed)
Low-Profile Bracket
Quick-Start Guide

Manufacturer Part No:
10P6G-PCIE-SATA-CARD
Brand:
Product Type:
-
UPC
065030893763
Product Family:
-
Shipping Weight:
1.01 kg
PB Part No:
ADPSTT5386999
Product Model:
10P6G-PCIE-SATA-CARD
Warranty: 12 months *
