Shure Aniusb-Matrix - Audio Network Interface -POE -4 Dante audio inputs - 1 analog input - Matrix Mixing

Out of stock

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

This product can only be sold to limited liability companies, local councils, government departments and schools. A limited liability company name or valid council, government department or school name must be entered during the checkout process.

Shure Aniusb-Matrix - Audio Network Interface -POE -4 Dante audio inputs - 1 analog input - Matrix Mixing

  • Brand: Shure
  • MPN: ANIUSB-MATRIX
  • Part #: AUDSHU2000
  • UPC:
No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock
Sign in to your commercial account or apply online now to view the price and order this product

Features



Audio network interface connects up to 4 Dante channels and 1 analog output to a room's audio and video conferencing system via USB connection. Internal matrix mixer offers flexible routing, allowing users to route any input to any output.

- Connects 4 Dante audio inputs and 1 analog input to an A / V conferencing system or a PC-based videoconferencing application
- Flexible signal routing and connectivity: analog audio (1 block in / 1 block out) to room A / V conferencing system; USB (1 in / out) to connect to laptop or room PC
- Power-over-Ethernet (PoE) eliminates the need for an outboard power supply
- Compact form factor is easy to mount without equipment rack

The ANIUSB-MATRIX USB Audio Network Interface complements the existing ANI4IN, ANI4OUT, and ANI22 products. It offers the ideal performance, connectivity, and affordability for audio/video conferencing installations in small and medium-size meeting rooms when a premium microphone solution is desired, and acoustic echo cancellation of an A / V conferencing codec will be used.

The ANIUSB-MATRIX connects 4 Microflex® Advance™ or Microflex® Wireless microphone channels via Dante (4 in / 2 out), and provides analog connectivity (1 block in / 1 block out) to a room audio / video conferencing system or a PC-based A / V conferencing application via USB (1 in / out).

An internal matrix mixer offers flexible routing, allowing users to route any input to any output. A 4-band parametric EQ filter is also available on the analog and USB outputs.

The ANIUSB-MATRIX supports standards-based security protocols to manage access and protect data, including 802.1x, secure boot/storage, and AES encryption for control and audio data.

Specifications

Inputs (Analog)

1 x 3-pin block connector (active balanced)

Outputs (Analog)

1 x 3-pin block connector (impedance balanced)

USB Connection

1 x USB 2.0, Type-B

Dante Connection

1 x RJ45
Channel Count: 4 inputs, 2 outputs

Polarity

Non-inverting, any input to any output

Power Requirements

Power over Ethernet (PoE), Class 0 (PoE Plus compatible)

Power Consumption

6.5 W maximum

Application Control

HTML5 browser based

Operating Temperature Range

20 to 104°F (-6.7 to 40°C)

Storage Temperature Range

20 to 165°F (-29 to 74°C)

Thermal Dissipation

Maximum: 6.8 W (23.0 BTU/hr)
Typical: 6.0 W (20.8 BTU/hr)

Audio

Frequency Response

20 Hz to 20 kHz +1, -1.5 dB

Dante Audio Flows

Sampling Rate: 24-bit/48 kHz

USB Audio

16-, 24-bit/44.1, 48 kHz

Latency

Does not include Dante latency
Analog to Analog: 0.98 ms
Analog to Dante 0.39 ms
Dante to Analog: 0.72 ms
Dante to Dante: 0.14 ms

Dynamic Range

20 Hz to 20 kHz, A-weighted, typical
Analog to Dante: 113 dB
Dante to Analog: 117 dB

Equivalent Input Noise

20 Hz to 20 kHz, A-weighted, input terminated with 150 Ohms
Line: -86 dBV
Aux: -98 dBV

Total Harmonic Distortion (THD)

<0.05% @ 1 kHz, 0 dBV input, 0 dB analog gain

Common Mode Rejection Ratio

>70 dB, 150 Ohms balanced source @ 1 kHz

Impedance

10.6 kOhms

Input Clipping Level

Line: +27 dBV
Aux: +15 dBV

Output Clip Level

Line: +20 dBV
Aux: 0 dBV
Mic: -26 dBV

Digital Signal Processing (DSP)

Per Channel: Equalizer (4-band Parametric, Analog and USB output channels only), Mute, Limiter, Gain (140 dB range)
System: Matrix mixer

Networking

Cat 5e or higher (shielded cable recommended)

Dimensions

1.6 x 5.5 x 5.0" (4 x 14 x 12.8 cm)

Weight

1.5 lb (672 g)

Manufacturer Part No:
ANIUSB-MATRIX
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.2 kg
PB Part No:
AUDSHU2000
Product Model:
Aniusb-Matrix
