Onkyo M-80B Icon Power Amplifier - Black
200W at 4 Ohm
Onkyo M-80B Icon Power Amplifier - Black
200W at 4 Ohm
- Brand: Onkyo
- MPN: M-80B
- Part #: AUDOKY10035
- UPC:
- Brand: Onkyo
- MPN: M-80B
- Part #: AUDOKY10035
- UPC:
Features
ONKYO Icon Power Amplifier. With a three-stage Inverted Darlington Amplifier and great attention paid to vibration suppression, the Onkyo M-80 Power Amplifier powerfully drives large speakers to deliver dynamic full range audio that will captivate and move you.
Refined Style You Can Feel
Just as your favourite music resonates on an emotional level, premium design is felt instinctively. Intuitively. The Onkyo Icon Series is meticulously designed for simplicity and balance, blending an elegant form factor with classic hi-fi details. Carefully selected materials and tactile buttons and knobs elevate the user experience to something greater than the sum of its parts.
Superior Sound Starts With Onkyo
Sophisticated circuitry, elevated design choices, and next-generation tech are woven into every millimetre of Onkyo's new Icon Series. Our dedicated engineers believe everyone deserves an exceptional listening experience with all the nuance, detail, and emotion that the artists or players intended. The content played through any of our Icon Series products isn't just heard - it's felt.
Powering The Music That Moves You
The M-80 uses a three-stage Inverted Darlington Amplifier. The three-stage Inverted Darlington Amplifier has a very low output impedance and drives speakers powerfully with a large current. Also, by keeping NFB (Negative Feedback) low, it is not affected by noise from the speaker. It offers a powerful yet highly resolving and informative sound. The M-80's output stage transistors are in parallel configuration, which provides excellent instantaneous current supply capability, further enhancing the rise of sound and the sense of power. The driver stage of the M-80 amplifier uses DIDRC (Dynamic Intermodulation Distortion Reduction Circuitry). Reducing beats generated signals(noise) in the ultra-high frequency band by DIDRC's high slew rate designand helps produce the natural sound of an analog record.
Cutting Edge Componentry For Captivating Playback
The Onkyo M-80 Power Amplifier features a custom high-current power supply to provide dynamic full-range sound, and an extrusion aluminium heat sink that suppresses vibration. The addition of high-quality 10000uF capacitors custom-made exclusively for Onkyo, Hi-Fi grade terminals (both speaker output and audio input terminals), copper bus bars, and a robust vibration-proof front panel ensures powerful, world-class playback.
The M-80 housing consists of two aluminium side panels and a steel top panel. The three-piece construction of the housings increases rigidity and improves seismic resistance. Various vibrations are suppressed, and sound quality is improved.
Create your Perfect System
The M-80 has an output power of 150W (8Ω, 1kHz, THD 0.7%, 2ch driven) / 200W (4Ω, 1kHz, THD 0.7%, 2ch driven), which allows it to powerfully drive large speakers and bring you dynamic acoustic information. For example, Klipsch Forte speakers paired with the P-80 and M-80 would maximise the dynamic and extended sound of the Forte.
From Onkyo Academy: The Benefits Of A Power Amplifier
A power amplifier receives the signal from your pre-amp and literally powers it into your speakers. Think of your pre-amp as a brain, and your power amplifier as the muscle. Separating your amplifiers into pre- and power gives you ultimate flexibility in audio playback. Since they are not affected by each other's circuits, they can provide high-resolution sound quality through even cleaner signal transmission. Audiophiles are well-known to prefer specific power amps and the way they impact sound quality and colouration. The M-80 is a power amplifier that reproduces the full range of artists' or players' intentions in their music and drives you into a world of emotion.
Specifications
Reviews
Delivery & Pick-up
Delivery Estimates
The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-4 working days.
Next Day Delivery
Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.
Same Day Delivery
Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security & Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
1 Hour Store Pick-up / Click & Collect
You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.
Overseas Shipments
PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Amplifiers
WiiM Amp 120W 2.1 Channel Multiroom Streaming Amplifier - Space...
WiiM Amp Ultra 200W 2.1 Channel Multiroom Streaming Amplifier...
WiiM Amp Pro 120W 2.1 Channel Multiroom Streaming Amplifier with...
AUDIOENGINE N22 (Gen 2) Premium Desktop Audio Amplifier with...
WiiM Vibelink Amp 200W Power Amplifier with Premium ESS SABRE DAC...
Onkyo M-80B Icon Power Amplifier - Black 200W at 4 Ohm
- Brand: Onkyo
- MPN: M-80B
- Part #: AUDOKY10035
Product URL: https://www.pbtech.co.nz/product/AUDOKY10035/Onkyo-M-80B-Icon-Power-Amplifier---Black-200W-at-4
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
ONKYO Icon Power Amplifier. With a three-stage Inverted Darlington Amplifier and great attention paid to vibration suppression, the Onkyo M-80 Power Amplifier powerfully drives large speakers to deliver dynamic full range audio that will captivate and move you.
Refined Style You Can Feel
Just as your favourite music resonates on an emotional level, premium design is felt instinctively. Intuitively. The Onkyo Icon Series is meticulously designed for simplicity and balance, blending an elegant form factor with classic hi-fi details. Carefully selected materials and tactile buttons and knobs elevate the user experience to something greater than the sum of its parts.
Superior Sound Starts With Onkyo
Sophisticated circuitry, elevated design choices, and next-generation tech are woven into every millimetre of Onkyo's new Icon Series. Our dedicated engineers believe everyone deserves an exceptional listening experience with all the nuance, detail, and emotion that the artists or players intended. The content played through any of our Icon Series products isn't just heard - it's felt.
Powering The Music That Moves You
The M-80 uses a three-stage Inverted Darlington Amplifier. The three-stage Inverted Darlington Amplifier has a very low output impedance and drives speakers powerfully with a large current. Also, by keeping NFB (Negative Feedback) low, it is not affected by noise from the speaker. It offers a powerful yet highly resolving and informative sound. The M-80's output stage transistors are in parallel configuration, which provides excellent instantaneous current supply capability, further enhancing the rise of sound and the sense of power. The driver stage of the M-80 amplifier uses DIDRC (Dynamic Intermodulation Distortion Reduction Circuitry). Reducing beats generated signals(noise) in the ultra-high frequency band by DIDRC's high slew rate designand helps produce the natural sound of an analog record.
Cutting Edge Componentry For Captivating Playback
The Onkyo M-80 Power Amplifier features a custom high-current power supply to provide dynamic full-range sound, and an extrusion aluminium heat sink that suppresses vibration. The addition of high-quality 10000uF capacitors custom-made exclusively for Onkyo, Hi-Fi grade terminals (both speaker output and audio input terminals), copper bus bars, and a robust vibration-proof front panel ensures powerful, world-class playback.
The M-80 housing consists of two aluminium side panels and a steel top panel. The three-piece construction of the housings increases rigidity and improves seismic resistance. Various vibrations are suppressed, and sound quality is improved.
Create your Perfect System
The M-80 has an output power of 150W (8Ω, 1kHz, THD 0.7%, 2ch driven) / 200W (4Ω, 1kHz, THD 0.7%, 2ch driven), which allows it to powerfully drive large speakers and bring you dynamic acoustic information. For example, Klipsch Forte speakers paired with the P-80 and M-80 would maximise the dynamic and extended sound of the Forte.
From Onkyo Academy: The Benefits Of A Power Amplifier
A power amplifier receives the signal from your pre-amp and literally powers it into your speakers. Think of your pre-amp as a brain, and your power amplifier as the muscle. Separating your amplifiers into pre- and power gives you ultimate flexibility in audio playback. Since they are not affected by each other's circuits, they can provide high-resolution sound quality through even cleaner signal transmission. Audiophiles are well-known to prefer specific power amps and the way they impact sound quality and colouration. The M-80 is a power amplifier that reproduces the full range of artists' or players' intentions in their music and drives you into a world of emotion.
Specifications
OUTPUT POWER
150W (8Ω, 1kHz, THD 0.7%, 2ch driven)
200W (4Ω, 1kHz, THD 0.7%, 2ch driven)
AMPLIFIER CHANNEL
2 Ch
AMPLIFIER TYPE
Class AB
FREQUENCY RESPONSE
5Hz~100kHz(+1/-3dB)
SPEAKER IMPEDANCE
4-16Ω
ANALOG AUDIO INPUT
RCA (Unbalanced) x 1 pair
XLR (Balanced) x 1 pair
12V TRIGER Input
1/8" (3.5mm) Jack
PRODUCT DIMENSIONS (W X H X D)
17.1" (435mm) x 5.3" (135mm) x 13.6" (345mm)
PRODUCT WEIGHT
13.5 kg
PACKAGE DIMENSIONS (W X H X D)
21.3" (542mm) x 9.3" (236mm) x 17.4" (441mm)
POWER CONSUMPTION
445w
51w (idle)
Less than 0.3w (Standby)
