FUSION SIGNATURE SERIES MARINE AMPLIFIER 6-CH 1500W 24VOLT

PB Tech price
PB Tech price
$ 907 .83
 +GST
$ 1,044 .00
 inc GST

Out of stock

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

FUSION SIGNATURE SERIES MARINE AMPLIFIER 6-CH 1500W 24VOLT

  • Brand: FUSION
  • MPN: 010-02556-00
  • Part #: CARFSN1011
  • UPC:
PB Tech price
$ 907 .83 $ 1,044 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?

Features

Fusion Signature Series Marine Amplifiers 6-CH, 1500W, 24 Volt

Purpose-built for the marine environment, the Signature Series marine amplifiers feature some of the most impressive protection from the environment available - delivering a Signature performance out on the water.

- Class-D design delivers higher efficiency and greater output.
- Connect up to two speakers per channel at 2 ohms, or bridge two channels at 4 ohms for increased power.
- Conformal coated PCBs provide extra protection from the marine elements.
- Rigid aluminum alloy heat sink is molded for greater dissipation of heat.

DESIGNED AND ENGINEERED TO TRUE-MARINE™ STANDARDS:

Purpose-built for the marine environment, the Signature Series marine amplifiers feature some of the most impressive protection from the environment available - delivering a Signature performance out on the water. Built on the True-Marine design philosophy from Fusion, the Signature Series amplifiers have been tested to a high level of protection against salt fog, temperature, vibration and UV.

STAINLESS STEEL MIRROR FINISH

The polished stainless steel control panel cover conceals and helps protect all cable connections and settings controls while providing an attractive finish to complement any installation.

MARINE-READY DESIGN WITH CONFORMAL COATED PCBS

Helping to extend the life of your amplifiers, the Signature Series amplifiers are designed with conformal coated PCBs to provide extra protection from the marine elements.

Specifications

Physical dimensions (LxWxH)

24-Volt 6 channel: 16.54" x 8.27" x 2.24" (420 x 210 x 57 mm)

Amplifier class

D

Peak power (Watts)

1500W

Total rated power output - 4 Ohm (Watts)

100 W RMS x 6 @ 28.8 V input - 4 Ohm < 1% THD

Total rated power output - 2 Ohm (Watts)

140 W RMS x 6 @ 28.8 V input - 2 Ohm < 1% THD

Total rated power output (Watts)

280 W RMS x 3 @ 28.8 V input - 4 Ohm Bridged < 1% THD

Frequency response

10 Hz - 40 kHz (-3dB, dB @ 4 Ohm rated power)

Input sensitivity

0.3 V - 8 V RMS (user adjustable)

Input impedance

7k Ohm nominal

High-pass/low-pass full range filter

yes (user selectable)

HP variable crossover frequency

32 Hz - 320 Hz

LP variable crossover frequency

32 Hz - 320 Hz

Bass boost

0 dB - 9 dB, user adjustable (zone 3 only)

Operating voltage

21.6 V - 32 V DC

Current consumption (StandBy)

< 1 mA @ 28.8 V input

Current consumption (Idle)

< 1.25 A @ 28.8 V input

Current consumption (Max)

35 A

Fuse rating

24-Volt 6 channel: 3 x 20 A ATC blade-type (SAE J1171 compliant)

Operating temperature range

32° to 122° F (0° to 50° C)

Manufacturer Part No:
010-02556-00
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1.01 kg
PB Part No:
CARFSN1011
Product Model:
-
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
