CSB BAT12V7A 12v 7.2Ah 25W General Purpose Security Battery for Alarm Systems Up to 5 years in Standby Service or more than 260 Cycles at 100% Discharge in Cycle Service, F1 Terminal - Not Suitable for UPS
CSB BAT12V7A 12v 7.2Ah 25W General Purpose Security Battery for Alarm Systems Up to 5 years in Standby Service or more than 260 Cycles at 100% Discharge in Cycle Service, F1 Terminal - Not Suitable for UPS
- Brand: CSB
- MPN: BAT12V7A
- Part #: BATCSB1207
- UPC:
- Brand: CSB
- MPN: BAT12V7A
- Part #: BATCSB1207
- UPC:
What PB Tech customers are saying about this product...
See More Reviews"Cost effective and functional and does what is says on the tin Noted other review in which a previous one had lasted several years which was encouraging"
"Product is as described and is a drop in replacement for the Dynamix 1200 defender UPS.
It is the same part as what the original device came with.
Silence the 😡🚨even when ...view more"
"Got 10 a year ago, to power PIT tag readers deployed in a bird colony. These replaced the original ones deployed 12 years ago. Have bought 2 more sets of 10 since, 18 in tot ...view more"
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Battery Accessories





CSB BAT12V7A 12v 7.2Ah 25W General Purpose Security Battery for Alarm Systems Up to 5 years in Standby Service or more than 260 Cycles at 100% Discharge in Cycle Service, F1 Terminal - Not Suitable for UPS
- Brand: CSB
- MPN: BAT12V7A
- Part #: BATCSB1207

Product URL: https://www.pbtech.co.nz/product/BATCSB1207/CSB-BAT12V7A-12v-72Ah-25W-General-Purpose-Security
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
CSB 12v 7.2Ah 25W General Purpose Security Battery for Alarm Systems, Up to 5 years in Standby Service or more than 260 Cycles at 100% Discharge in Cycle Service, F1 Terminal.* Not recommended for UPS*
BAT12V7A is a general-purpose battery up to 5 years in standby service.
As with all CSB batteries, all are rechargeable, highly efficient, leakproof and maintenance-free.
This battery has F1 terminals which is not recommended for UPSes
please consider the alternate product: BATSLT1207
MORE INFO:
https://cdlnz.com/content/images/PDF/bat12v7a.pdf
Specifications
Cells Per Unit
6
Voltage Per Unit
12 V
Capacity
24.5W @15Min-rate to 1.67V per cell @ 25°C (77°F)
Weight
Approx. 1.84 Kg (4.06 lbs)
Maximum Discharge current
100/130A (5 Sec)
Internal Resistance
Approx. 25.8 mO
Operating Temperature Range
Discharge:-15~50C(5°F~122°F)
Charge:-15~40C(5°F~104°F)
Storage:-15~40C(5°F~104°F)
Nominal Operating Temperature Range
25±3C(77°F±5°F)
Float charging voltage
13.5 to 13.8 VDC/Unit Average at 25C (77°F)
Recommended Maximum Charging current limit
2.5A
Equalization and Cycle Service
14.4 to 15.0 VDC/Unit Average at 25C(77°F)
Self Discharge
It should be more than 75% of the capacity before storage after stocked for 6 months at ambient temp. 25C
Terminal
F1/F2-Faston Tab187/250
Container Material
ABS(UL94-HB) & Flame retardant(UL94-V0) available upon request.
