Rockford Fosgate Punch P300-8P 30-200Hz Frequency Response 300w RMS 300W 8" Powered Subwoofer Enclosure
Rockford Fosgate Punch P300-8P 30-200Hz Frequency Response 300w RMS 300W 8" Powered Subwoofer Enclosure
- Brand: Rockford Fosgate
- MPN: P300-8P
- Part #: CARRFG1016
- UPC: 780687353971
Select your store to check availability
- Brand: Rockford Fosgate
- MPN: P300-8P
- Part #: CARRFG1016
- UPC: 780687353971
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Car Audio
Rockford Fosgate Punch P300-8P 30-200Hz Frequency Response 300w RMS 300W 8" Powered Subwoofer Enclosure
- Brand: Rockford Fosgate
- MPN: P300-8P
- Part #: CARRFG1016
- UPC:780687353971
Product URL: https://www.pbtech.co.nz/product/CARRFG1016/Rockford-Fosgate-Punch-P300-8P-30-200Hz-Frequency
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 1 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Nelson | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 1 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
The Punch P300-8P is an "all in one" solution for dropping Bass in any factory or aftermarket system. This model features an 8" high output woofer with a 300-watt internal amplifier in a slim design enclosure that's great for truck and small car applications. The enclosure features quick release input and power connectors for easy removal when extra space is required.
The Punch 300-8P is a self-contained subwoofer enclosure with built-in amplifier. This "all in one" solution is great for systems that need extra Punch on the low-end of the frequency spectrum. The 8" high output subwoofer is impedance optimized for the built in 300-watt class-D amplifier that features a low-pass crossover, bass EQ and phase switch. The enclosure can be connected via speaker level inputs for connection to factory systems, or traditional line level inputs for aftermarket systems. It also features an intelligent auto turn-on/off circuit that eliminates the need for a separate turn-on wire. The enclosure itself is precision designed and constructed using MDF (Medium Density Fiberboard) for the best acoustical properties and covered with heat activated vinyl finish to resist marks.
- High-Efficiency, Low Current Amplifier Design
- Thermal and over/under voltage protection
- Intelligent auto turn on/off function
- Robust Power/Ground connections
- Adjustable 12db/Octave low pass crossover
- Separate low level and speaker level inputs
- Optimized 8" Low Impedance Woofer
- 300 Watt Class-D Amplifier with Optimized "Closed Loop" Design
- On Board Phase Switch
- Quick Input Connections for Easy Removal
- On Board Adjustable Bass EQ
- Precision Constructed MDF Enclosure with Heat Activated Vinyl Finish
- Slim Design For Truck Applications
- Remote bass level control included
Specifications
Frequency Response
30 Hz to 200 Hz
Woofer Quantity
1
Woofer Size
8"
Woofer Series
Proprietary
Nominal Impedance
-
Power Handling (Watts RMS)
300 Watts RMS
Enclosure Type
Vented
Enclosure Material
5/8" MDF (Medium Density Fiberboard
Speaker Connector
-
Integrated Amplifier
300 Watts RMS
Crossover Controls
Variable 50 Hz to 200 Hz
12dB/Octave Butterworth
Tone Controls
Bass Boost
0 dB to +12 dB;
Phase Control
0° to 180°
Remote Control
Punch Level Control (Included)
Replacement Part
1130-59232-01
Auto Turn-On Selector
Remote Trigger
DC Offset Sense
Audio Sense
Input Switch
High-Level (Speaker Line)
Low-Level (RCA)
Signal Input
Low/High-Level: 1 RCA Pair (L/R Summed)
Replacement Part: 1130-59232-01
Input Sensitivity
Low-Level: 150 mV to 6 V
High-Level: 300 mV to 12 V
Input Impedance
20k Ohms
Power Input Connector
Quick Disconnect
Replacement Part
1130-59232-01
Power Wire Gauge
B+/GND: 8 AWG
REM: 18 AWG
Circuit Topology Class
Class-D
Heatsink Type
Extruded Aluminum
Cooling
Convection
Visual Indicators
Power/Protect LED
Fuses
20 Amp (2 x 10 Amp ATO Fuse)
Dimensions Box H x W x D Wedge H x W x D1 x D211.4" x 17.6" x 5.6"
289 mm x 448 mm 141 mm
Shipping Weight
19 lbs. (8.6 kg)
