Cerwin-Vega CERWIN VEGA XED8001D AMPLIFIER XED SERIES MONO 450W RMS 4OHM / 800W RMS 2OHM
Cerwin-Vega CERWIN VEGA XED8001D AMPLIFIER XED SERIES MONO 450W RMS 4OHM / 800W RMS 2OHM
- Brand: Cerwin-Vega
- MPN: XED8001D
- Part #: AUDCWV1057
- UPC:
- Brand: Cerwin-Vega
- MPN: XED8001D
- Part #: AUDCWV1057
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Amplifiers





Cerwin-Vega CERWIN VEGA XED8001D AMPLIFIER XED SERIES MONO 450W RMS 4OHM / 800W RMS 2OHM
- Brand: Cerwin-Vega
- MPN: XED8001D
- Part #: AUDCWV1057

Product URL: https://www.pbtech.co.nz/product/AUDCWV1057/Cerwin-Vega-CERWIN-VEGA-XED8001D-AMPLIFIER-XED-SER
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
XED (Xtreme Energy Design) series amplifiers are legitimately just that, extreme to the core! XED series amplifiers deliver insane power output and is clearly designed and engineered to crush the watts per dollar criteria! Utilizing the latest high efficiency Class D topology circuit design encompassed in a compact aluminum chassis, XED series amplifiers will wake up any speaker or subwoofer by delivering pure power and performance for loud continuous play.
- 1100W MAX Power
- 1 Channel Amplifier
- 800W x 1 @ 2O RMS
- 450W X 1 @ 4O RMS
- Crossover: 35Hz~250Hz (LP)
- Frequency Response: 10Hz~30KHz
- Dimensions: 8.7"x 4.7" x 1.8" ( 220.98mm x 119.38mm x 45.72mm)
- Latest High-Efficiency Class D Topology
- Compact Size with Ambient backlit logo
- RCA "Pass Thru" output for easy system expansion
- Fully Variable Crossovers (12dB per octave)
- Handles HI and LO level input to 12V
- 2 O Stable
- Proprietary Vega Bass Boost EQ Up To 12dB
- Dimensions: 8.7"x 4.7" x 1.8" ( 220.98mm x 119.38mm x 45.72mm)
Specifications
Amplifier
1 Channel
RMS Power Rating
450w @ 4O/800w @ 2O
Amplifier Power
1100W MAX
RMS Power(2O)
800w
RMS Power (4O)
450w
Types
Monoblock, Class D
Topology
Class D
Frequency Response
10Hz~30KHz
Power Supply
Full PWM
Power Supply (Threshold)
10.0DVC - 16.0DVC
Idle Current
(0.7A)
Distortion - THD (1KHz@4O)
<0.1%
Distortion - S/N Ratio (A weight @ 1W)
-85dBA
Distortion - S/N Ratio (A weight @ FP)
-101.1dBA
Input Sensitivity Low
250mV - 6.0V
Input Sensitivity High
1.1V ~>20.0V
Input Impedance - Low Input Level
20 KO
Input Impedance - High Input Level
100 O
Output Impedance
2O
Damping Factor (50Hz@4O)
>70
Bandwidth (-3dB)
10Hz-250Hz
Crossover (-12 dB/ Oct) Variable High-Pass
N/A
Crossover (-12 dB/ Oct) Variable Low-Pass
35Hz-250Hz
Crossover (-12 dB/ Oct) Variable Sub-Sonic
10Hz-50Hz
FUSE Ratings - ATC
2 x 35A INTERNAL
Remote
Bass Level Control
Dimension - Length x Width x Height - Inches(mm)
8.7"x 4.7" x 1.8" ( 220 x 120 x 46.5mm )
