SOUNDCRAFT UI24R 24 INPUT DIGITAL MIXER W/USB MULTITRACK

PB Tech price
PB Tech price
$ 1,913 .04
 +GST
$ 2,200 .00
 inc GST

Out of stock

SOUNDCRAFT UI24R 24 INPUT DIGITAL MIXER W/USB MULTITRACK

  • Brand: SOUNDCRAFT
  • MPN: UI24R
  • Part #: AUDSCF5086001
  • UPC:
NEW ARRIVAL
PB Tech price
$ 1,913 .04 $ 2,200 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?
  • Brand: SOUNDCRAFT
  • MPN: UI24R
  • Part #: AUDSCF5086001
  • UPC:

Features





A Complete Digital Mixing System

The Ui24R is a complete digital mixing and multi-track recording system that delivers flexible I/O, pristine sound quality, intuitive wireless control, and roadworthy reliability-all in a streamlined design. The system can be controlled by up to 10 devices via Ethernet or built-in dual-band Wi-Fi, making it possible to control mixing and multi-track recording wirelessly. Renowned Lexicon, dbx and DigiTech signal processing ensures pristine sound, while 20 Studer-designed microphone preamps deliver more professional inputs than any other mixer in its class. The compact, rack-mounted Ui24R is also compatible with the new HARMAN Connected PA ecosystem, and offers unprecedented control, versatility and power at an incredible value.

- Renowned Soundcraft quality and performance
- Built-in dual-band Wi-Fi provides a reliable connection
- Legendary Lexicon and dbx signal processing
- Professional-quality Studer-designed preamps
- 2 channels of DigiTech guitar/amp modeling
- Cross-platform compatibility for complete control on any device
- Tablet/PC/Smart Control allows up to 10 device connections
- 32-in/32-out USB recording interface
- 24-channel direct-to-memory recording
- 10 combo 1/4"-TRS/XLR, 10 XLR, 2 line, and 2 channels of digital playback for a total of 24 simultaneous inputs
- HARMAN Connected PA compatible

More Ways to Connect

When you need a mixer with comprehensive connections and a compact footprint, Ui24R provides the perfect solution. The streamlined Ui24R allows you to mix from multiple sources including 10 combo 1/4"-TRS/XLR, 10 XLR, 2 line level inputs, and 2 channels of digital USB playback for a total of 24 channels. With its flexible and high-quality I/O, Ui24R gives venues, bands and engineers room to grow, while expanding your creative options.



More Ways to Control

Control Ui24R from the device of your choice via iOS, Android, Windows, Mac OS and Linux browsers, without installing apps. Onboard dual-band WiFi ensures you (and up to 9 members of the band) always have creative control. Musicians can adjust their individual mix on stage while the FOH engineer optimizes the audience experience. Experience easier set up and control when used with the HARMAN Connected PA App and compatible products like JBL PRX800W loudspeakers, dbx DI1 stageboxes, and AKG P5i microphones.



Multi-track Recording and Playback

Ui24R is more than just a complete mixing system-it's also a top-notch recording tool. Enjoy peace of mind with dual-path, multi-track recording of all 22 inputs and your stereo mix, directly to a USB storage drive AND a connected computer. The multichannel USB audio interface also makes it easy to integrate the Ui24R into your recording studio for production work with your favorite DAW.



Harman Sound Quality and Reliability

Ui24R brings together industry-leading HARMAN technologies to deliver unprecedented power and missioncritical stability. Renowned Studer preamps deliver rich sound for live performance and multitrack recording, while iconic Lexicon reverbs, choruses, delays, and dbx compression offer polished results for vocals, acoustic guitar and more. dbx AFS2 automatic feedback suppression is available on all monitor outputs, providing an excellent live experience. Plus, DigiTech guitar amp modeling brings a host of effects to any performance, particularly when low stage volume is desired.

Specifications

(20) Mic Preamps

Studer designed, 10 combi, 10 XLR

(2x) Line Inputs

10 unbalanced

(2x) Master Outputs

+4 XLR, with individual volume pots

(2x) Headphone Outputs

With shared volume pot

(8x) AUX Outputs

+4 XLR with 32 band graphic and dbx AFS² Feedback Suppression

USB PLAY

USB A port

USB RED

USB A port

USB I/F

USB B port

USB 1

USB A, for controllers (such as a computer mouse)

USB 2

USB A, for software update installation

Footswitch

1/4" for closure pedal event trigger

Ethernet

RJ45, for LAN connections

Manufacturer Part No:
UI24R
Brand:
SOUNDCRAFT
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.2 kg
PB Part No:
AUDSCF5086001
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
