StarTech.com PEXUSB3S24 2 Port PCIe USB3.0 Card Adapter with UASP

PB Tech price
PB Tech price
$ 57 .03
 +GST
$ 65 .58
 inc GST
$57.03  +GST
$65.58

StarTech.com PEXUSB3S24 2 Port PCIe USB3.0 Card Adapter with UASP

  • Brand: StarTech.com
  • MPN: PEXUSB3S24
  • Part #: ADPSTT690113
  • UPC: 065030855587
5
PB Tech price
$ 57 .03 $ 65 .58
 +GST  inc GST


Click & Collect: Select your store to check availability
Delivery: Order now and it ships tomorrow When will I receive it?
$57.03  +GST
$65.58

Four payments of $16.56 per fortnight*

Afterpay lets you spread the cost of your purchase over 4, interest-free, fortnightly payments.

Click the button below or select Afterpay as your payment method during the checkout process.

If you do not have a Afterpay account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.

Learn more about Afterpay

  • Brand: StarTech.com
  • MPN: PEXUSB3S24
  • Part #: ADPSTT690113
  • UPC: 065030855587

What PB Tech customers are saying about this product...

See More Reviews

"Has a SATA power connector - when used, this allows delivery of higher power via the connected USB ports. I haven't seen it "kick in" yet but could conceivably be useful to avoid i ...view more"

JB
By: JohnB4794 02/02/26
Verified Owner

"It does what's advertised, easy to set up, and I'm two USB ports richer. Good purchase!"

SW
By: StuartW563 22/11/22
Verified Owner

""Dose exactly what it says on the tin"". No need to load driver from disk, Win 10 found it immediately and it worked straight away."

PP
By: PhilipP93 03/01/22
Verified Owner

Features

The PEXUSB3S24 2-Port PCI Express USB 3.0 Card lets you add two USB 3.0 ports to your PCI Express-enabled computer system, with an optional SATA power connector to connect to your system power supply and deliver up to 900mA of power per port to USB 3.0 bus-powered devices (500mA for USB 2.0).

Enhanced with UASP support (USB Attached SCSI Protocol), this USB 3.0 controller performs up to 70% faster than conventional USB 3.0 when paired with a UASP supported enclosure (Note: UASP is not supported by all operating systems). Using a more efficient protocol than the traditional USB BOT (Bulk-Only Transport), UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly increasing transfer speeds for less wait time on data transfers. See our UASP test results below for further details.

The PCIe USB 3.0 adapter is compliant with USB 3.0 standards for data transfer speeds up to 5 Gbps, while still offering backward compatibility with existing USB 2.0 / 1.1 devices. For added versatility, the controller card is equipped with a standard profile bracket and includes a low-profile/half-height bracket for installation in small form-factor computers.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

Improved Performance with UASP

UASP is supported in Windows® 8, 8.1, Server 2012 and Linux kernel 2.6.37 or later. In testing UASP performed with up to a 70% faster read / 40% faster write speed over traditional USB 3.0 at peak performance.

https://www.pbtech.co.nz/fileslib/_20170119163339_StarTech_2_Port_USB_Adapter_descr_001.jpg

At the same peak in testing, UASP also showed up to an 80% reduction in required processor resources.



https://www.pbtech.co.nz/fileslib/_20170119163339_StarTech_2_Port_USB_Adapter_descr_002.jpg



Specifications

Bus Type

PCI Express

Card Type

Standard Profile (LP bracket incl.)

Interface

USB 3.0

Port Style

Integrated on Card

Ports

2

Maximum Cable Length

9.8 ft [3 m]

Maximum Data Transfer Rate

5 Gbps

Type and Rate

USB 3.0 - 5 Gbit/s

UASP Support

Yes

Connector Type

1 - PCI Express x1 Male

External Ports

2 - USB Type-A (9 pin) USB 3.0 Female

Internal Ports

1 - SATA Power (15 pin) Plug

OS Compatibility

Windows Vista, 7, 8, 8.1, 10
Windows Server 2008 R2, 2012, 2012 R2, 2016
Linux 2.6.31 to 4.4.x LTS versions only

Special Notes / Requirements

The maximum throughput of this card is limited by the bus interface. If used with PCI Express Gen 1.0 enabled computers, the max throughput is 2.5 Gbps. If used with PCI Express Gen 2.0 enabled computers, the max throughput is 5 Gbps.

System and Cable Requirements

Available PCI Express slot

Humidity

20-80% RH

Operating Temperature

5°C to 50°C (41°F to 122°F)

Storage Temperature

-25°C to 70°C (-13°F to 158°F)

Dimensions

Height: 4.7 in (120 mm)
Length: 2.6 in (65 mm)
Width: 0.7 in (18 mm)

Manufacturer Part No:
PEXUSB3S24
Brand:
Product Type:
-
UPC
065030855587
Product Family:
-
Shipping Weight:
0.2 kg
PB Part No:
ADPSTT690113
Product Model:
PEXUSB3S24
Warranty: 24 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
Provide feedback on product content: If this product page is missing key information or you spotted a mistake
