HOUSEWATCH 55-461 360 Degree Surface/Flush Sensor. IP44. Passive IR. 7m Detection Range at 2.5m High. Cutout diameter: 57mm. Dual Element Sensor. White Colour.
HOUSEWATCH 55-461 360 Degree Surface/Flush Sensor. IP44. Passive IR. 7m Detection Range at 2.5m High. Cutout diameter: 57mm. Dual Element Sensor. White Colour.
- Brand: HOUSEWATCH
- MPN: 55-461
- Part #: ALCHWC0099
- UPC:
- Brand: HOUSEWATCH
- MPN: 55-461
- Part #: ALCHWC0099
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Sensors





HOUSEWATCH 55-461 360 Degree Surface/Flush Sensor. IP44. Passive IR. 7m Detection Range at 2.5m High. Cutout diameter: 57mm. Dual Element Sensor. White Colour.
- Brand: HOUSEWATCH
- MPN: 55-461
- Part #: ALCHWC0099

Product URL: https://www.pbtech.co.nz/product/ALCHWC0099/HOUSEWATCH-55-461-360-Degree-SurfaceFlush-Sensor-I
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
360 Degree Surface/Flush Sensor
-Manual overload
-Adjustable Time, Distance & Lux
-Built-in walk test function
-Dual element sensor
-Cutout diameter: 65mm
-Polycarbonate construction
-Minimum load 10W
-IP44
-Passive IR
-7m Detection Range at 2.5m High
Specifications
Mounting
Surface or Flush
Sensor Type
Passive IR
Detection Range
7m Diameter at a 2.5m Mounting Height
Detection Angle
360° Adjustable with Lens Shield
Time on Adjustment
5 sec to 30 mins
Lux Setting (Lux)
0 to 2000
Load
2000W max. for Incandescent Light
1000W max. for Halogen Light
1000VA max. for Low Voltage Halogen Light
900VA/100µ F for Fluorescent Light
600VA (400W) Max. for Energy Saving Lamp (CFL PL Lamps)
Voltage
240V AC 50Hz
Operating Temperature
0°C to +45°C
Environment Protection
IP44
